CNC Surface grinding machine

ABA Z&B Starline 500

Condition: used, Year of construction: 1993, pressure:160 t Nwjdpfxoh Ra R Ie Ag Def throat:360 mm stroke:300 mm table-size:1500 x 700 mm dimension of ram:1200 x 560 mm return capacity:40 t stroke speed:400 m/min stroke speed - under load:16 - 42 Hub/min stroke speed -return:350 mm/min die-cushion pressure:630 kN die cushion stroke:100 mm total power requirement:42 kW weight of the machine ca.:19,5 t pressure of ejector:50 kN ejector stroke:50 mm

Condition: used, Year of construction: 2009, Grinding machines Nwedpfxow Eki To Ag Dsf Travel distance X: 600 mm Travel distance Y :600 mm Travel distance Z: 335 mm Grinding width: 335 mm Grinding length: 800 mm Max. grinding plates: 300 mm Grinding spindle drive: 9,3 kW Speed adjustable: 4200 rpm Distance: table till middle of the spindle: 620 mm Table size: 600 mm Table longitudinal feed oscillation: 50 m/min Table longitudinal feed creep speed: 5 mm/min PA37K – CNC Profile Dressing Device (Diamond Dressing System)

Condition: used, Year of construction: 2010, functionality: fully functional, total height: 2,300 mm, total length: 2,500 mm, total width: 2,400 mm, overall weight: 4,800 kg, travel distance X-axis: 750 mm, travel distance Y-axis: 485 mm, travel distance Z-axis: 335 mm, feed length X-axis: 750 mm, feed length Y-axis: 485 mm, feed length Z-axis: 335 mm, grinding wheel width: 600 mm, table width: 300 mm, Capable of creep feed grinding, plunge grinding, and transverse grinding. This machine also comes with 2x Rotary Diamond Disc dressing units, one unit being stationary and the other unit being an extremely rare option on these machines which is a motorized "swivel" rotary diamond disc dressing unit with a stationary diamond on the end (see pictures). Nedpfexaqm Ssx Ag Dewf

Condition: excellent (used), Vacuubrand chemistry diaphragm pump Here we offer a Vacuubrand chemistry diaphragm pump. VACUUBRAND VARIO chemistry diaphragm pump MV 10C EX VARIO Technical data: Max. Pumping speed 50Hz 8.1 m³/h Ultimate vacuum 2 mbar / 1.5 torr Ultimate vacuum with gas ballast 10 mbar / 7.5 torr Number of cylinders 8 Nsdpfx Agoq Suwme Djwf Number of stages 4 Vacuum display / controller type without controller Ambient temp., lower limit, operation, in °C 10°C Ambient temp., upper limit, operation, in °C 40°C Ambient temp., lower limit, storage, in °C -10°C Ambient temp., upper limit, storage, in °C 60°C Max. Max. outlet pressure absolute in bar 1.1 bar Connection on suction side Small flange KF DN 25 Connection on pressure side Small flange KF DN 16 Nominal power in kW 0.5 kW Minimum speed VARIO in min-1 30 min-1 Maximum speed in min-1 1500 min-1 Nominal speed in min-1 1500 min-1 IP protection class to IEC 60529 IP 54 Dimension L in mm 560 mm Dimension B in mm 457 mm Dimension H in mm 410 mm Weight in kg 61 kg Noise (sound pressure level) in dBA at 50 Hz or 1500 rpm/62% (VARIO)/1500 rpm (VARIO-SP)/12500 rpm (VACUU-PURE®) 42 dBA EX approval Pumping chamber (pumped gases): II 2G Ex h IIC T3 Gb X, external chamber with inert gas purging: II 2G Ex h IIB T4 Gb X, Outdoor area without inert gas purging: II 3G Ex h IIB T4 Gc X, motor: II 2G Ex db IIB T4 Gb NRTL certification No Nominal voltage range 1 (in V) 230 V Mains frequency Voltage range 1 (in Hz / DC) 50 Hz Weight 61 kg Type: MV 10C EX VARIO Condition: gebraucht / used Scope of delivery: (see picture) (Subject to changes and errors in the technical data and specifications!) We will be happy to answer any further questions you may have on the phone.
