EDM

AGIE CHARMILLESS Roboform 31

Condition: used, Year of construction: 1995, functionality: unexamined, machine/vehicle number: XXX, We are going to sell 3 wire edm machines and 1starthole edm machine Rodotylpcepfx Adiou

Condition: excellent (used), Year of construction: 2006, machine/vehicle number: 642576, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 300 mm, workpiece weight (max.): 500 kg, total height: 2,522 mm, total width: 1,690 mm, total length: 1,900 mm, table width: 500 mm, type of input current: three-phase, table length: 400 mm, overall weight: 2,350 kg, table load: 500 kg, For sale is a premium-quality die-sinking EDM machine from Charmilles, model Roboform 350. The machine is in excellent condition, both technically and visually. Technical specifications: Year of manufacture: 2006 Machine no.: 642576 Travel paths (X, Y, Z): 350 x 250 x 300 mm Table dimensions: 400 x 500 mm Max. workpiece weight: 500 kg Max. electrode weight: 50 kg Connected load: 7.5 kVA Current consumption: 10.6 A Voltage: 400 V / 3-phase / 50 Hz Machine weight: 2,350 kg Dimensions (L x W x H): 1,900 x 1,690 x 2,522 mm The scope of delivery does not include chucks or clamping devices; these can be offered separately on request. Transport and loading can be organized throughout Europe at an additional cost. Prices are subject to VAT. Inspection is possible by appointment. Please contact us—our team will be happy to assist you! Trade-in or exchange is possible! Machinery purchase and sale PURCHASE / SALE OF PRODUCTION AND METALWORKING MACHINERY AND MORE. Are you in need of a high-quality yet affordable metalworking machine for your production? Or are you looking to sell your machine? Redpfx Adoykrckeiou For more information or contact options, please visit our website.

Condition: reconditioned (used), Year of construction: 1999, operating hours: 25,984 h, machine/vehicle number: 125128, travel distance X-axis: 320 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 320 mm, workpiece weight (max.): 550 kg, total height: 2,790 mm, total width: 2,540 mm, total length: 1,910 mm, table width: 880 mm, type of input current: three-phase, table length: 560 mm, table height: 225 mm, workpiece length (max.): 880 mm, workpiece width (max.): 550 mm, workpiece height (max.): 225 mm, year of last overhaul: 2025, In very good condition: Refurbished Charmilles Roboform 2000+ completely refurbished with 16-fold RTC changer. Extensive maintenance according to dealer prescrition performed: all air-valves and tubing replaced, filters replaced, motors refurbished with new bearings and cleaned up, fans replaced, screen replaced. C-axis seals have been replaced and is accurately aligned again. This is a 64A machine. Software and documentation is provided, onsite installation including warranty can be discussed! Optionally floppy drives can be exchanged for USB drives. Tested and fully functional. Can be viewed and tested in working order. Immediately available! Rjdpfx Aew Ad Idjdiju

Year of construction: 2004, condition: ready for operation (used), A CNC die-sinking EDM machine Charmilles without counter is available. Travel path X/Y/Z: 350mm/250mm/300mm, C-axis: 360°, tool positions: 4, quill stroke: 300mm, table dimensions X/Y: 500mm/400mm, max. workpiece weight: 500kg, max. workpiece dimensions X/Y/Z: 780mm/550mm/370mm, surface quality: approx. Ra 0.1µm, max. electrode weight: 50kg, tank usable volume: 160l, total tank volume: 410l. Machine dimensions X/Y/Z: approx. 1900mm/1700mm/2550mm, weight: approx. 250kg. Documentation available. An on-site inspection is possible. Rodpfxsympdds Adiju

Condition: used, Year of construction: 2007, operating hours: 128,688 h, functionality: fully functional, machine/vehicle number: 642672, 128,688 h active time (total time the machine was switched on) 21,821 h operating time (net time in which the machine was actively used) Rsdpfxjym N Nao Adieu

Condition: excellent (used), Year of construction: 2001, operating hours: 27,265 h, functionality: fully functional, Charmilles Roboform 35 with QCRI robot Year of manufacture: 2001 Operating hours: 27,265 X, Y, Z travel: 355 x 255 x 305 mm C-axis with Erowa chuck Erowa chuck on the table Erowa probe Magnet 3 x aluminium Erowa pallets 320 x 320 mm 35 x electrode holders 50 x 50 mm QCRI robot 4 x pallet positions on the table 54 x electrode holder locations Documentation and diskettes Machine powered up for inspection Rsdpfsyh E A Njx Adiou

Condition: ready for operation (used), Year of construction: 2005, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, controller manufacturer: AGIE, number of axes: 3, This 3-axis AGIE Hyperspark 2 Exact with Erowa was manufactured in 2005. It features an X-axis travel of 350 mm, Y-axis travel of 250 mm, and Z-axis travel of 250 mm. The machine is equipped with AGIE VISION 4 Software and includes an EROWA ROBOT MULTI with 60 ITS 148 places and 240 ITS 50 magazine places. If you are looking to get high-quality die-sinking EDM capabilities, consider the AGIE Hyperspark 2 Exact machine we have for sale. Contact us for further details. • EROWA ROBOT MULTI with 60 ITS 148 Places and 240 ITS 50 Magazine Places Rjdpfsy S A Dcjx Adiju
