Plate Bending Machine - 4 Rolls

AKBEND AHS 20/10

Year of construction: 1978, condition: ready for operation (used), A Haeusler CNC large-format 4-roll plate bending machine is available. Number of rolls: 4, Roll width: 3050mm, Max. prebending plate width: 3000mm, Max. prebending plate thickness: 60mm, Max. rolling capacity at max. plate width and 3500mm bending diameter: 70mm, Roll diameter top/bottom/side: 620mm/600mm/500mm, Max. top roll load: 12000kN, Operating speed: 4m/min, Connected load: 132kW, Weight: approx. 85t. Including cone bending device. Documentation available. An on-site inspection is possible. Laedpozka H Aefx Amvjg

Condition: new, functionality: fully functional, Year of construction: 2021, For sale: Brand new, never-used DAVI bending machine. *MAIN FEATURES MCP 18* Ljdpey N Rbwofx Amvsag *1. Type and Capacity* - *3 hydraulically driven rollers*, pyramid configuration - *Shafts Ø 180 mm* → this is the "18" in MCP 18 - *Bending*: round, square, rectangular tubes, angles, flat bars, UPN, IPE, HEA... all b235 profiles *2. Indicative capacities on MCP series* DAVI does not provide the exact MCP 18 datasheet online, but for the equivalent MCP range: Profile Approx capacity MCP 18 Round tube Ø 6" to 8" depending on wall thickness Solid square 80x80 mm to 100x100 mm Angle 120x120x12 mm UPN UPN 200 - 240 IPE flat flange IPE 200 - 240 Actual figures depend on wall thickness and steel grade. The 18 cm Ø shafts make this a mid/high-category machine. For all available options, please refer to the photo in the listing.

Condition: new, sheet length: 2530sheet thickness: 6prebending: 5total power requirements: 5,5weight approx.: 3750messurements (LxWxH): 4250 x 1.200 x 1.250 Ljdpod Ab E Uofx Amveag

Condition: used, Rolling Machine Ljdpfx Amjwf Ndisvjag Brand: JAMMES PROMECAM Type: HC 1310 Maximum thickness: 10 mm Maximum length: 3040 mm Rolling capacity: 1500 mm Upper roller diameter: 300 mm Side roller diameter: 220 mm Working speed: 0 to 7 m/mm Hydraulic control 1 hp motor Hydraulic unit motor: 5.5 kW Weight: 7000 kg Dimensions: 5100 x 1000 x 1000 mm Type: 4-roller rolling machine

Condition: new, sheet width 3100 mm plate thickness 10 mm pre-bending 8 mm upper roll diameter 270 mm lower roll diameter 250 mm side roll diameter 210 mm total power requirement 11 kW Lsdpsyv Nhcsfx Amvjag weight of the machine ca. 7750 kg Overall size 5600x1450x1600 mm

Condition: new, table length 1300 mm table width 800 mm stroke height 1015 mm Ljdpfevn Uzmsx Amvoag weight max. in kg 3000 kg 220 mm connected load frequency 400 V total power requirement 1,5 kW weight of the machine ca. 0,32 t dimensions of the machine ca. 1,3 x 0,8 x 0,23 m The hydraulic lifting tables are electrically driven and operated. Have a contact strip for safe lowering operation. Wide applicability for workshops, assembly departments, loading pits, etc.

Condition: new, Ostas 4-roll plate bending machine 4R OHS 3070 x 320 Hydraulic side roll adjustment 3 digital displays Hydraulic drop-end bearing Hardened rolls Conical bending device Separate control panel Roll length: 3070 mm Top roll diameter: 320 mm Side roll diameter: 240 mm Total motor power: 20 kW Weight: 13,050 kg Dimensions (mm): 5900 x 1850 x 2050 (L x W x H) Bending Performance Data 16 mm at minimum inside diameter (5 x top roll) 12 mm at minimum inside diameter (1.5 x top roll) Pre-bending Performance Data 12 mm at minimum inside diameter (5 x top roll) 10 mm at minimum inside diameter (1.5 x top roll) Ledsxrdxfopfx Amvjag All bending capacities are calculated based on a yield strength of 250 N/mm2 Material (ST 37 – ST 42 structural steel) The pictures shown are for reference only.

Condition: new, functionality: fully functional, Year of construction: 2025, The EVO is the latest innovation in sheet metal processing. It is equipped with numerous innovative and patented features that increase your production capacity and productivity while simultaneously offering the lowest overall operating costs. The high-quality components used in this machine, as well as the latest version of the BENDtronic® control, which is installed as standard on all EVO machines, are particular highlights. HAEUSLER EVO 21015 4-roll round bending machine / roll bending machine Manufacturer: Haeusler Type: EVO 21015 4-roll round bending machine / roll bending machine Origin: Germany / Switzerland Condition: NEW, showroom machine Laodpsxnnf Iefx Amvsg Availability: 12-14 weeks Performance: Working width 2100 mm Round bending capacity 12 mm Pre-bending capacity 9 mm Standard equipment: • Variable oscillation adjustment of the side rolls VSA® • HAEUSLER Hybrid Drive System HHDS® • Movable 21.5" touch control panel including high-end BENDtronic® control • Infinitely adjustable rotation speed between 0 and 8 m/min • Machine prepared for remote maintenance • Electro-mechanical locking system for the rotation of the top roll • Automatic pressure adjustment of the bottom roll • Automatic pressure compensation of the bottom roll cylinder, standard cooling system for ambient temperatures up to 35° C • Automated axis optimization • Automatic shutdown of the hydraulics for the roll position • Ultra-compact design to reduce or even eliminate foundation costs • Safety emergency stop cord Optional equipment: • Two-roll drive for the top and bottom rolls • Taper bending device for bending conically shaped workpieces • Extended cooling system for ambient temperatures up to 45 °C • Upper support for easier bending of large diameters • Side support to assist in bending large diameters • Gas pressure accumulator for calibrating already welded cylinders • BendIT-Office workstation software • Autonomous bending • Machine prepared for quick change of top rolls • Interchangeable top rolls with different diameters for bending shots with small diameters • Hardened rolls if black and stainless material is to be bent • Infeed roller table for easy feeding of sheets into the machine • Centering device for the infeed roller table, for automatic centering of the sheets before bending Not the right machine? As a representative of Haeusler, we can put together and offer you your desired machine according to your needs. Further information on request.

Condition: used, Surface Grinding Machine, Precision Surface Grinder BRAND (Switzerland) Model FS 735 Machine No.: 322 82 Year of manufacture: 1982 Electro-magnetic chuck 700 x 300 mm Grinding length 700 mm Grinding width 300 mm Cross travel max. 340 mm Table longitudinal travel max. 750 mm Distance spindle center to magnet max. 400 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel width 60 mm with single-sided recess in the grinding wheel Grinding wheel bore 127 mm Table longitudinal feed 0 - 30 m/min, stepless Table cross feed per pulse 1 to 10 mm Rapid cross traverse 340 mm in 6 sec Vertical infeed 0.001 - 0.055 mm Vertical rapid traverse 150 mm/min Grinding wheel speed 2500 rpm Grinding wheel surface speed 39 m/s Spindle drive motor power max. 5.7 kW Hydraulic motor power 1.5 kW Power supply 400 Volts, 50 Hz, approx. 7 kVA - Stepless grinding wheel speed adjustment - Automatic depth infeed - Automatic table cross feed, hydraulic and mechanical handwheel for table cross movement - Hydraulic clamping for the cross movement - Hydraulic table longitudinal movement - Hydraulic dressing device - Electromagnetic chuck BRAILLON, Type BJP 700 x 300 mm, overall height 100 mm, continuously adjustable magnetic force - Centralized oil lubrication Lsdpfx Amjn Saf Nsvoag - BEDA band filter system with coolant tank and pump standing beside, L x W x H = 1600 x 650 x 1100 mm - Separate hydraulic unit with electrical cabinet, L x W x H = 1800 x 750 x 1700 mm - Machine equipped with one grinding wheel Ø 295 mm, width 50 mm - Two additional grinding wheel holders with grinding wheels (internal diameter 127 mm) - One grinding wheel puller Required space for surface grinder L x W x H 2200 x 1800 x 2350 mm Weight of surface grinder approx. 3100 kg Weight of hydraulic unit 500 kg Weight of band filter system 200 kg Space requirement on pallet 2700 x 2200 x 2500 mm Total weight with pallet approx. 4000 kg Good condition

Condition: new, Year of construction: 2025, All-round sheet fiber laser metal cutting machine Equipped with automatic functions of nozzle changing and one-click processing, P-Series is competent for all cutting demands. Laedpjhwhfxjfx Amveg Flake graphite in the cutting machine bed improves greatly the shock absorption and wear resistance, and residual stress almost disappears after age hardening, therefore, precision and lifetime of the equipment are improved, and costs saved. The special fiber laser nozzle and cutting process ensure faster carbon steel oxygen cutting, more gas-saving low-pressure stainless steel nitrogen cutting, and better-quality carbon steel air cutting. Fiber laser heads are able to detect jutting obstacles to effectively reduce the damage rate and save the maintenance cost of a laser cutter. The fully closed-loop control adjusts according to feedback to ensure that the actual motion position is consistent with the theoretical input value. With One-click Processing, one laser cutter is able to process multiple sheets in batches with a one-off setup, achieving batch processing. Condition: New Laser Type: Fiber Laser Laser Power: 1500W - 30000W Cutting Area: 3048*1524mm - 6100*2500mm Cutting Speed: 0-169m/min Positioning accuracy: ±0.03mm - ±0.05mm Repositioning accuracy: ±0.02mm - ±0.03mm Graphic Format Supported: AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT CNC or Not: Yes Cooling Mode: WATER COOLING
