Upright Drilling Machine

ALZMETALL AB 40 ST

Condition: ready for operation (used), Bench drill / ALZMETALL AB 40 ST -Drilling capacity in steel approx. 50mm -Threading capacity max. M30 -Tool holder MK 4 -Spindle stroke approx. 160mm -Automatic feed rate 0.1-0.2-0.3-0.4mm/rev -Overhang approx. 300mm -Continuously variable speed adjustment (variator) -Right/left rotation -Height-adjustable work table via hand crank -Work table size approx. 740x460mm -Motor power approx. 3 kW Cedpfxszm Tb Es Ap Asha Dimensions: L x W x H 1.2 x 0.8 x 2.2 meters / Weight approx. 1200 kg Errors and omissions excepted.

Condition: used, Bench drill, gear drill ALZMETALL Type AB 40 ST Production drill Manufacturer No. 750 Year of manufacture 1994 Drilling capacity 40 mm Spindle mount MK 4 - short quill Overhang 325 mm Quill stroke 200 mm Table size 740 x 460 mm Height adjustment of drill head 700 mm Chedpfxeza Hzgo Ap Aea Distance spindle-table max. 1015 mm Spindle speed 56 - 2500 rpm 12 gear stages Automatic feed 0.15 - 0.2 - 0.3 - 0.36 mm/rev Motor power 4 kW Mains connection 380 Volt, 50 Hz - Spindle speed via 12 gear stages - Drilling and threading device with right and left rotation - Electric foot switch for switching the direction of rotation to left for thread cutting interruption - Rapid traverse via hydraulic quill movement - Semi-automatic operating sequence: rapid traverse - working feed - rapid return - Drill head height adjustment via hand crank - Table height adjustment via hand crank (table height from 740 to 1170 mm) - Coolant system - Control cabinet on the back of the machine - Mounted on a steel plate (1300 x 750 x 15 mm) with machine feet - Quick-change drill chuck METABO 3 to 16 mm - Operating manual and electrical diagram Overall height with drill head at the top 2750 mm Space requirement L x W x H 1400 x 850 x 2300 mm Weight 1250 kg Good condition
