AMUT EA90/24 SINGLE SCREW EXTRUDER

AMUT RALDI

Condition: new, Year of construction: 2023, functionality: fully functional, Drying system / dryer suitable for various materials such as powder, granulate etc. Iodpfx Ajqu R Nasdketg - Control for temperature regulation This machine is connected and ready for testing in our machine hall.

Condition: used, Year of construction: 1994, operating hours: 62,058 h, functionality: limited functionality, machine/vehicle number: 099314, bale width: 770 mm, bale height: 520 mm, Manufacturer: COMDEC - PAAL Model: LV2020PFT Serial number: 099314 Year of manufacture: 1994 Maximum capacity: 25,000 kg/h Iedpfxet Ucqfe Adkotg Bale discharge dimensions: 77 cm x 52 cm The press was in operation until the production line was shut down.

Condition: ready for operation (used), Circumferential speed: 80m/s, an on-site inspection is possible. Iodpfxjrp E Nno Adkotg

Condition: used, Year of construction: 2005, operating hours: 62,235 h, functionality: fully functional, screw diameter: 70 mm, overall weight: 25,100 kg, The ENGEL Victory 2050/350 is a tie-bar-less injection molding machine manufactured in 2005. With a machine weight of 25,100 kg, it offers a maximum shot volume of 1,145 cm³ and a maximum injection pressure of 1,482 bar. The clamping force is 350 tons and the screw diameter is 70 mm. Technical data at a glance: - Year of construction: 2005 - Machine weight: 25,100 kg - Maximum shot volume: 1,145 cm³ - Maximum injection pressure: 1,482 bar - Clamping force: 350 t - Screw diameter: 70 mm - Tool installation height: 350–1,000 mm - Clamping plate size: max. 1,200 x 1,100 mm - Ejector stroke: max. 250 mm - Control system: ENGEL - Total operating hours: 62,235 h - Additional equipment: - MORETTO Hopper Loader R10 C52 dosing device - ENGEL ERC linear handling system - Longitudinal structure - Removal cell with machine housing - Separating cardboard feeder - Two-stage roller conveyor The tie-bar-less design of the ENGEL Victory series enables free access to the tool area, which allows the use of larger tools on smaller machines, thus increasing efficiency. This design also offers advantages in automation, as robots and peripherals can be more easily integrated. The machine is equipped with the ENGEL control system, which is known for its intuitive operation and precise process control. The servo-hydraulic technology ensures energy-efficient operation and reduces the need for cooling water. In addition, the machine has a MORETTO dosing device and an ENGEL linear handling system, which supports production automation and increases overall productivity. Iodovxzw Nepfx Adketg With a total of 62,235 operating hours, the machine is in a used but functional condition.

Condition: new, Year of construction: 2016, operating hours: 9 h, functionality: fully functional, BMCtouch Integrated Automation System Iedpox Sbc Rofx Adkjtg The control system, constructed in modular design, includes the following components: - PLC in industrial-standard design for machine control - Industrial PC for visualization and data management - Swivel-type operating and display panel with 19" TFT touch screen Performance Features: - User interface and functionality as per previous BMCtouch systems - Temperature control with self-tuning function - Pre-heating and start-up program - Prepared for data transfer to haul-offs with BMCsmart control systems - Operation of haul-off and saw from extruder terminal - CANopen Interface DS420 V2.0 - Flexible process display with individually configurable summary pages and customizable background - Configurable alarm management and alarm history - Trend data acquisition and presentation - Order management/administration - Configurable access authorization - Online assistance - Suitable for independent multi-user operation - Additional memory for history trends - Network capability - Modem Integration of Central Air Supply Co-extruder, BCE 1-30-25D - Stand-alone machine - Synchronization with main extruder via CANopen, DSP 420 V2.0 - AC drive incl. gearbox - Nitrided screws - BMCeco operator terminal - Product of battenfeld-cincinnati China branch Extruder, solEX 75-40 i Designed for pipe extrusion Technical Data: - Screw diameter: 75 mm - Effective screw length: 40xD - Drive power: 300 kW - Barrel heating zones: 5 pcs. - Barrel cooling zones: 5 pcs. - Total installed power, max.: 347.37 kVA Die heating zone incl. thermocouple (6 kW, 230 V) (BMCtouch control) Extrusion Die, helix 500 VSI-TZ Designed for the extrusion of PO pipes - Two-step distributor consisting of smoothing thread and compact lattice basket - Base die and die set made of tempered steel - Material flow surfaces are polished - Pipe O.D.: 90 - 500 mm - Number of heating zones: 17 Co-extrusion ring for 4 color stripes Calibrating sleeve, type 6 For PO pipes vacStream 500-6 No. 1 Designed for calibrating and cooling of pipes - Closed stainless steel tank with welded feet - Tank on rollers with height and lateral adjustment - Rust-proof hinged lids - Central water inlet and outlet - Pipework made from rust-proof materials - Manual reversible flow filter unit with bypass - Mechanical vacuum control - Temperature display Technical Data: - Pipe diameter range: 90 - 500 mm - Number of solid taper nozzles: 162 pcs. - Number of spray rods: 6 pcs. - Max. vacuum: 0.7 bar - Length of vacuum chamber: 5500 mm - Total length: 5900 mm vacStream 500-6 No. 2 Designed for calibrating and cooling of pipes coolStream 500-6 4 For pipe cooling - Closed stainless steel tank - Base frame with height-adjustable feet - Rust-proof, hinged lid - Central water inlet and outlet - Pipework made from rust-proof materials - Manual reversible flow filter unit with bypass - Temperature display - Spray rods made of PVC - Solid taper nozzles with bayonet lock - Visual monitoring of pumps - Drip trays at inlet and outlet - Water circulation pump pullStream R_ 500-6 E Designed for pipe haul-off cutStream RTAplus 500 For chipless cutting of PO pipes

Year of construction: 2023, condition: new, Aluminum angle conveyor belt with substructure including adjustable feet and machine feet to level unevenness horizontal area: 3,750mm rising area: 3,200mm angle of inclination at the bend 45° total conveyor belt length measured on the ground: 6,000mm discharge height: 2,500mm horizontal height: 250mm design: aluminum construction - double profile reinforced 90x45mm drive roller + deflection roller S235 steel welded and machined Ø100x520mm crowned, shaft fixed with clamping bearings. Drive: slip-on gear motor 0.55KW, speed 0.3m/sec Connection 230/400V, 50Hz protection class IP54 Drive ready for connection to motor terminal box (commissioning must be carried out by a qualified electrician) PVC conveyor belt DM 10/2 0+005 PVC including corrugated edges PVC green Conveyor belt width: 500mm 2 corrugated edges 40 high, 35mm wide, high frequency welded 46 T-40 studs, approx. 300mm pitch Belt material: 2-ply, particularly stable across the belt In the bend area, the belt is guided on both sides with 3 hold-down rollers each. The belt is designed with a 70mm edge-free zone on both sides. Due to the corrugated edge on both sides, the usable width of the conveyor belt is reduced: Usable width: 290mm, results as follows: (top view) transverse arrangement 70+35+290+35+70mm Our core competence lies in supplying the customer with exactly what he really needs. Together with our customers, we work out customer-specific, individual solutions and supply corresponding systems from our own production. Feel free to contact us by phone to find a suitable solution for your application. Itsdpfxjht Uzas Adkog Conveyor belt, conveyor belt system, discharge belts, belt conveyor, magnetic separator, overbelt magnetic separator, recycling, wood chips, plastic, metal-free metal detection, neodymium, overbelt magnet, magnetic belt separator

Condition: excellent (used), functionality: fully functional, Manufacturer: "Alpina" Cutting mill, suitable for secondary shredding. Drive: 15 kW Fully functional, with control panel. - Optional with blower and extraction to cyclone. Matching conveyor belt in stock. Iodpfx Adotw Sf Sekjtg Machine testing possible upon agreement.

Year of construction: 2026, condition: new, Description: The FR8 flotation tank is designed for density-based separation of plastics in recycling washing lines. The machine separates floating materials from sinking contaminants, improving material purity before further washing, drying, or granulation processes. Suitable for continuous industrial operation 24/7. Materials: PE, PP, HDPE, LDPE, plastic flakes, films Features: Effective density separation (float/sink process) Itodpsyh Hx Ejfx Adkjg Heavy-duty industrial construction Continuous operation for recycling lines Easy cleaning and service access Ready for integration with pre-washers, friction washers, and dryers 📩 Available in customized configurations. Contact us for details.

Condition: good (used), Year of construction: 2010, operating hours: 3,641 h, functionality: fully functional, pressing force: 36 t, filling opening width: 1,100 mm, filling opening length: 1,080 mm, bale width: 1,100 mm, bale height: 750 mm, power: 15 kW (20.39 HP), volume flow: 90 m³/h, Technical data baler: Iedpfx Adeu Thh Eekotg Manufacturer Presto GmbH & Co. KG Typ CC 36 M Year of construction 2010 Hours of operation 3,641 h Press power main press 36 t Specific press capacity 467 N/cm² Feed channel 1.080 x 1100 mm (l x w) Cycle time 34 sec. Capacity per cycle time 0,85 m³ Theoretic throughput rate 90 m³/h Throughput rate under operating conditions with a material bulk density of 35 kg/m³ approx. 51 m³/hour Bale size 1100 x 750 mm (w x h), length variable Driving motor 15 kW Tying 4-fold vertical, semi-automatic, with polyester synthetic yarn Throughput rate at a bulk weight of 35 kg/cbm 1,8 to/h bulk weight of 60 kg/cbm 2,5 to/h bulk weight of 100 kg/cbm 3,1 to/h Transport dimensions only baler 4.200 x 1.640 x 2.200 mm Machine weight baler approx. 4 to Comments: The press was checked for function in our workshop, then stored and is therefore available at short notice. The machine documentation (operating instructions, CE, electrical and hydraulic circuit diagram) is available. Inspections are possible after agreement. We will not assume liability for the given technical data and possible errors.

Condition: like new (used), Year of construction: 2019, operating hours: 39 h, functionality: fully functional, machine/vehicle number: MZ-7321/19 / 11024, total height: 2,198 mm, total width: 1,648 mm, total length: 3,500 mm, overall weight: 3,500 kg, rotor diameter: 400 mm, rotor width: 850 mm, type of input current: AC, input voltage: 400 V, rotational speed (max.): 100 rpm, power: 30 kW (40.79 HP), As-new single-shaft shredder / size reduction system with minor signs of use. Used solely for testing purposes. The rotor shaft is equipped with a heavy-duty wear protection. Cassette system for rotor knives, 34 x 34 mm. Electric motor 30 kW, total installed power 37 kW, hydraulic power 3.75 kW, 400 V, 3-phase. Additional new rotor and stator knives included as spare parts. German operating manual. Three-part, adjustable stator knives. Hopper lockable, perforated screen 40 mm. The machine can be demonstrated under power. No warranty after purchase. Free loading from factory premises – Raesfeld. Detailed photos available on request. Subject to prior sale. Prices are net prices. Itsdpfsy E S S Aox Adkjg
