Flash Pasteuriser

Apparatebau Nordhausen

Condition: used, tank capacity: 1,850 l, GENERAL INFORMATION Equipment: Crane lugs Design: vertical Speed: 300 rpm Internal diameter: 1,178 mm Total height: 3,350 mm Heating/Cooling: available Insulation: available Power: 1.5 kW Max. permissible operating temperature: 100 °C Max. permissible operating overpressure: 6.0 bar Max. overpressure: 4.0 bar Shaft seal: Mechanical seal with thermosyphon vessel Agitator: Cross-blade agitator Support type: Feet Location: Bremen Technical documentation: Drawing, TÜV papers Cylinder temperature control: Double jacket Nameplate: Vacuum: 1.0 bar Volume: 1,850 liters Double jacket volume: 100.0 liters Product contact material: V2A 1.4301 (AISI304) Condition: used Cylindrical height: 1,500 mm VESSEL Max. permissible operating temperature: 100 °C Bottoms: Dished ends Number of feet: 3 HEATING/COOLING JACKET Bottom temperature control: Double jacket INSULATION Insulation jacket: hermetically welded Itedpfx Aexqahgehuob EQUIPMENT Manway / Dome: in top head (DN 400) Outlet: Clamp Note: Pressure marks on the insulation jacket Outlet: 40 mm AGITATOR 1 Agitator manufacturer: Stelzer Voltage: 230/400 volts Agitator arrangement: eccentric in the top head

Condition: used, tank capacity: 5,500 l, GENERAL Itsdpfoxqazaox Ahuob Equipment: Crane lugs Design: vertical Remarks: Dents in the insulation jacket possible; the manufacturing and documentation drawings are available from the manufacturer and can be purchased separately there Speed: 429 rpm Outer diameter: 1,890 mm Inner diameter: 1,680 mm Total height: 3,500 mm Heating/cooling: available Insulation: available Power: 2.2 kW Max. permitted operating temperature: 140 °C Max. permitted operating overpressure: 2.5 bar Max. overpressure: 2.5 bar Agitator: Propeller Base type: Height-adjustable feet Location: Bremen Cylinder temperature control: Double jacket Nameplate: Vacuum: 1.0 bar Volume: 5,500 liters Double jacket volume: 154.0 liters Double jacket material: V2A 1.4301 (AISI 304) Product-contact material: V4A 1.4571 (AISI 316) Condition: used Last application: brine TANK Max. permitted operating temperature: 140 °C Number of feet: 3 pcs HEATING/COOLING JACKET Max. permitted vacuum: 1.0 bar Base temperature control: Double jacket INSULATION Insulation jacket: hermetically welded Insulation jacket material: stainless steel EQUIPMENT Manhole / dome: on top head (DN 400) Note: slight residues present, outlet nozzle cut off Outlet: 38 mm MATERIAL SPECIFICATION Feet material: stainless steel AGITATOR 1 Agitator manufacturer: PRG Voltage: 230/400 Volt Agitator arrangement: bottom-mounted

Year of construction: 2013, condition: used, Additional title: trub removal Capacity: 182 hl Volume net: 150 hl Volume gross: 182 hl Material: 1.4301 Position: outdoor Isdpfexbn S Iex Ahuotb Features: insulation (100 mm mineral wool)

Year of construction: 2010, condition: used, Additional title: 10 hl brewing system with grist mill, wort cooling and hot water tank Cast wort capacity: 1000 l Current: 17 A Itjdpfx Aev Av S Njhueb Voltage: 400 V Frequency: 50 Hz Operation / Control: Simatic Multi-Panel, Siemens CPU Features: Grist mill, mash tun, lauter tun, wort kettle, whirlpool, plate heat exchanger, wort aeration, hot water tank, lauter pump, wort cooling pump, hot wort pump, Pipework, valves, accessories, controls
