Injection molding machine

ARBURG

Condition: excellent (used), Year of construction: 2010, clamping force: 600 kN, Equipment: documentation/manual, ARBURG ALLROUNDER 370 S 600-170 Year: 2010 CLAMPING UNIT Clamping force: 600 kN / 60 t Distance between tie bars H: 370 mm Distance between tie bars V: 370 mm Mould platen dimensions: 510 × 510 mm* Mould opening stroke: 400 mm* Minimum mould height: 200 mm* Maximum daylight: 600 mm* Maximum movable mould weight: 360 kg* Ejector force: 30 kN* Ejector stroke: 125 mm* INJECTION UNIT Injection unit: 170 (model designation) Screw diameter: 20 mm Shot volume: To be confirmed Shot weight (PS): To be confirmed Injection pressure: To be confirmed Screw stroke: To be confirmed Screw L/D ratio: To be confirmed HYDRAULIC SYSTEM Drive: Hydraulic Hydraulic core pullers: 1× CONTROL & EQUIPMENT Hot runner zones: 6× Robot interface: NO GENERAL INFORMATION Blodpfezn I H Esx Alzsp Machine type: Horizontal Operating hours: 60,700 h Year of manufacture: 2010

Condition: used, Year of construction: 2006, Arburg 370 U 600-290 (2006) CLAMPING UNIT Clamping force: 600 kN Closing force: 38 kN Opening force / increased: 24 / 160 kN Opening stroke: 400 mm Mould height min.: 200 mm Daylight max.: 600 mm Distance between tie bars: 370 × 370 mm Platen size: 510 × 510 mm Weight of mov. mould half: 360 kg Ejector force: 125 kN Ejector stroke: 125 mm ⚙️ HYDRAULICS Drive power: 15 kW Total connected load: 23,9 kW 💉 INJECTION UNIT — ø 35 mm Screw stroke max.: 150 mm Effective screw length L/D: 20 Injection volume max.: 132 cm³ Shot weight max.: 20,5 g PS Material throughput max.: 10,5 kg/h PS Injection pressure max.: 2000 bar Injection flow max.: 140 cm³/s Injection flow with accumulator: 430 cm³/s Back pressure max.: 350 / 200 bar Screw speed max.: 54 m/min Screw torque max.: 380 Nm Nozzle contact force: 60 kN Nozzle retraction stroke: 240 mm Heating zones / power: 4 zóny / 5,8 kW Bljdpe Ahpmmefx Alzop Nozzle heating: 0,6 kW Hopper capacity: 50 l 📦 DIMENSIONS & WEIGHT Oil capacity: 135 l Net weight: 3300 kg Electrical connection: 80 A

Condition: used, Year of construction: 2017, overall weight: 8,850 kg, Model 570 A 2000-400 Year of manufacture: 03/2017 Net weight according to the technical data sheet for the basic configuration: 8,850 kg Blodo Ahkh Aepfx Alzep with the following peripherals: - KUKA robot KR 16-2, year of manufacture 2017, with control panel - KUKA robot KR 10 R1100 sixx, year of manufacture 2017, with control panel - FARRAGTECH Card 40S compressed air granulator dryer - NZME temperature control unit station - Conveyor belt - Machine stairs - Machine documentation as shown - Enclosure as shown, without any further accessories or items depicted in the background, not tested for function or completeness This ARBURG 570 A 2000-400 injection molding machine will be auctioned online in our industrial auction / machine auction "Aumovio Germany GmbH - Step 2 - Injection molding machines, temperature control units, storage racks and various". You can find this and many other items from the areas of temperature control units, operational equipment and storage technology on our platform.

Condition: used, Year of construction: 2014, clamping force: 1,000 kN, screw diameter: 35 mm, clearance between the columns: 420 mm, displacement volume: 144 cm³, injection pressure: 2,000 bar, injection weight: 132 g, mold height (min.): 250 mm, plate length: 570 mm, plate width: 570 mm, total length: 4,300 mm, total width: 1,700 mm, overall weight: 3,640 kg, Arburg 420C-1000-290 injection molding machine (261) with sorting flap Number: 261 Availability: in stock Year of production: 2014 Producer: Arburg Injection molding machine condition: used Screw diameter [mm]: 35 Injection weight [g]: 132 Injection pressure [bar]: 2000 Closing force [kN]: 1000 Column spacing [mm]: 420 x 420 Plate size [mm]: 570×570 Min. mold height [mm]: Blsdpfe Ahhfuex Alzsp 250 Control type: Selogica Tongue: English, German Installed power [kW]: 21.4 Working hours [h]: 59000(new pump 13000) Weight [kg]: 3640 Dimensions [mm]: 4300 x 1700 Feed hopper: NO Robot socket: Yes Core string: 1x Air valve: 1x Control of heating for molds: 3x

Condition: ready for operation (used), Year of construction: 2007, clamping force: 5,000 kN, screw diameter: 90 mm, overall weight: 26,400 kg, This 3-axis Arburg Allrounder 920S 5000-3200 hydraulic injection moulding machine was manufactured in 2007. It features a maximum clamping force of 5,000 kN, a screw diameter range of 70 to 90 mm, and a maximum shot weight up to 1,860 g. Consider the opportunity to buy this Arburg Allrounder 920S hydraulic injection moulding machine. Contact us for more information about this machine. • Maximum mold opening force: 150 kN • Enhanced opening force: 100 / 1,000 kN • Opening stroke: up to 900 mm • Mold height: min. 400 – max. 1,050 mm • Distance between platens: 1,300 – 1,950 mm • Tie-bar spacing (H × V): 920 × 920 mm • Platen size (W × H): 1,280 × 1,280 mm • Movable platen weight (half): max. 8,000 kg • Ejector force: max. 800 kN • Ejector stroke: max. 250 mm Hydraulics / Drive • Hydraulic pump motor power: 75 kW • Dry cycle time (opening stroke 5): 4.5–6.44 s • Installed total power: 96 kW • Color: Structural light gray / mint green / red-yellow • Control cabinet safety standard: DIN EN 60204 • Socket combination: 1 × Schuko, 1 × CEE Injection Unit • Screw diameters: 70 / 80 / 90 mm • Effective screw length (L/D): 23 / 20 / 18 • Maximum shot volume: 1,232 / 1,608 / 2,036 cm³ • Maximum shot weight (PS): 1,125 / 1,469 / 1,860 g • Plasticizing capacity (PS): 185 / 215 / 250 kg/h Bledpfjydnigsx Alzjp • Maximum injection pressure: 2,500 / 2,000 / 1,580 bar • Injection rate: • Without accumulator: 290 / 380 / 482 cm³/s • With accumulator: 1,188 / 1,552 / 1,964 cm³/s • Holding pressure: max. 350 / 200 bar • Screw speed: 47 / 54 / 61 rpm • Screw torque: 3,500 Nm • Nozzle contact force: max. 110 kN • Nozzle stroke: max. 675 mm • Installed barrel heating power: 6 × 5,500 + 4,300 W • Installed nozzle heating power: 1,100 W • Oil fill volume: 590 liters • Motor + heating fuse rating: 200 A • Motor fuse: 125125 A • Heating fuse: 63 A

Condition: refurbished (used), Arburg, Thermonic heating controller, Arburg Allrounder Blodpfx Asyvp Upjlzep 4 units, as new condition. Stored as spare parts in maintenance. Price per unit: €99

Condition: used, Year of construction: 2006, Arburg 370U 600-290 (2006) 📐 CLAMPING UNIT Clamping force: 600 kN Closing force: 38 kN Opening force / increased: 24 / 160 kN Opening stroke: 400 mm Mould height min.: 200 mm Daylight max.: 600 mm Distance between tie bars: 370 × 370 mm Platen size: 510 × 510 mm Weight of mov. mould half: 360 kg Ejector force: 125 kN Ejector stroke: 125 mm ⚙️ HYDRAULICS Drive power: 15 kW Total connected load: 23,9 kW 💉 INJECTION UNIT — ø 35 mm Screw stroke max.: 150 mm Effective screw length L/D: 20 Injection volume max.: 132 cm³ Shot weight max.: 20,5 g PS Material throughput max.: 10,5 kg/h PS Injection pressure max.: 2000 bar Injection flow max.: 140 cm³/s Injection flow with accumulator: 430 cm³/s Back pressure max.: 350 / 200 bar Screw speed max.: 54 m/min Bjde Ahgdqjpfx Alzslp Screw torque max.: 380 Nm Nozzle contact force: 60 kN Nozzle retraction stroke: 240 mm Heating zones / power: 4 zóny / 5,8 kW Nozzle heating: 0,6 kW Hopper capacity: 50 l 📦 DIMENSIONS & WEIGHT Oil capacity: 135 l Net weight: 3300 kg Electrical connection: 80 A

Condition: good (used), Year of construction: 2002, operating hours: 82,515 h, Arburg 420S-600-150 Year of manufacture: 2002 Clamping force: 60 tons Bljdpfx Ao Ag Tc Hjlzjp Tie bar spacing: 42 x 42 Screw diameter: 35 mm Injection volume: 144 cm3 Mounting height: 200-250 mm Operating hours: 82,515 Arburg robot

Condition: good (used), Year of construction: 2004, Arburg 570C-200-350/150 Clamping force: 200 tons Year of manufacture: 2004 Blsdo Ag S R Rspfx Alzep Tie bar spacing: 57 x 57 mm Overall height: 300 mm Screw diameter: 45 mm + 35 mm Two-component machine

Condition: excellent (used), Year of construction: 2014, ARBURG A 370 S 700-290 U-Version (S&P 3804) Manufacture year: 2014 Operating hours: 41,257 Stunden Screw: 40 mm Bledpfs Af Rykjx Alzjp Injection pressure: 1530 bar Stroke volume: 188 cm³ Clamping Force: 70 t Tie bar distance: 370 x 370 mm Mould installation height min.: 200 mm Plate distance max.: 600 mm Dimensions: 3700 x 1400 x 2000 mm Eeight: 3580 kg Connected load: 15 kW U-Version = clamping and injectionside could be turned into vertical and horizontal position, 1 x corepuller, 6 x hotrunner, Airvalve, Interface colorizing, 23.761 h automatic and 17.496 h manual... Price: on request contact: Mr. Ralf Schulz
