Decoiling/levelling/feeding line 13 t

ARKU

Condition: used, Year of construction: 1993, material width 350 mm coil weight 2,0 t coil internal diameter 470 - 530 mm coil external diameter 1500 mm power requirement 1,0 kW weight 1,5 t dimensions (WxDxH) 1,3 x 1,6 x 1,9 m motoric driven, with manual expansion as is where is, WITHOUT putting into operation Iedpfx Aevuuapshusht Price for commissioning (in given condition) on request

Condition: used, Year of construction: 1996, Coil weight 3000 kg, belt width max. 900 mm, Iodjtxpdbopfx Ahuoht

Condition: used, Year of construction: 1982, material width 250 mm material thickness 0,4 - 5,0 mm no. of straightening rolls 9 straightening roll diameter 60 mm speed 3 - 15 m/min material thickness at 250 mm material width 3,5 mm material thickness at 100 mm material width 5,0 mm power requirement 1,8 kW weight 0,9 t dimensions (LxWxH) 1,45 x 1,4 x 1,55 m with infinitely variable drive, centralized adjustment of the straightening rolls, indication via dial gauges, support of the levelling rolls, coil loop control via proximity switch material thickness 3,5 mm at material width 250 mm material thickness 5,0 mm at material width 100 mm can be inspected in running condition in our warehouse Ihsdpfxjvuk Nyo Ahuot

Condition: excellent (used), Year of construction: 1995, Decoiler Max. width 350 mm Clamping area coil internal 470 - 530 mm Coil diameter 1500 mm Work load 2000 Kg Straigtner Width 350 mm Roll diameter 30 mm Number off rolls 9 units In feed rolls 2 units Ihjdpfxex Sx Spj Ahuet In feed roll diameter 90 mm Working speed 40 M/Min Max. thickness 6 mm at 240 N/mm2 Max. Thickness 5 mm at 400 N/mm2 Length:3200mm Width:1500mm Height:2200mm Weight:3700kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 1992, Decoiler Max. width 350 mm Clamping area coil internal mm Coil diameter 1500 mm Isdpsuqm Dnefx Ahuoht Work load 1000 Kg Straigtner Width 250 mm Roll diameter 30 mm Number off rolls 21 units Working speed 40 M/Min Max. thickness 6 mm at 240 N/mm2 Max. Thickness 5 mm at 400 N/mm2 Length: 3200 mm Width: 2000 mm Height: 2100 mm

Condition: used, Year of construction: 2007, machine/vehicle number: 001669, Lg 33121 Single side decoiler ARKU AH 3000/ST-M year of manufacture 1995 belt width max. 600 mm load capacity max. 3.000 kg coil outer diameter max. 1.800 mm Spreading hydraulic Pressing arm hydraulic Decoiler with auxiliary drive and brake coiler chair fixed + reel traversing device with: Ihodpfxjhigmbj Ahuet Lg 33221 High performance belt leveler LORENZ BRM 50/620.9 year of manufacture 2007 Machine no. 001669 passage width max. 620 mm number of straightening rolls 9 Straightening roll diameter 50 mm Material density 0.7 to 6.0 mm Straightening rolls supported several times against deflection All rolls driven by transfer gearboxes and cardan shafts. cardan shafts. Used, in as-is condition from stock, available immediately. On request with overhaul. Delivery time by agreement. Further data shortly or on request.

Condition: used, Year of construction: 2006, machine/vehicle number: M 91317, Decoiler Coil weight: 5 ton Material width: 80 - 500 mm Coil exterior diameter: 1800 mm Expansion range: 508 mm Speed: 50 m / min Leveller / Straightener Material width : 50 - 500 mm Ihodpfxsuqd Ude Ahuet Number of levelling rolls: 9 pcs. Diameter of the levelling rolls: 65 mm Number of pull out rolls: 2 pcs. Diameter of the pull out rolls: 150 mm Material thickness: 1 - 8 mm Feeding speed: 50 m / min Feeding length: 0,1 - 9999,9 mm Standard configuration Coil loading unitStroke 500 mm Load capacity 5000 kg Material width max. 500 mm

Condition: used, Year of construction: 1985, Decoiler Decoiler with arm: 1,5 ton Material width: 350 mm Coil exterior diameter: 1.200 mm Expansion range: 370 - 430 mm Speed: 0 - 20 m / min Leveller / Straightener Material width : 250 mm Number of levelling rolls: 9 pcs. Diameter of the levelling rolls: 30 mm Material thickness: 0,5 - 6 mm Cross section: 1.200 mm Feeding speed: 20 m / min Required power: 18 kW Iedpoxdl Niefx Ahueht Standard configuration - Pneumatic clamp roller- Manual disc brake

Year of construction: 1994, condition: used, decoiler - expansion mandrel with coil lifter strip width: max. 650 mm strip thickness: max. 3 mm coil weight: 2 t Ihjdebh S Dpopfx Ahuot mandrel Ø: 406/508/610 mm

Condition: used, Year of construction: 1993, Price: On request Coil feed line system, straightener, decoiler Manufacturer: ARKU Year: 1993 Decoiler Type: AH 5000/500/MSG-4Q Capacity: 5000kg Working width: 50-500mm Speed: 50 m/min Max coil-diameter: 1800mm Isdpfx Ahswng Ukeujht Straightener Type: RM 3060.4/9 Number of rolls: 9 Diameter rolls: 30 Capacity: 0,5-6mm Working width: 50-600mm Speed: 50 m/min Needs new PLC (controller in cabinet). Is taken by previous owner for programm. - Year: 1993 - Documentation available: No - CE certificate present: No Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Year of construction: 1975, 13 stations shaft Ø: 50,4 mm strip width: 500 mm strip thickness: 1,5 mm Iedpfx Ahobif E Eoujht
