Bed Type Milling Machine - Universal

BÖHNKE FU 71.2 CNC

Condition: ready for operation (used), total height: 3,900 mm, total width: 2,900 mm, total length: 8,000 mm, controller manufacturer: Heidenhain, empty load weight: 13,000 kg, Type: TMML6-centrum Maximale afstand van kolom tot midden van spindel: 1210 mm (diepte van de kiel) Gereedschapswisselaar met 30 posities Spaantransportband Kan achteraf worden uitgerust met nieuwe Heidenhain-besturing Originele tafel kan opnieuw worden gebruikt of een T-gleuf vloerplaat om hogere werkstukken te kunnen bewerken Longitudinal travel X-axe: 3023 mm Crosstravel Y -axe: 800 mm Ihjdpfx Aov St Efoacsu Travel Z-axe (Height): 1528 mm Dimensions clamping space - table: 4200 x 1000 mm Max Height of workpiece: 2000 mm Power on spindle: 20 kW Admission in millingheadspindle (ISO): ISO 50 Max speedrange: 50 > 1980 rpm

Year of construction: 1995, condition: ready for operation (used), A CNC rigid board milling and drilling center Bimatec Soraluce is available. Travel X/Y/Z: 2500mm/900mm/1600mm, speed: 2000rpm, spindle mount: ISO40/M16, tool positions: 30, transport dimensions X/Y/Z: approx. 5300mm/3450mm/3500mm, weight: approx. 13500kg, control: Heidenhain CNC 415, operating hours: 31507h. Including fixed table, movable stand, automatically indexing milling head, manual measuring probe, coolant device and filter system. Documentation available. On-site inspection is possible. Ijdpfsu T Rgwox Aacjhu

Condition: used, Year of construction: 2020, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, RepairFIT by Dornhöfer The Difference. Including installation & commissioning! TECHNICAL MAIN DATA Year of manufacture: 2020 Capacities / Travel distances: Longitudinal (X): 3,000 mm Vertical (Y): 1,500 mm Ihedpfxeygiwqo Aacju Transverse (Z): 1,500 mm Clamping area NC rotary table: Indexing plate: 2,400 x 1,900 mm Max. load capacity (with centrical load): 10,000 kg Positioning accuracy arc/sec ±2.5” Max. swing diameter: approx. 2,900 mm Paintwork: RAL 7024 graphite grey RAL 7038 agate grey Tool holder: DIN 69871 AD (ISO50) Big Plus Pull stud: DIN 69872 Type A Main spindle drive: Motor / manufacturer main spindle drive Heidenhain Max. drive power: 32 kW from 376 rpm Max. torque: 1,085 Nm (constant up to 376 rpm) Speed control/gearbox: 3-stage (oil-cooled), automatic gear shifting Spindle speeds: 6,000 rpm: low range rpm 0–738 medium range rpm 739–1,842 high range rpm 1,843–6,000 Axis drive / axis feed: Axis motors: Manufacturer Heidenhain (digital drives) Rapid traverse max.: X, Y, and Z axis 25,000 mm/min Max. working feed: X, Y, and Z axis 15,000 mm/min Max. mean acceleration: 2 m/s² Max. feed force: X, Y, and Z axis 26,000 N Axis drive systems: X-axis (longitudinal) preloaded ball screw Ø 63 x 40 Z-axis (vertical) preloaded ball screw Ø 63 x 20 Y-axis (transverse) preloaded ball screw Ø 50 x 20 Guideway systems: X-axis (longitudinal) 6 pcs Type: INA RUE 55 EL Z-axis (vertical) 4 pcs Type: INA RUE 65 EL Y-axis (transverse) 8 pcs Type: INE RUE 55 E-HL plus additional damping unit Clamping table / Table surface: T-slot size 10x: 22 H12 mm Reference slot, center 1x: 22 H8 mm T-slot spacing: 150 mm (pitch of outer slots 1,800 mm) Weight: Weight RT3000 approx. 32,000 kg Connected load: approx. 53 KVA Heidenhain TNC 640HSCI Automatic tool changer with 80 stations Automatic oil-cooled milling head 2.5° x 1° 2 chip conveyors Coolant system with increased pressure to 37 bar ICS Special operating mode 4 RepairFIT is our proven package for a profitable entry into our product lines. Machines available in this line are sourced through a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, any found defects and faults are professionally repaired by our expert service team.

Condition: excellent (used), Year of construction: 2002, Deckel Maho DMU 80 P-Hi Dyn 5-Axis CNC Machining Center Year of manufacture: 2002 Control: Heidenhain 430 Ihodpox Dlf Rjfx Aacsu X-axis travel: 800 mm Y-axis travel: 700 mm Z-axis travel: 600 mm B-Axis: Automatic swivel milling head C-Axis: NC rotary table: 900x630 mm Workpiece weight: 800 kg Tool holder: SK40 Tool changer: 60 positions Accessories: Chip conveyor High-pressure coolant 40 bar (IKZ) Handwheel Heidenhain TS 642 probe

Condition: used, Year of construction: 2014, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 20 rpm, RepairFIT by Dornhöfer The Difference. Installation & Commissioning Included! TECHNICAL MAIN DATA Year of manufacture: 2014 Travel/Capacity: Longitudinal (X): mm 3,000 Transverse (Y): mm 1,200 Vertical (Z): mm 1,500 Clamping table/Clamping surface: Length: mm 3,200 Width: mm 1,000 Number of T-slots on table surface: pcs. 7 T-slot size: mm 22H12 Reference slot: mm 22H7 Distance between slots: mm 140 Maximum transport load: kg 11,000 Paint: graphite grey RAL 7024 and agate grey RAL 7038 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Maximum drive power, from 198 rpm: kW 30 Spindle speed range: Spindle speed: rpm 20-6,000 Maximum torque: Nm 935 Speed control: 3-stage (oil-cooled) with automatic changeover Iedeygipaopfx Aacjhu Feed rates: X, Y and Z axes mm/min: 2 – 15,000 Maximum rapid traverse speed: X, Y and Z axes mm/min: 25,000 Maximum feed force: X, Y and Z axes: N 22,000 Space requirements: Length approx. BT3200: mm 8,100 (without cross conveyor +1,280 mm) Height approx. (at Z = 1,500 mm): mm 3,800 Width approx. (at Y = 1,200 mm): mm 5,000 (with spacer 4,500 mm) Weight: approx. kg 20,200 Connected load: approx. KVA 52 HEIDENHAIN iTNC 530 HSCI Automatic MTE universal milling head Diagonal 2.5° x 2.5° Automatic tool changer with 40 positions 2 chip conveyors + cross conveyor Coolant system with 20 bar & through-spindle coolant RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are sourced through a strict selection process and undergo thorough inspection (Deep-Dive Check). After intensive cleaning, any identified obvious defects and faults are professionally repaired by our qualified service team.

Year of construction: 2005, condition: ready for operation (used), Travel X/Y/Z: 700mm/500mm/500mm, feed X/Y/Z: 5000mm/5000mm/2500mm/min, feed force X/Y/Z: 20kN/20kN/30kN. Spindle power: 7kW, speed: 3150rpm, spindle torque: 250Nm, spindle mount: ISO40. Vertical table: dimensions X/Z: 500mm/320mm, flute width: 14H8, axis distance: 50mm, number of flutes: 5. Angled table: Dimensions X/Y: 900mm/500mm, flute width: 14H8, axis distance: 50mm, number of slots: 10, machine dimensions X/Y/Z: approx. 1820mm/2050mm/2175mm, weight: approx. 2500kg, control: Heidenhain TNC 310, probe included. Documentation available. On-site inspection is possible. Ihedpjulzliefx Aacou

Condition: good (used), Year of construction: 2009, functionality: fully functional, Technical details x-travel 4000 mm Iedpfx Ajyf Evtoacohu y-travel 1350 mm z-travel (Vert.) 1600 mm Control Heidenhain iTNC 530 table surface area 4200 x 1150 mm table load 13 t tool taper ISO 50 spindle turning speed - stepless 0 - 3000 U/min transmission ratio 2 spindle motor 28/38 kW feed range 5000 mm/min rapid traverse (X/Y) 12 m/min rapid traverse (Z) 10 m/min weight of the machine ca. 37 t dimensions of the machine ca. 12,9 x 6,53 x 3,79 m

Condition: used, Year of construction: 2000, x-travel 4300 mm y-travel 1000 mm z-travel 1700 mm Ijdjyhhvhepfx Aacjhu Control TNC430 ja
