Böhringer VDF 250

Condition: good (used), Year of construction: 1990, functionality: fully functional, CNC Lathe BOEHRINGER VDF 250 C Year of manufacture: 1990 CNC control: PHILLIPS GRUNDIG Working area: Swing diameter over bed: 550 mm Swing diameter over cross slide: 480 mm Travel (X-axis): 405 mm Travel (Z-axis): 1,099 mm Max. turning length: 2,000 mm Djdowu Rbujpfx Agdowd Turret: Number of positions: 12 Mounting: VDI 50 DIN 698800 Driven tools: No Headstock: Spindle head size: 8 DIN 55026 Front bearing diameter: 150 mm Spindle bore: 103 mm Max. chuck diameter: 315 mm Drive power, 50% duty cycle: 53 kW Max. torque: 780 Nm Spindle speed range: 30 – 3,000 min⁻¹ Feeds: Cross slide (X-axis): 10,000 mm/min Longitudinal slide (Z-axis): 10,000 mm/min Rapid traverse X-axis: 10 m/min Rapid traverse Z-axis: 10 m/min Max. feed force: 15 kN Dimensions and weight: Machine dimensions (L x W x H) approx.: 6,400 x 3,200 x 2,400 mm Machine weight approx.: 13,500 kg

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, Technical Data Working range: Circumferential diameter over bed: 550 mm Circumferential diameter over bed slide: 480 mm Axial run-out (X-axis): 405 mm Traverse path in longitudinal direction (Z-axis): 1,099 mm Max. Max. turning length: 1,000 mm Tool turret: Number of positions: 12 pcs. Holder: VDI 50 DIN 698800 Driven tools: No Headstock: Spindle head size 8 DIN 55026 Bearing diameter front: 150 mm Spindle bore: 103 mm Max. Max. diameter of the chuck: 315 mm Drive poweR 50% ED: 53 kW Max. Torque: 780 Nm Spindle speed range 30 - 3,000 min-1 Feed speeds: Face slide (X-axis): 10,000 mm/min Longitudinal slide (Z-axis): 10,000 mm/min Rapid traverse X-axis: 10 m/min Dwedst Rwlpspfx Agdjd Rapid traverse Z-axis: 10 m/min Max. Feed force: 15 kN Dimensions and weight: Machine dimensions L x W x H approx.: 5400 x 3200 x 2400 mm Weight of the machine approx.: 11,000 kg

Year of construction: 1992, condition: ready for operation (used), Turning diameter over bed/face slide: 420mm/280mm, turning length: 1000mm, spindle bore: 78mm, max. speed: 3550rpm, drive power: 35kW, tool positions: 12 (with driven tools), tool holder: VDI50, rapid traverse: 10m/min. Machine dimensions X/Y/Z: approx. 4100mm/2300mm/2200mm, weight: approx. 10000kg, control: Siemens 840T with C-axis. After a buffer battery replacement, the software of the machine was deleted, whereby some machine parameters were deleted without documentation and automatic operation is currently impossible. Expected to be available from Q1, 2025. Dsdpfx Aeu D H Hwegdjwd

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, turning length: 1,000 mm, turning diameter: 480 mm, spindle bore: 78 mm, rotational speed (max.): 4,000 rpm, Meticulously maintained lathe: Turret overhauled in 2021 and coolant pump with higher pressure installed in 2021! Draw tube replaced and spindle head re-bushed and ground in 2022! Automatic loading of parts via robot cell possible (robot cell not included)! TECHNICAL DETAILS Max. swing diameter: 550 mm Spindle nose: 40 mm Drive power (50%): 53 kW Speed range (1-step): 30 – 4,000 rpm Speed range (2-step): 20 – 2,500 rpm Turret Drum turret: 12-position Number of tool mounts: 12, of which powered: 6 Tailstock Tailstock: hydraulic with quill adjustment Dsdewx Ipqjpfx Agdowd Control CNC control with Siemens 840 D color display EQUIPMENT Fully enclosed machine housing with work area lighting Automatic power-operated sliding door C-axis Program-controlled tailstock with various live centers 12-position drum turret Driven turret tooling Prepared for automatic parts loading with robot cell Overhauled turret (2021) Coolant pump with increased capacity (2021) Draw tube and spindle head re-bushed and ground (2022)

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning length: 3,000 mm, turning diameter: 480 mm, spindle speed (max.): 3,550 rpm, quill travel distance: 100 mm, turning diameter over bed slide: 520 mm, TECHNICAL DETAILS Dodpfjww E I Isx Agdewd Turning length: 3,000 mm Recommended chuck outer diameter: 250–315 mm Swing diameter over bed: 520 mm Max. turning diameter over cross slide: 480 mm Plan travel: 435 / 405 mm Cross slide travel: 3,176 mm Tool holder shank height: 25 mm Boring bar holder, shank diameter: 50 mm Spindle nose with centering cone (DIN 55026): Size 8 Spindle bore: 78 mm Spindle diameter at front bearing: 120 mm Drive power (max.): 53 kW Max. torque: 630 Nm Speed range: 37–3,550 rpm Speed control: stepless Max. feed rate: 10,000 mm/min Rapid traverse speed: 10 m/min Max. feed force / drilling force: 15 kN Tailstock quill outer diameter: 100 mm Tailstock quill stroke: 100 mm Max. quill force: 14 kN MACHINE DETAILS Drive power: 53 kW at 50% duty cycle Approx. machine weight: 15,600 kg Bed design: VDF slant bed EQUIPMENT - Composite bed structure made of Meehanite cast iron bed and reinforced concrete subframe - High rigidity and damping - 3-point, foundation-free installation - Unobstructed chip fall due to 20-degree slant of guideway cover - Wedge-shaped cross slide for heavy-duty machining - Automatic lubrication system with reservoir

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, turning length: 1,000 mm, turning diameter: 480 mm, • Turret overhauled in 2021 • Coolant pump upgraded to higher pressure/flow rate in 2021 • Draw tube replaced and spindle head newly mounted and ground in 2022 • Prepared for automatic loading of parts via robot cell Control: CNC control including Siemens 840 D color screen TECHNICAL DATA Maximum swing diameter: 550 mm Maximum turning diameter: 480 mm Turning length: 1000 mm Spindle bore: 78 mm Drive power (50%): 53 kW Speed range (single stage): 30 – 4000 rpm Drum turret Number of stations: 12, of which powered: 6 Tool shank diameter: 40 mm Speed range (two-stage): 20 – 2500 rpm Tailstock (hydraulic quill adjustment) EQUIPMENT / ACCESSORIES Dwodpswwkx Ejfx Agdjd  Full enclosure including work area lighting  Automatic power-operated sliding door  C-axis  Tailstock programmable drag function including various center points  12-position drum turret  Turret drive unit  Chip conveyor  Coolant system with reinforced pump, approx. 4 bar  Interface for automation  Various accessories  1 pc. Heimbuch collet chuck SK 80, without collets  1 pc. Schunk Rota NCF 315 three-jaw chuck  1 pc. Schunk Rota NCF 250 three-jaw chuck  1 pc. Schunk Rota NCF 250 two-jaw chuck  1 pc. WTO broaching head  2 pcs. driven tools CAPTO axial tool  2 pcs. driven tools CAPTO axial radial tool  3 pcs. driven tools CAPTO radial tool  7 pcs. static tool holders  Installation elements  Documentation

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, turning length: 1,000 mm, spindle speed (max.): 3,000 rpm, turning diameter over bed slide: 480 mm, controller model: Siemens Sinumerik 840C, TECHNICAL DETAILS Turning length: 1,000 mm Swing diameter over bed: 550 mm Swing diameter over cross slide: 480 mm Turret: 12 positions Number of driven stations: 6 Tool holder: VDI50 Speed range: 30 - 3,000 rpm Spindle bore: 90 mm MACHINE DETAILS Control: Siemens Sinumerik 840C Dimensions & weight Dimensions (LxWxH): 580 x 270 x 270 cm Weight: approx. 11 t Dwodpfx Agjxtmvcedsd EQUIPMENT SMW Autoblok 315 power chuck (without soft top jaws) Approx. 10 driven tools Approx. 10 live centers for tailstock

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 1114.3705-24, Used CNC Lathe Make: Boehringer Type: VDF 250Cm Year of Manufacture: 1997 VDF Boehringer 250C The machine has the following features: 1000mm turning length No tailstock Driven tools Special indexing chuck Siemens 840C control system The Boehringer VDF 250Cm is a CNC lathe designed for machining chucked parts. It is characterized by its robust construction and precise machining capabilities. Technical Specifications (Model Year 1997) Working Area: Swing over Bed: 550 mm Swing over Cross Slide: 480 mm X-Axis Travel: 405 mm Z-Axis Travel: 1,099 mm Maximum Turning Length: 1,000 mm (None) Tailstock: Tool Turret: Number of Positions: 12 Tool Holder: VDI 50 DIN 69880 Live Tools: YES Spindle: Spindle Head Size: 8 DIN 55026 Spindle Bore: 103 mm Max. Chuck Diameter: 315 mm Max. Drive Power (50% Duty Cycle): 53 kW Max. Torque: 780 Nm Speed Range: 30–3,000 rpm Feeds: Automatic Feeds: 1–10,000 mm/min Rapid traverse speed: 10 m/min (X and Z axes) Max. feed force: 15 kN Dimensions and weight: Machine dimensions (L × W × H): approx. 5,400 × 3,200 × 2,400 mm Machine weight: approx. 11,000 kg Equipment: Pivoting control panel Hydraulic system from HYDROKRAFT Coolant system with 600 l tank, max. pump pressure 5.5 bar, flow rate 60 l/min, pump power 1.1 kW Chip conveyor with 325 l tank capacity, right-hand discharge 3-jaw power chuck Oil mist extraction Djdpfxswlap Ao Agdewd Control cabinet with cooling unit and temperature controller from RITTAL Control system: SIEMENS SINUMERIK 840 C Variants and Differences There are various variants of the VDF 250 series, such as the VDF 250 CU, which can be equipped with different control systems (e.g., PHILIPS B2T) and technical specifications. Some models feature driven tools and a tailstock, while others are designed as pure chuck-type lathes without a tailstock. Conclusion The Boehringer VDF 250 Cm is a versatile CNC lathe characterized by its stability and precision. With its robust construction and extensive features, it is ideally suited for machining chucked parts in a variety of production environments.
