Long belt grinder

Bürkle

Condition: good (used), Paint casting machine, paint casting station -Paint casting machine Manufacturer: Bürkle -Max. pouring width: 1290 mm -Adjustable pouring gap: via handwheel with indicator -hydraulically: height adjustable -without: paint pump -Dimensions: 2100/800/H1450 mm -Weight: 386 kg Ljdpfx Agec R Iyaotshk

Condition: used, Year of construction: 2001, Thermo-lamination system Manufacturer: BÜRKLE Type: FFAII 1300 Year of manufacture: 2001 Technical data: Working width: 1300 mm Panel dimensions Width: 200 - 1300 mm Lsdjzuzt Sepfx Agtehk Length: 400 - 3000 mm Thickness: 8 - 40 +/- 0.2 mm Film dimensions Width max. 1320 mm (lateral overhang up to 20 mm) Roll diameter 76 or 152 mm (3" or 6") Working height above floor: 940 mm System speed: 15 - 45 m/min Three-phase drive with vector control Operating side: right Panel feed: centered System configuration FFAII 1300 - Brush machine DBM (chain brushes) - Preheating and smoothing calender GKL, D = 500 mm - Thermo-oiler heater 36 kW - Hardener application machine DAH + complete hardener circulation system with monitoring - Transport section + IR zones with temperature sensors - Adhesive application machine DAK + automatic level sensing - Cooling unit for DOW cooling - Adhesive supply - Conical transport section TKE - Lamination calender EKM, D = 500 mm + film unwinding station + separating station + belt transport section with operator platform for FVE - Expansion shafts - Smoothing calender GKL, D = 500 mm at the inlet of the conveyor belt - Thermo-oiler heater 96 kW for lamination calender and smoothing calender - Central control cabinet - I.S.E. Optimat ISL 111 (year of manufacture 2004) Note: The technical data and descriptions are a transcript of the order confirmation at the time. The data is for informational purposes only and is not binding.

Condition: used, Year of construction: 1990, Paint/coating application system Ljdpfxszuzqde Agtohk Manufacturer: Bürkle Type: DAL 1 1300 Year of manufacture: 1990 Note: The technical data and descriptions are transcriptions from the original order confirmation. The data is for informational purposes only and is not binding.

Condition: used, Door panel postforming line Note: The line began series production in 2022; at this point, all machines were technically synchronized and, if necessary, overhauled. Door panel postforming line consisting of: Portal loading system Manufacturer: Kraft Ljdpfx Aezuziyegtohk Year of manufacture: 2019 Technical data - with vacuum lifter - 2 infeed roller conveyors - one transport roller conveyor for further transport Wide belt sanding machine Manufacturer: Costa Type: KK7 CT CT 1350 Year of manufacture: 2018 consisting of: Wide belt sanding machine, sanding from below Technical data - contact roller - electronic shoe sanding unit - cleaning brush - intermediate transport belt, length approx. 3000 mm Wide belt sanding machine, sanding from above Technical data - identical equipment Complete formatting, laminating and postforming line consisting of: Roller conveyor system Manufacturer: Kraft Year of manufacture: 2019 Technical data - 3 individual elements - centering station Double end profiler Manufacturer: IMA Type: FBA/II/740/A Year of manufacture: 2018 Technical data - equipped with infeed conveyor and aligning station - saw unit below - trimming unit - edge trimming unit - prism milling cutter - joint milling cutter - cross edge milling unit - 3 profile milling units - brushes Laminating line consisting of: Infeed conveyor Manufacturer: Kraft Year of manufacture: 2019 Glue application machine Manufacturer: Bürkle Type: DAK1300 Year of manufacture: 1992 Technical data - mechanically overhauled in 2018 - control system completely overhauled in 2022 - with infeed table, manufacturer Kraft - steel platform with stairs and various pumps - glue melting unit GWK Eco 03A Infeed table for laminating line Manufacturer: Kraft Year of manufacture: 2019 Laminating line Manufacturer: Bürkle Type: EKMH 1300 Year of manufacture: 1998 Technical data - new Siemens Simatic KMG Touch control system - Bürkle GLK press calender - incl. film holder and saw for overhang - working width 1300 mm - 2 temperature control units GWK - column swivel crane for loading paper rolls - extraction conveyor Postforming line Manufacturer: Homag Technical data - infeed table - with 2 saw units, horizontal and vertical - intermediate buffer with 4 levels - infeed to the postforming machine - 2 identically constructed processing sides with glue application - PU pre-melting unit Nordson / VersaBlue, year 2020 and 2004 - pressure zone with revolving magazine for various profiles - various milling units and flap brushes - 2 cooling units BEKO Bekoblizz LC, year 2020 Belt conveyor with inspection system - swivel arm with vacuum suction cup - inspection station for optical inspection of the workpiece Portal destacking system Manufacturer: Kraft Technical data - with vacuum portal and 3 destacking stations Note: The technical data and descriptions are copies of the original order confirmation. The information provided is for informational purposes only and is non-binding.

Condition: used, Paint line Paint line consisting of: Vacuum loading system Technical data - 2-strand - Roller width: approx. 1000 mm Wide belt sanding machine Manufacturer: Büftering Type: Classic 213EB Year of manufacture: 2000 Technical data - Working width: max. 1350 mm - Vacuum conveyor belt - Electronic sanding pad Belt conveyor system Manufacturer: Belting Year of manufacture: 2019 Technical data - Dimensions: 6100 x 1000 mm Dust extraction system Manufacturer: Heesemann Lsdpfxjzuzhis Agtshk Type: EA2 Year of manufacture: 1990 Paint application machine Manufacturer: Bürkle Type: DAL1-1300 Year of manufacture: 1993 Throughfeed drying tunnel Manufacturer: Bürkle Technical data - with UV lamp Paint application machine Manufacturer: Bürkle Type: DAL1-1300 Year of manufacture: 1993 UV drying tunnel Manufacturer: Elmag Type: Ti166-35+2iVM1-65 Technical data - equipped with 2 UV lamps Wide belt sanding machine Manufacturer: Büftering Type: Optimat SCO 313QHQ Year of manufacture: 2007 Technical data - Working width: approx. 1350 mm - Machine equipped with 3 sanding units (cross-longitudinal-cross) 4-tier intermediate buffer Technical data - Tier size: 3000 x 1350 mm Dust extraction system Manufacturer: Cefla Type: TN3500/TT Year of manufacture: 2004 Paint robot Manufacturer: Cefla Type: Spraybotic MD Year of manufacture: 2004 Technical data - Throughput width: approx. 1350 mm - Automatic spray arm with 4 spray nozzles - Pump station with 5 Graco paint pumps Intermediate transport Manufacturer: Cefla Type: TN3591/TT Year of manufacture: 2004 Throughfeed multi-level dryer Manufacturer: Cefla Type: VN 2000/3/7500/300-24 Year of manufacture: 2004 UV drying tunnel Manufacturer: Venjakob Year of manufacture: 2008 Technical data - Infeed conveyor belt - 4 UV drying lamps (1 below, 3 above) - mounted on 2 belt conveyors Venjakob Belt conveyor Manufacturer: Cefla Type: TN3500/E Year of manufacture: 2004 Technical data - Conveyor length approx. 3500 mm Belt conveyor Manufacturer: Cefla Type: TT/1V/3750 Year of manufacture: 2004 Technical data - Conveyor length approx. 3750 mm Roller conveyor Technical data - Roller width: 1700 mm - Conveyor length: 3750 mm Edge sanding and brushing machine Technical data - with alignment table - 3 sanding units for cross and longitudinal processing of door leaf edges Belt conveyor Manufacturer: Belting Technical data - Conveyor length: approx. 4000 mm - Belt width: approx. 1170 mm Turning system for door leaves Manufacturer: Kraft Year of manufacture: 2018 Individual components of the system can be purchased separately as follows: Vacuum loading system €10,000.00 Büftering Classic 213EB wide belt sanding machine €12,000.00 Belting belt conveyor €3,500.00 Heesemann EA2 dust extraction system €2,500.00 Bürkle DAL1-1300 paint application machine No. 1 €7,500.00 Bürkle throughfeed drying tunnel €9,000.00 Bürkle DAL1-1300 paint application machine No. 2 €7,500.00 Elmag UV drying tunnel €13,000.00 Büftering Optimat SCO 313QHQ €15,000.00 4-tier intermediate buffer €10,000.00 Cefla TN3500/TT dust extractor €4,000.00 Cefla Spraybotic MD incl. pump station €50,000.00 Cefla TN3591/TT intermediate transport €4,000.00 Cefla VN 2000/3/7500/300-24 multi-level dryer €20,000.00 Venjakob UV drying tunnel €13,000.00 Cefla conveyor belt TN3500/E €2,500.00 Cefla conveyor belt TT/1V/3750 €2,500.00 Roller conveyor €2,000.00 Edge sanding and brushing machine €5,500.00 Belting conveyor belt €2,000.00 Kraft turning system for door leaves (2018) €20,000.00 Note: T

Condition: used, Year of construction: 2001, - RBO vacuum feeder – Tornado SC 1300 Lodpfx Agszuzg Eotehk - HEESEMANN MFA 8 (transverse-longitudinal-longitudinal brushes) - HEESEMANN – Dust removal machine - Plus additional dust removal - BÜRKLE SLC 1400 – Roller coating machine - Spreading brush machine with air nozzles from above - BÜRKLE SLC 1400 – Roller coating machine - Spreading brush machine with air nozzles from above - HACKEMACK slit nozzle dryer - RBO – Vacuum stacker Oil application line Year of construction: 2001 Oil application line consisting of: RBO vacuum feeder – Tornado SC 1300 HEESEMANN MFA 8 (transverse-longitudinal-longitudinal brushes) HEESEMANN – Dust removal machine Plus additional dust removal BÜRKLE SLC 1400 – Roller coating machine Spreading brush machine with air nozzles from above BÜRKLE SLC 1400 – Roller coating machine Spreading brush machine with air nozzles from above HACKEMACK slit nozzle dryer RBO – Vacuum stacker with new Siemens control system in 2024 Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: good (used), Year of construction: 2007, functionality: fully functional, working width: 1,400 mm, roller diameter: 240 mm, passage height: 80 mm, height adjustment type: electric, working height: 870 mm, roll width: 1,500 mm, workpiece height (max.): 80 mm, Bürkle DAK 1400 adhesive application machine, from the first owner, in well-maintained condition: – Machine for single- and double-sided adhesive application – Adhesive application on the top and bottom (4-roller machine) – Robust industrial design – Direct drive of the application rollers – Separate direct drive of the metering rollers – Metering gap adjustment with mechanical digital display – Height adjustment with mechanical digital display – Roller parallelism adjustable via sliding coupling – Infeed with 3 driven rollers for part length min. 350 mm – Outfeed with 3 driven blade disks for part length min. 350 mm – Frequency-controlled drive 6-30 m/min – Motorized height adjustment via push buttons – Working width max. 1400 mm – Clearance height up to 80 mm – Working height above floor approx. 870 mm – 2 application rollers Ø 240 mm – Grooving 20 pitches per inch – 2 metering rollers Ø 190 mm – Roller width 1516 mm – Drive power 3 kW – Operating side Right – Paint finish RAL 7035 light gray Lodpfx Aozuv Dfjgtshk – Year of manufacture 2007, first owner, well-maintained condition – Sale from location Karlsruhe / Southern Germany – Inspection and trial operation possible by arrangement

Year of construction: 2016, condition: ready for operation (used), A Bürkle roller coater including Bürkle LZU 800 outfeed table is available. Working width: 700mm, max. mechanical feed speed: 120m/min, nominal feed speed: 25m/min, max. workpiece height: 80mm, working height range: 880mm-920mm, outfeed table length: 4000mm, operating hours: approx. 1233h. Accessories: two original Bürkle spare rollers (sealed). Documentation available. On-site inspection possible. Lhedjxtfgyspfx Agtjk

Year of construction: 1993, condition: ready for operation (used), A complete paint shop is available. 1) Sergiani S.p.A. Monomatic S, year of construction: 2001. 2) Finnrose FLT 6, year of construction: 1993. 3,4,5) Three identical Bürkle DAL1-1300 presses, year of construction: 1993. 6) Karl Heesemann FGA 6 EX, year of construction: 1993. 7) Finnrose FLT-4.5, year of construction: 1993. 8) Bürkle DAL2-1300, year of construction: 1985. Hackemack KTR 2040, year of construction: 1996. All machines are part of a paint shop. On-site inspection is possible. Lhedpfetpp H Eex Agtek

Condition: excellent (used), Shelf dimensions: 130 cm width, 255 cm length. Lhodpezimiusfx Agtsk
