Wide-belt sander

Bütfering AWS Combi 1350

Condition: used, Year of construction: 1984, Used machine Year of manufacture: 1984 Condition: fully inspected and serviced Features and technical data: - Includes combination unit with contact roller and sanding pad Gisdew R Hh Ujpfx Aa Iol - Height-adjustable contact roller for calibration - Air-cushion pressure pad controlled by the workpiece - 4-way adjustable grit compensation - Pneumatic belt tensioning device - Rotating texturing brush at the outfeed side of the machine - Sanding width: 1350 mm - Sanding belt length: 1900 mm - Passage height: 150 mm - Main motor: 15 kW - Infinitely adjustable feed speed: 2.5 – 12.5 m/min - Infeed roller table - Separate, additional texturing brush - Outfeed roller table - Digital display device for the electrically powered workpiece thickness adjustment - Automatic workpiece thickness adjustment - Extraction sockets: 2 x 200 mm - Feed belt is functional; damaged at one location (see photo) Dimensions: approx. 2300 x 2000 x 2300 mm Weight approx.: 2500 kg The images show the machine in a condition prior to inspection! Location: Röllbach Availability: approx. 4–6 weeks after order confirmation

Condition: excellent (used), Calibration and fine sanding machine with 1 sanding unit 1 motor, processing from above Working width 1000 mm Sanding belt dimensions 2200 x 1030 mm Workpiece dimensions 3 - 170 mm Table height adjustment motor 0.18 kW, 400 V, 50 Hz Main motor 7.5 kW, 400 V, 50 Hz 2 feed speeds 5.5 & 11 m/min 1st unit: Combination unit, sanding drum, rubberized, 90 Sh / pneumatic sanding pad Sanding pad NEW 2nd unit: Cleaning brush Compressed air requirement approx. 6 bar Suction diameter 200 mm Dimensions approx. L x W x H = 1385 x 1980 x 1900 mm Weight approx. 1800 kg Automatic workpiece thickness adjustment with digital display Oscillation of the sanding belt Sanding belt emergency stop with disk brakes Table extension with 3 rollers in the outfeed Emergency stop button Main switch TRANSPORT CARPET LIKE NEW - was replaced by us approx. 3 years ago MORE THAN 30 WIDE BELT SANDERS Note used machines: Gedpfx Aeudxchja Ijil - Subject to errors in technical specifications and prior sale. - Prices quoted are ex location - free loading! - The machines have been cleaned and functionally tested. - All machines are purchased as seen without any warranty. The buyer is free to inspect the machines on site. - Special agreements are only possible in written form. (Inquiries will only be answered with your address and telephone number).

Condition: reconditioned (used), Year of construction: 1993, functionality: fully functional, Weight approx. 1140 kg Connected load 380V 7.5kW Scoring unit 0.75 kW manually adjustable via pneumatic connection, can be raised and lowered Trimming length 2800 mm speeds 600/5000/4000/3000 rpm via V-belt Giedpfoq Au Huox Aa Isl Electric tilt with digital display Electric height adjustment with digital display Cutting width 1000 mm rear support table 950 x 400 mm wide angle fence 2500 mm with extension 2840 mm with 2 stops suction connection 120 mm + 80 mm for PSV Parallelogram protection device with narrow and wide hood Trimming fence Air requirement for scorer 6bar connection

Year of construction: 1988, condition: used, rolls: 4 speed: 2 - 30 m/min number of speeds: 2 Getriebe, 2 Motor, 2 Zahnrad-wechsel (8) Gsdpsw Dd Rhefx Aa Ieil

Condition: used, Wide belt sander Bütfering, year of manufacture 1985, not so good condition, including pneumatic sanding shoe, electric table lift, 1350 mm table width, connected load 40A, approx. 2,200 kg Gjdpovrvlhofx Aa Ioil Prices subject to change, errors, printing and typesetting errors reserved

Condition: used, Working width 1100 mm Working height 2 - 180 mm Gijdpfsw N Ngdsx Aa Iel Sanding belt speed 9 + 18 m/min Sanding belt 2800 x 1120 mm Feed rate 6-25 m/min 1 combination unit Weight 2450 kg Machine loaded free on truck

Condition: excellent (used), Year of construction: 1994, Langzauner Edge Sanding Machine EK 3/4 - School Machine - Table width: 350 mm Table length: 1,000 mm Maximum sanding belt width: 150 mm Sanding belt length: 3,000 mm Belt speed: 22 m/s Gijdpsx Nrfwsfx Aa Ijl Main motor: 2.2 kW Round sanding support Oscillation Height adjustment: table, manual Sanding belt tiltable: Yes Conformity marking: CE mark Total connected load: 4.6 kW Space requirements: Length: 1.7 m Width: 0.85 m Height: 0.9 m Location: ex stock 54634 Bitburg - Immediately available -
