Folding machine

Bernardo TB 1270

Condition: new, Universally applicable bending machine for metalworking and repair shops. Working length: 1270 mm Max. sheet thickness (400 N / mm²): 2.0 mm Max. opening width: 45 mm Bending angle: 0 - 135° Hodpfovnrk Eox Anpjp Width: 1620 mm Depth*: 1115 mm Height: 1150 mm Weight approx.: 340 kg * with back stop Features: - Universally applicable bending machine for metalworking and repair shops - Robust construction in a modern design - Easy adjustment of the upper beam using the foot pedal, hands are free for the workpiece - Manual bending machine for standard bending tasks - Segmented upper beam for a large number of bending options - Optimal price-performance ratio - Fast and easy bending process using the bow handle - Easy adjustment of the lower beam to the respective sheet thickness - High upper beam for producing high-edged profiles Scope of delivery: - Segmented Upper beam - Back stop - Bending segments 25 | 30 | 35 | 40 | 45 | 50 | 75 | 100 | 150 | 200 | 250 | 270 mm

Condition: new, sheet width 1270 mm plate thickness 2.0 mm daylight opening 48.0 mm Hedpfxsxabquj Anpep daylight opening 150 mm ohne Segmente bending angle max. 0 - 135 ° work height max. 900 mm weight of the machine ca. 465 kg dimensions of the machine ca. 1620 x 1070 x 1280 mm Furnishing: - Swivel bending machines with segm. Upper, lower and bending beam - Universally usable bending machine for sheet metal works and repair shops - Robust construction in a modern design - Easy adjustment of the upper beam using a foot pedal - Hands are free for the workpiece - Manual bending machine for standard bending tasks - Segmented upper beam for a large number of bending possibilities - Optimum price-performance ratio - Quick and easy bending process using the bow handle - Non-slip rubber covering on the foot pedal for safe working - Easy adjustment of the lower beam to the respective sheet thickness - High upper beam for the production of high folded profiles Scope of delivery : - Segmented upper, lower and bending beam - manual backgauge - Corner segment left / right each 75 mm | 25 | 30 | 35 | 40 | 45 | 50 | 75 | 100 | 200 | 250 | 270mm
