Lead/traction spindle latheBernardo
Titan 560 x 2000 Pro Vario
Machine data
Price & Location
- Location:
- Stahlwerkstrasse 4, 57555 Mudersbach, DE
Details about the offer
- Listing ID:
- A202-48670
- Update:
- 09.10.2025
Description
Technical Specifications
Center Distance: 2000 mm
Center Height: 280 mm
Swing Over Bed: 560 mm
Swing Over Gap: 785 mm
Swing Over Cross Slide: 350 mm
Bed Width: 350 mm
Spindle Bore: 105 mm
Spindle Mount: DIN 55029, D1 – 8
Speed Range: 25 – 220 / 220 – 1500 rpm
Longitudinal Feed Range (42): 0.055 – 3.061 mm/rev
Cross Feed Range (42): 0.025 – 1.384 mm/rev
Metric Threads (41): 0.1 – 14 mm
Inch Threads (60): 2 – 112 TPI
Quill Diameter: 75 mm
Quill Travel: 185 mm
Quill Taper: MK 5
Djdpfjxl Tc Tsx Aghsku
Motor Power: 7.5 kW (10.0 HP)
Machine Dimensions Length: 3340 mm
Width x Height: 1150 x 1610 mm
Weight approx.: 2720 kg
Features
• Standard with Delta frequency inverter for high torque at low speeds and nearly constant speed under load
• Infinitely variable speed control, with digital readout of set speed
• Versatile applications in general engineering, production, one-off manufacturing, etc.
• Removable gap bridge for machining large-diameter workpieces
• Standard rapid traverse in longitudinal and cross directions for reduced non-productive times
• Modern main spindle bearing with angular contact ball bearings in precision design
• The machine bed is cast in one piece, extremely torsion-resistant and low-vibration, ensuring a key requirement for precise turning
• Tailstock offset for taper turning
• Central lubrication for the carriage
Scope of Delivery
• 3-axis ES-12 V digital readout with LCD display
• 315 mm / D8 3-jaw chuck PS3
• Fixed steady rest – max. passage diameter: 180 mm
• Follow steady rest – max. passage diameter: 120 mm
• Foot pedal with braking function (CE compliant)
• Safety guard for quick-change toolpost
• LED machine light
• Initial fill with Shell Tellus 46
• 450 mm face plate
• 2 live centers
• Frequency inverter
• Digital speed display
• Slip clutch
• Rapid traverse longitudinal and cross
• Coolant device
• Quick-change toolpost with 4 holders
• Change gears
• Reducing sleeve
• Chip guard
• Operating tools
