COMPLETE HEAD 11 CENTERING SPINDLES

BIESSE

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 6,170 mm, travel distance Y-axis: 1,395 mm, travel distance Z-axis: 180 mm, drill diameter: 35 mm, rotational speed (max.): 24,000 rpm, Submission of bids obligates timely collection by the end of May! TECHNICAL DETAILS Travel axis X: 6,170 mm Travel axis Y: 1,395 mm Travel axis Z: 180 mm Spindle Main spindle power: 7.5 kW to 12 kW Max. speed: 24,000 rpm Tool holder: HSK F63 Drilling head Vertical spindles X-direction: 10 Vertical spindles Y-direction: 10 Horizontal spindles X-direction: 6 Horizontal spindles Y-direction: 2 Max. drilling diameter: 35 mm Usable length: 45 mm Max. outreach: 60 mm Tool change system Turret tool changer capacity: 18 tools Holder: ISO30 / HSK F63 Max. tool diameter: 200 mm Max. tool length: 160 mm Working length: approx. 7,300 mm MACHINE DETAILS Clamping and vacuum system Vacuum pump capacity: 90 m³/h Uniclamp clamping unit workpiece thickness: 4,098 mm Electrical system Connection: 400 V / 50 Hz / 3 Phase Power: 22 kW Cgedpfx Aey Iwuhod Nst Compressed air Connection: 3/8" Operating pressure: 6 bar Consumption: approx. 400 NL/min Extraction Connection diameter: 250 mm Air requirement: 5,300 m³/h Air speed: 30 m/s Pressure drop: 1,500 Pa Dimensions & Weight Dimensions (L x W): approx. 8,850 x 4,020 mm Machine weight: approx. 4,750 kg EQUIPMENT Portal design with movable machining unit 10 consoles with adjustable vacuum supports 30 adjustable support elements Multi-zone vacuum system Automatic central lubrication Chip conveyor Blow-off device for spindle Pneumatic preparation system Safety equipment in accordance with Directive 98/37/EC CNC control (Biesse system)

Condition: excellent (used), C.N.C. WORKING CENTER with 4 axes (X-Y-Z-C) for routering, boring, cutting and edge banding Goose-neck type Numerical Control Type ?? / Software Biesse Works N. 1 Working table with N. 10 supports ATS (L = mm 1800) Automatic Tools Changing System (Store /14 folds-positions) Useful working area (X - Y - Z) mm 6735 x 1650 x 290 Cgjdpfx Asy Nk R Eod Net Useful working area (X - Y - Z) in edge banding mm 5780 x 1650 x 60 N. 2 Working areas n. 1 Vacuum pump (capacity m3/h) 250 Front emergency carpets - Motorized carpet to evacuate the wastes from the working process Total power installed KW 31.13 Working group (top): N. 20 Independent vertical boring spindles N. 8 Independent horizontal boring spindles N. 1 Circular Saw N. 1 Vertical electro-spindle HSK F63 (Kw 13,2) Edge Banding group on board, with Glueing Unit (Hot Melt glue) Edges (tape) thickness in rolls (min/max) mm 0,4 - 3 Edge coils supporting unit (N. 4 reels)

Condition: used, machine/vehicle number: 007687, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, Hot Air Premilling Unit: yes Corner Rounding Unit: yes Codswuz Npjpfx Ad Nogt Max feed speed: 18 m/min Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: used, machine/vehicle number: 007673, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 25 m/min Maximum panel thickness: 60 mm Cgjdpfey Nkuksx Ad Net Operating Units: 8 nr

Condition: used, machine/vehicle number: 007645, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, Hot Air Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Cgedjwuz Niepfx Ad Net Max feed speed: 18 m/min Maximum panel thickness: 60 mm Operating Units: 9 nr

Condition: used, machine/vehicle number: 007087, X axis working area: 4300 mm Y axis working area: 2200 mm Cjdpfxey Nkrvs Ad Negt Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Total number of drilling spindles: 40 Total number of tool changer positions: 30

Condition: used, machine/vehicle number: 007913, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt, Hot Air Premilling Unit: yes Corner Rounding Unit: yes Cgedpfx Aewkf Dvod Net Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: used, machine/vehicle number: 008112, X axis working area: 3390 mm Y axis working area: 1535 mm Working Table: Pod and Rail Main Electrospindle power: 15 KW Number of controlled axes: 5 axes Total number of drilling spindles: 21 Total number of tool changer positions: 14 Csdjw Idgvjpfx Ad Nogt

Condition: used, machine/vehicle number: 007685, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: PUR Corner Rounding Unit: yes Combination Squaring Edgebanding Machine: First and Second Pass Max Panel Width: 3200 mm Csdpfx Asy Nkqfod Nogt Operating Units Right Side: 15 nr Operating Units Left Side: 15 nr

Condition: used, machine/vehicle number: 007641, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, PUR Combination Squaring Edgebanding Machine: First Pass Max Panel Width: 1200 mm Codpfxewuz R Hs Ad Negt Operating Units Right Side: 8 nr Operating Units Left Side: 9 nr
