9-POINT HEAD

BIESSE

Condition: ready for operation (used), Year of construction: 2022, machine/vehicle number: 1000056636, functionality: fully functional, cutting width (max.): 3,500 mm, overall weight: 3,969 kg, cutting length (max.): 3,200 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Max. cutting length: 3,200 mm Max. cutting width: 3,200 mm Ibsdpfxjz Ni Eqe Acpoc MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 8,000 x 2,400 x 2,400 mm Weight: 3,969 kg Shipping packages: 4 units EQUIPMENT CE marking Documentation

Condition: used, total height: 2,200 mm, total length: 5,350 mm, total width: 1,200 mm, Year of manufacture: 2018 Colour: White Weight: 3.500 kg Price: On request - Year: 2018 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 1000022855 - Number of units [pcs]: 8 - └ 1st unit type: Pre-milling unit - - Tools available: Yes - └ 2nd unit type: Glue unit - └ 3rd unit type: Pressure rollers - - Tools available: Yes - └ 4th unit type: Cap unit - - Tools available: Yes - └ 5th unit type: Rough milling unit - - Tools available: Yes - └ 6th unit type: Corner rounding unit - - Tools available: Yes Ibedozw El Ropfx Acpsc - └ 7th unit type: Flat scraping unit - - Tools available: Yes - └ 8th unit type: Brushing unit - - Tools available: Yes - Min. edge band thickness [mm]: 0.4 - Max. edge band thickness [mm]: 3 - Edge band height [mm]: 64 - Min. panel thickness [mm]: 10 - Max. panel thickness [mm]: 60 - Min. panel width [mm]: 85 - Max. panel width [mm]: 3200 - Min. panel length [mm]: 140 - Max. panel length [mm]: 3200 - Min. feed speed [m/min]: 12 - Max. feed speed [m/min]: 18 - Feed speed control: Variable - Left or right-sided: Yes - Max. spindle speed [rpm]: 12000 - Voltage [V]: 400 - Current consumption [A]: 20 - Fuse [A]: 32 - Power [kW]: 11.0 - Transport dimensions: 5350mm x 1200mm x 2200mm (l x w x h) - Transport weight [kg]: 3500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, machine/vehicle number: 008689, X axis working area: 6735 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Ibjdeznuxbjpfx Acpjc Number of controlled axes: 4 axes Maximum edge height: 65 mm Total number of drilling spindles: 30 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008470, X axis working area: 4300 mm Y axis working area: 2205 mm Ijdpfoyzyrvex Acpsbc Working Table: Flat table Main Electrospindle power: 13 KW Number of controlled axes: 5 axes Total number of drilling spindles: 46 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008782, Max. panel width: 3200 mm Max. panel length: 1000 mm No of Bottom Units: 5 No of Top Units: 2 Positioning of Units by NC: yes Lateral horizontal groups: yes Ijdpfx Aoz S T Unocpebc

Condition: used, machine/vehicle number: 008438, Max. panel width: 4500 mm Max. panel length: 4500 mm Main saw blade projection: 50 mm Ibodpfeyngy Sex Acpec No of Grippers: 8

Condition: used, machine/vehicle number: 008606, Max. panel width: 3200 mm Ibjdpfx Acezqz Rcspec Max. panel length: 1000 mm No of Bottom Units: 5 No of Top Units: 2 Positioning of Units by NC: yes Lateral horizontal groups: yes

Condition: used, machine/vehicle number: 008694, X axis working area: 4320 mm Y axis working area: 1287 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Number of controlled axes: 5 axes Total number of drilling spindles: 16 Total number of tool changer positions: 31 Ibedpszqz Nxefx Acpjc

Condition: excellent (used), Year of construction: 2022, Manufacturer: BIESSE Model: AKRON 1440 A Category: Edge banding machine Year of manufacture: 2022 Availability: short notice Operational status: disassembled/stored Technical data Maximum edge banding thickness: 12 mm Maximum panel thickness: 60 mm Maximum thickness of roller material: 3 mm Iedpfxezb Aics Acpebc Minimum workpiece length: 140 mm Minimum workpiece width: 50 mm Minimum feed rate: 12 m/min Maximum feed rate: 18 m/min Feed rate: stepless Height adjustment: motorized Belt overpressure Gluing system: granulate Glue reservoir: top Quick-change glue reservoir Suitable for PUR adhesives Strip magazine Spraying device Edge trimming unit Preheating zone Pressure zone, NC-controlled Miter saw unit: 2 motors Edge trimming/radius/chamfer stations: 1 Corner copying unit: 2 motors Pulling blade unit Profile pulling blade, flat pulling blade Smoothing unit Nesting equipment Edge trimming/radius/chamfer stations, profile pulling blade Units controlled by timer NC axis(es) Profile change: automatic Edge trimming/radius/chamfer stations Design: left-hand machine Machine length: 5,610 mm Control system: BIESSE SMART TOUCH 23" Conformity marking: CE marking, EAC marking Total connection: 13 kW Weight approx.: 2,250 kg Location: at customer's site - available immediately - As it is disassembled/stored.

Condition: as good as new (ex-display), Year of construction: 2026, CNC Machining Centers Rover Multi Up M C S Working Area*: X = 3280 mm; Y = from 1580 to 1660 mm, depending on work conditions Z = 200 mm – 5-axis machining unit and drilling unit, with vacuum modules H = 74 mm Z = 245 mm – 5-axis machining unit and drilling unit, with vacuum modules H = 29 mm Workpiece Clearance*: Y = 1900 mm Axis Travel*: X = 3706 mm; Y = 2294 mm; Z1 = 515 mm; Z2 = 371 mm VACUUM SYSTEM Subdivision of the vacuum system into 2 working zones and 2 clamping zones in X. AUXILIARY VACUUM SYSTEM – 2 zones Allows clamping of workpieces using vacuum templates. Remote Control RM850 Rover Multi Up M C S Panel – Multi Purpose Regular Configuration 2 Compatible with the turret tool magazine with 16 positions and the side tool magazine with 12 positions. The tool magazines can also be retrofitted. Uninterruptible Power Supply (UPS) for machine PC. 6 ATS workpiece supports – 18 module carriers — 6 aluminium workpiece supports. The positioning of the workpiece supports is via linear guides with ball bearing slider blocks. Clamping is performed on the front and rear linear guides via pneumatic cylinders. Clamping is released by a push button located at the front of the workpiece support. — 18 module carriers, 132 x 132 x H 41.5 mm, with independent pneumatic clamping. The vacuum modules can be rotated in 15° increments on the module carriers; an ideal solution for shaped parts. — 18 covers for module carriers without template. SA (Set-Up Assistant) working table for tables up to 1550 mm. Supported manual positioning system with motion direction indicator and position indicator. — Sensors on each working table and along the X-axis of the working area. — Display of direction and position achieved for the carriage during positioning phase, mounted on each working table. According to the programmed configuration of the working tables, the system indicates the direction of movement for each working table and carriage, and confirms with a green LED and audible signal when the correct position is reached, with a tolerance of +/- 1.5 mm. Subdivision of the pneumatic system into 2 working areas in X. Machining unit with 5 interpolating axes, 13 kWp (17.4 HP), with HSK F63 adapter, liquid-cooled – 20,000 rpm Extraction hood with 12 NC-controlled positions for the 5-axis electrospindle. Flange for preparation of a 5-axis interpolating machining unit for mounting aggregates. Coolant system Additional Z-axis carrier for rear machining units, with independent Z-axis. Drilling head BH 24 L Side tool magazine with 12 positions, integrated into the machine bed. Turret tool magazine with 16 positions, installed directly on the X machining unit. HSK F63 tool adapter, equipped with a long integrated flange, for saw blades on the 5-axis head. Saw blade 300 mm, for tool holder. Hi-Tech tool set Complete set of tools for the acceptance test Consisting of the following 9 parts Replacement of standard PC with a high-performance PC. Digital device for measuring tool length up to 130 mm diameter. bSolid NC-HOPS 8 MacroCAM Rover 1. AV NC-HOPS MacroCAM 1. License WorkCenter suction cup proposal 5-Axis Simultaneous Ibedpfoy Ehrxox Acpec Material removal simulation 12-month warranty period Location: ex stock 54634 Bitburg - immediately available -
