COMPLETE HEAD 4 SPINDLES

BIESSE

Condition: ready for operation (used), Year of construction: 2022, machine/vehicle number: 1000056636, functionality: fully functional, cutting width (max.): 3,500 mm, overall weight: 3,969 kg, cutting length (max.): 3,200 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Max. cutting length: 3,200 mm Max. cutting width: 3,200 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 8,000 x 2,400 x 2,400 mm Hnsdpjz Ni Eqsfx Akrju Weight: 3,969 kg Shipping packages: 4 units EQUIPMENT CE marking Documentation

Condition: excellent (used), Year of construction: 2022, Manufacturer: BIESSE Model: AKRON 1440 A Category: Edge banding machine Year of manufacture: 2022 Availability: short notice Operational status: disassembled/stored Technical data Maximum edge banding thickness: 12 mm Maximum panel thickness: 60 mm Maximum thickness of roller material: 3 mm Minimum workpiece length: 140 mm Minimum workpiece width: 50 mm Minimum feed rate: 12 m/min Maximum feed rate: 18 m/min Feed rate: stepless Height adjustment: motorized Belt overpressure Gluing system: granulate Glue reservoir: top Quick-change glue reservoir Suitable for PUR adhesives Strip magazine Spraying device Edge trimming unit Preheating zone Pressure zone, NC-controlled Miter saw unit: 2 motors Edge trimming/radius/chamfer stations: 1 Corner copying unit: 2 motors Pulling blade unit Profile pulling blade, flat pulling blade Smoothing unit Nesting equipment Hnjdpszb Aicefx Akrsu Edge trimming/radius/chamfer stations, profile pulling blade Units controlled by timer NC axis(es) Profile change: automatic Edge trimming/radius/chamfer stations Design: left-hand machine Machine length: 5,610 mm Control system: BIESSE SMART TOUCH 23" Conformity marking: CE marking, EAC marking Total connection: 13 kW Weight approx.: 2,250 kg Location: at customer's site - available immediately - As it is disassembled/stored.

Condition: as good as new (ex-display), Year of construction: 2026, CNC Machining Centers Rover Multi Up M C S Working Area*: X = 3280 mm; Y = from 1580 to 1660 mm, depending on work conditions Z = 200 mm – 5-axis machining unit and drilling unit, with vacuum modules H = 74 mm Z = 245 mm – 5-axis machining unit and drilling unit, with vacuum modules H = 29 mm Workpiece Clearance*: Y = 1900 mm Axis Travel*: X = 3706 mm; Y = 2294 mm; Z1 = 515 mm; Z2 = 371 mm VACUUM SYSTEM Subdivision of the vacuum system into 2 working zones and 2 clamping zones in X. AUXILIARY VACUUM SYSTEM – 2 zones Allows clamping of workpieces using vacuum templates. Remote Control RM850 Rover Multi Up M C S Panel – Multi Purpose Regular Configuration 2 Compatible with the turret tool magazine with 16 positions and the side tool magazine with 12 positions. The tool magazines can also be retrofitted. Uninterruptible Power Supply (UPS) for machine PC. 6 ATS workpiece supports – 18 module carriers — 6 aluminium workpiece supports. The positioning of the workpiece supports is via linear guides with ball bearing slider blocks. Clamping is performed on the front and rear linear guides via pneumatic cylinders. Clamping is released by a push button located at the front of the workpiece support. — 18 module carriers, 132 x 132 x H 41.5 mm, with independent pneumatic clamping. The vacuum modules can be rotated in 15° increments on the module carriers; an ideal solution for shaped parts. — 18 covers for module carriers without template. SA (Set-Up Assistant) working table for tables up to 1550 mm. Supported manual positioning system with motion direction indicator and position indicator. — Sensors on each working table and along the X-axis of the working area. — Display of direction and position achieved for the carriage during positioning phase, mounted on each working table. According to the programmed configuration of the working tables, the system indicates the direction of movement for each working table and carriage, and confirms with a green LED and audible signal when the correct position is reached, with a tolerance of +/- 1.5 mm. Subdivision of the pneumatic system into 2 working areas in X. Machining unit with 5 interpolating axes, 13 kWp (17.4 HP), with HSK F63 adapter, liquid-cooled – 20,000 rpm Extraction hood with 12 NC-controlled positions for the 5-axis electrospindle. Flange for preparation of a 5-axis interpolating machining unit for mounting aggregates. Coolant system Additional Z-axis carrier for rear machining units, with independent Z-axis. Drilling head BH 24 L Side tool magazine with 12 positions, integrated into the machine bed. Hnedpjy Ehrxefx Akrsu Turret tool magazine with 16 positions, installed directly on the X machining unit. HSK F63 tool adapter, equipped with a long integrated flange, for saw blades on the 5-axis head. Saw blade 300 mm, for tool holder. Hi-Tech tool set Complete set of tools for the acceptance test Consisting of the following 9 parts Replacement of standard PC with a high-performance PC. Digital device for measuring tool length up to 130 mm diameter. bSolid NC-HOPS 8 MacroCAM Rover 1. AV NC-HOPS MacroCAM 1. License WorkCenter suction cup proposal 5-Axis Simultaneous Material removal simulation 12-month warranty period Location: ex stock 54634 Bitburg - immediately available -

Condition: excellent (used), Year of construction: 2018, I sell the throughfeed CNC drilling machine BIESSE SKIPPER V31, Year 2018. Configuration: 1pc. milling head 4,5kW (6,0 HP) - 18.000 rpm 10 + 4 + 2 pcs. drilling units 1pc. grooving saw Element dimensions max. 3200 x 920 x 70mm Backfeeding system to return the elements to the operator or move forwards as a throughfeed machine. With full documentation and CE. Very good condition. Available immediately. Hodpfxjz Suxue Akrjnu

Condition: used, total height: 1,500 mm, total length: 5,500 mm, total width: 1,100 mm, Year of manufacture: 2022 Colour: White Weight: 1.650 kg Price: On request - Year: 2022 - Documentation available: Yes - └ Type Documentation: Electrical diagrams, Operating system, User manual, Technical data - └ Language: NL - └ Type: Hardcopy - CE marking present: Yes - CE certificate present: Yes - Serial number: 1000054777 - Number of units [pcs]: 8 - └ 1st unit type: Pre-milling unit - - Tools available: Yes - └ 2nd unit type: Glue unit - └ 3rd unit type: Cap unit - - Tools available: Yes - └ 4th unit type: Fine milling unit - └ 5th unit type: Corner rounding unit - └ 6th unit type: Radius scraping unit - └ 7th unit type: Flat scraping unit - └ 8th unit type: Brushing unit - Min. edge band thickness [mm]: 0.4 - Max. edge band thickness [mm]: 5 - Edge band height [mm]: 64 - Min. panel thickness [mm]: 10 - Max. panel thickness [mm]: 60 - Min. panel width [mm]: 50 - Min. panel length [mm]: 150 - Max. panel length [mm]: 3200 - Feed speed control: Continuously adjustable - Glue system: Glue pot - Type of glue: PUR/EVA - Voltage [V]: 400 - Current consumption [A]: 22 - Power [kW]: 11.9 - Transport dimensions: 5500mm x 1100mm x 1500mm (l x w x h) - Transport weight [kg]: 1650kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT Hnjdpfx Aezx Aghekrju VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of manufacture: 2011 Colour: White Empty weight: 3.000 kg - Year: 2011 - Serial number: 56604 - Drilling unit present: Yes - Saw unit present: Yes - Vacuum pump present: Yes - Tools included: Yes - Transport weight [kg]: 3000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Hedpfozy Nb Iox Akronu Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: like new (used), Year of construction: 2021, machine/vehicle number: 1000047728, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, number of axes: 3, number of slots in tool magazine: 168, total length: 12,000 mm, total width: 4,500 mm, table length: 3,100 mm, table width: 2,205 mm, Equipment: CE marking, documentation/manual, FT Plus matrix table Working area: 3,100 x 2,205 mm Multi-zone vacuum system with 10 clamping areas Electrospindle: 19.2 kW Boring head: BH 10 16-position rotary tool changer 8-position rotary tool changer Hnedsz R N R Dspfx Akrju 2 x 290 m³/h vacuum pump Sweeping arm Automatic label printing in the loading zone Outfeed conveyor belt for workpieces: 3,740 mm

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, Work area X: 3100 mm Work area Y: 1500 mm 5-axis interpolating electro-spindle, 13 kW, HSK-F63 connection Extraction hood with 19-position slats Drilling bits for vertical drilling: 17 Drilling bits for horizontal drilling X: 6 Drilling bits for horizontal drilling Y: 4 Blade for grooving in the X and Y directions Rack-type tool changer with 9 positions Circular tool changer with 10 positions Hsdpfxoz R Nrnj Akrjnu Tool holder with HSK F63 connection, with short integrated flange, for blades that can be used on the 5-axis unit Blade diameter 300mm, for tool holder cone with integrated flange Work table with 6 supports Software: Biesse bSolid Control panel Vacuum pump, 120 m3/h Chip conveyor belt Safety systems with front and rear bumpers

Condition: used, Year of construction: 2017, machine/vehicle number: 1000020374, functionality: fully functional, operating hours: 5,484 h, power: 12.8 kW (17.40 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: DC, travel distance X-axis: 3,280 mm, travel distance Y-axis: 1,660 mm, travel distance Z-axis: 240 mm, number of axes: 5, number of slots in tool magazine: 16, controller manufacturer: Biesse, actuation type: pneumatic, Equipment: CE marking, documentation/manual, We are selling a 5-axis machining center, Biesse Rover A 1632 Smart, manufactured in 2017. The machining center is in very good condition due to relatively infrequent use since its purchase. We are the first owner. I have attached the file "Cartellino_1000020374" to the listing below. This is a manufacturer's document describing the configuration of the offered machine according to Biesse standards. Technical specifications of the machining center: ‣ Working areas *: X = 3280 mm; Y = 1580 to 1660 mm, depending on operating conditions. Z = 200 mm (configuration with 5-axis unit, drilling head, and H=74 mm modules). Z ​​= 240 mm (configuration with 5-axis unit, drilling head, and H=29 mm modules). ‣ Configuration 2 ‣ 6 ATS tables – 18 carriages ‣ Rear row stops with 115 mm travel and 25 mm extension. ‣ Intermediate row stop located at coordinate 1190 mm with 140 mm travel. ‣ 4 side stops with 140 mm travel (2 right + 2 left) with pneumatic system. ‣ Sensor to verify stop retraction. ‣ 4 support bars for H=74 mm modules. ‣ Claw-type vacuum pump with 250 m³/h capacity. ‣ Vacuum module – Size 132x146 – H74 mm with high-friction surface and pre-installed vacuum seal. ‣ Vacuum module – Size 132x75 – H74 mm with high-friction surface, pre-installed vacuum seal, and pre-installation for locating pins. ‣ Vacuum module – Size 132x54 – H74 mm with high-friction surface, installed vacuum seal, and pre-installation for locating pins. ‣ Automatic lubrication system. ‣ Sawdust and chip removal conveyor. ‣ 5-axis interpolating machining unit, 13 kW (17.4 HP), HSK F63 tool holder, liquid-cooled. ‣ Coolant supply unit. ‣ Additional Z-carriage for machining units, controlled by an independent Z-axis. ‣ BH 17 L drilling head. ‣ 16-position rotary tool magazine on the X-carriage. ‣ 12-position linear tool magazine mounted on the machine frame. ‣ HSK F63 adapter with integrated flange for saw blades used in 5-axis units. ‣ 300 mm diameter saw blade for integrated-flange mounting. ‣ bSolid software. Hsdpfx Ajz R I U Iekrsnu If the information above is insufficient, please contact me and let me know what you would like to know. Upon request, I can provide a document in English with a detailed description of our machining center's layout. Best regards, Ihor Balychev.

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, Working area X: 3200 mm Working area Y: 1550 mm Electrospindle Drilling bits for vertical drilling: 10 Hedpfx Ajz R I Sgjkrsnu Drilling bits for horizontal drilling X: 4 Drilling bits for horizontal drilling Y: 2 Blade for grooving in the X direction Disc tool changer with approx. 16 positions Worktable with 6 rows of stops Programming software: Biesse b_Suite3 Vacuum pump at 100/120 m3/h Safety mats Protective screens Weight approx. 2685 kg. Only 412 operating hours for the electrospindle and 92 hours for the drilling unit Includes 1 horizontal unit for door machining with 2 outlets.
