Work center

Biesse Rover 24 XL

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Travel Paths: • X-axis: 6170 mm • Y-axis: 1395 mm • Z-axis: 180 mm Machine Structure: • Gantry design with moving machining unit • 10 consoles (ATS) with adjustable vacuum pods • 30 movable support elements • Multi-zone vacuum system (4 working areas along the X-axis) Installation Dimensions: Ledpfx Amoyvz Eme Noaa • Machine length: approx. 8850 mm • Machine width: approx. 4020 mm • Working length: approx. 7300 mm Clamping and Vacuum System: • 2 vacuum pumps each with 90 m³/h capacity • Vacuum modules in various sizes (360° rotatable) • Pneumatic clamping systems: • Front stops • Side stops (left/right) • Central stops • Uniclamp clamping units for workpiece thicknesses 40–98 mm • Sensors for recognising lowered stops Machining Units Main Spindle: • Power: 7.5 kW to 12 kW • Speed: up to 24,000 rpm • Tool holder: HSK F63 Drilling Head: • Vertical spindles: • 10 along X-axis • 10 along Y-axis • Horizontal spindles: • 6 along X • 2 along Y Additional Parameters: • Max. drilling diameter: 35 mm • Usable length: 45 mm • Max. projection: 60 mm Tool Change System Turret Tool Changer: • Capacity: 18 tools • Holder: ISO30 / HSK F63 • Max. tool diameter: 200 mm • Max. tool length: 160 mm Additional: • Pick-up changer with 2 positions • Provision for aggregates (e.g., saw units up to Ø 270 mm) Electrical: • Connection: 400 V / 50 Hz / 3 phase • Power: 22 kW Compressed Air: • Connection: 3/8" • Working pressure: 6 bar • Consumption: approx. 400 NL/min Extraction: • Connection diameter: 250 mm • Air flow requirement: 5300 m³/h • Air velocity: 30 m/s • Pressure loss: 1500 Pa Mechanical Data • Machine weight: approx. 4750 kg Additional Equipment • Automatic central lubrication • Chip conveyor • Air blast device for spindle • Pneumatic pre-installation system • Safety equipment according to Directive 98/37/EC • CNC control (Biesse system)

Condition: used, SECOND-HAND HORIZONTAL COPYING LATHE WITH 4 SPINDLES BACCI - Spindles distance 180 MM - With cabin Lsdpfx Amswr Ukno Njaa

Condition: good (used), CNC Machining Center for Drilling and Milling Operations on Wood Panels, Derived Materials, Plastics, and Non-Ferrous Alloys Precise and highly reliable thanks to high-quality components, this machine is ideal for both craftsmen and industrial manufacturers aiming to increase flexibility and production quality. The main structure is made of a single welded steel base frame, constructed with thick-gauge steel plates. TECHNICAL SPECIFICATIONS • Working area X - Y - Z: 6,170 x 1,380 x 180 mm • Axis stroke X - Y - Z: 6,635 - 1,780 - 250 mm • Axis speed X - Y - Z: 100 - 100 - 30 m/min • Worktable: 10 bars Lodpstuxa Hofx Am Neaa • Bar carriages: 3 • Vacuum modules: 3 per bar • Pendulum processing up to: 2,975 mm • Two independent work zones allow simultaneous processing of two identical, mirrored, or different parts • Lifting device for easy positioning of heavy and large panels • 5-sided machining capability • "C-shaped" open frame structure • HSD routing unit • Air cooling system • Inverter included • Tool magazine: 1 with 10 positions • Drilling unit: • Vertical drilling spindles: X = 7, Y = 7 • Horizontal drilling spindles: X = 2+2, Y = 1+1 • Integrated saw blade: Ø 120 mm • Control system: NC 500 based on PC • Easy programming and file import • Remote control panel/console • Teleservice and video diagnostics for real-time support • Automatic guide lubrication system • Vacuum pumps: 2 x 100 m³/h • Chip conveyor belt • Centralized extraction duct • Extraction ports: 1 x Ø 250 mm • Safety devices: • Side protective curtains for the working unit • Perimeter safety guards with access door • Total installed power: 25 kW • Compressed air consumption: 400 NI/min • Operating pressure: 6.5 / 7.5 bar • Air consumption for extraction: 3,816 m³/h • Machine dimensions: 8,300 x 4,020 x 2,730 mm (h) • Machine weight: 4,100 kg + 600 kg (electrical cabinet) • Included documentation: user and maintenance manual, software manual, spare parts catalog, electrical diagram, CE declaration of conformity.

Condition: used, Year of construction: 2000, SECOND-HAND 5 AXIS CNC WORKING CENTER BACCI MOD. TWIN - CE - Axis strokes: X 3400 mm Y 1800 mm Z 1250 mm B unlimited C 400° - Head Type 4 (7.5 kw cad.) - Max rotation speed 24,000 rpm - N. 2 variable geometry tables TGV - Vacuum pomp - Yaskawa drivers - Osai control - Cabin on 4 sides + roof Lsdswrc Tdepfx Am Noaa - Year 2000 - CE rules
