2005 BIESSE ROVER B 4.40 FT

BIESSE ROVER B 4.40 FT

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, Work surface size: 5000×1600 8 bars with 4 carriages each with automatic positioning N. 2 ES959 electrospindles – HSK F63 air-cooled 13.2KW Rpm: 24000 Electrospindle stroke: 410mm Drilling head: BHZ111F with: 12+4V 60mm; 6H 75mm; 1L 60mm; d10; 1.7kW Automatic lubrication Drilling unit stroke: 371mm Tool magazine on the edge of the carriage: 22 places Magazine on the edge of the carriage: 4 places Magazine on the outside edge: 2 places Aggregates: Aggre109(BRUSH); Aggre44(LAMA215); GROTEFELD (L_GROT, S_GROT) Devices: n.2 x Agg117 (edge ref., edge scraper, glue scraper); Aggre99 (edge ref.) Tools: R/L Gleaner Vacuum pumps: n.1 Becker brand oil bath paddles Nodpfx Aswr Tivebcewp Axle lubrication: Automatic

Condition: excellent (used), Year of construction: 2006, I sell the double side throughfeed CNC working centre Biesse Skipper 100 Year 2006. Very productive and fast. Automatic infeed table. Working length 90-3000mm Working width 70-1000mm Working height 8-60mm Configuration per side: Milling head 3,5 kW, 7000-18000 rpm Nwodpfx Abshlhigecsp 29+8+2 Drilling heads 1 Grooving saw D.150mm X-direction Software BiesseWorks. CD included. Condition very good ! Fully working. Automatic system of central lubrication and dust collection connections. Complete with safety barriers, Transport elements and CE-points. CE-certyficate and full documents included. Repairs required: 1 safety carpet

Condition: excellent (used), Universal DOUBLE-SIDE SIZING & EDGE BANDING MACHINE (for both 1st and 2nd pass) Edges (tape) thickness in rolls (min/max) mm 0,3 - 3 Panels thickness (min/max) mm 10 - 60 Working width (min/max) mm 240 - 2700 Numerical Control /Software SINITRA Adjustable feeding speed (m/min ) 10 - 40 (INVERTER C.N.) Safety and sound-proof enclosures/cabins Distance (center-axes) of the Disappearing Dogs (mm) 500 SIZING PART (for each side): Anti-chipping Milling Unit AS 10 (Kw 5,8) N° 2 Hogging Units (1 Top + 1 Bottom) DT 10 (5,8 + 5,8) - Spraying unit (Anti-sticking liquid) EDGE-BANDING PART (for each side): Glueing Unit (Hot Melt + Quick Melt Unit) SP30 (High Melt + Edge Guide Z-axe) Band Pressure zone (N.C. adjustment) . Edge coils supporting unit (No. 6 reels) Snipping (end-cutting) unit IT 90-S (Kw 0,3 x 2) speed 28m/min. 0 - 25°. PNEU Njdpfx Asu Tg Uqebcjwp Fine Trimming unit (Multi-profile, by N.C.) RF 30 (Kw 0,65 x 2) 0 - 25° Multi Function Unit (Profile contour Trimming unit) AR 80 (Kw 0,3 x 2) max 25 m/min - ROTAX motors with automatic tool change (8+8 position store) Profile Scraping unit (Multi-profile, by N.C.) RB 30 Glue scraping unit RC 20 + Spraying Unit (for polishing liquid) Buffing unit SZ 30 (Kw 0,37 x 2) With ‘hopper’ for panels (useful height mm 80), as a buffer, to speed up the work cycle

Condition: excellent (used), Double-side Sizing & Edge Banding - First Machine (1st in a line) Double side TWIN machine (1 Left Side single machine + 1 Right-side sigle machine) Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 Panels thickness (min/max) mm 10 / 60 Working width (min/max) mm 100 / 1200 Numerical Control PC base Windows /Software PC / SINTRA Nodpfx Absu Rc Hyocswp Adjustable feeding speed (m/min) 10 - 40 (INVERTER C.N.) SIZING PART (for each side): Spraying unit (Anti-sticking liquid) No. 2 Hogging Units (1 Top + 1 Bottom) DT 10 (Kw 5,8 x 2) Free space EDGE-BANDING PART (for each side): 1° Glueing Unit (Hot Melt Glue + Quick Melt system) SP 30 (High Melt + Edge Control EC 40) 2° Glueing Unit (Thermofusion with hot air) Air Force System Band Pressure zone (N.C. adjustment) Edge coils supporting unit (No. 6 reels) Rough Trimming unit RS 10 (2 x Kw 2) Fine Trimming unit (Multi-profile, by N.C.) RF 40 (2 x Kw 1) 0°-25° No. 1 Milling grooving unit EB 60 (1 x Kw 5) 0°-90°, ISO 30 motor Profile Scraping unit (Multi-profile, by N.C.) RB 40 Glue scraping unit RC 20 Spraying Unit (for polishing liquid) Buffing unit SZ 30 (2 x Kw 0,37)
