ISO 30 ER32 right tool holder BIESSE

BIESSE ROVER

Condition: used, Year of construction: 2013, power: 17.1 kW (23.25 HP), number of axes: 4, working width: 1,320 mm, milling spindle speed (max.): 24,000 rpm, working length: 2,500 mm, TECHNICAL DETAILS Working area, X-axis: 2,500 mm Working area, Y-axis: 1,320 mm Travel, Y-axis: 1,900 mm Max. panel thickness: 170 mm Work table: Cantilever and rail table Number of controlled axes: 4 Travel speed, X-axis: 80 m/min Travel speed, Y-axis: 80 m/min Travel speed, Z-axis: 20 m/min Drilling unit Number of drilling units: 1 Position of drilling unit: top Vertical drilling spindles: 10 Horizontal drilling spindles, X-direction: 4 Horizontal drilling spindles, Y-direction: 2 Total number of drilling spindles: 16 Milling spindle Number of milling spindles: 1 Position of milling spindle: top Controlled axes: 4 Automatic tool changer: yes Motor power: 13 kW Speed: 24,000 rpm Grooving unit Number of grooving units: 1 Position of grooving unit: top Design: fixed, for grooving in the X-direction Max. tool diameter: 120 mm Isdpfx Abozmtlkehsba Motor power: 1.7 kW Speed: 7,500 rpm Number of tool magazines: 2 Tool magazine, rear: 12 slots Tool magazine, side: 10 slots Total number of tool change slots: 22 MACHINE DETAILS Machine programming software: BiesseWorks Number of vacuum pumps: 1 Suction capacity per pump: 90 m³/h Total connected load: 17.1 kW EQUIPMENT CE marking Protective structure for machining units with safety sensors Safety system: front safety mats 4 consoles with suction cups for workpiece clamping 1 drilling unit, top 1 milling spindle, top 1 fixed grooving unit, top, for grooves in the X-direction 1 rear tool magazine with 12 slots 1 side tool magazine with 10 slots 1 vacuum pump Front safety mats The machine is sold and delivered in its actual and legal condition ("as is, where is") based on photographic documentation and technical/commercial documents with a descriptive character. The buyer has the right to inspect the goods before collection and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 8359

Condition: ready for operation (used), Year of construction: 2014, operating hours: 1,618 h, travel distance Z-axis: 430 mm, number of axes: 5, number of slots in tool magazine: 16, table length: 4,300 mm, table width: 2,205 mm, spindle motor power: 13,000 W, spindle speed (max.): 20,000 rpm, swivel angle B-axis (min.): -99 °, swivel angle B-axis (max.): 100 °, swivel angle C-axis (max.): 360 °, This 5-axis BIESSE Rover A FT 2243 including WINSTORE 3D K1 was manufactured in 2014. It operates on a 400 V power supply. With approximately 1,700 hours of axis movement, this CNC wood machining centre is designed for precision and efficiency. If you are looking to get high-quality wood machining capabilities, consider the BIESSE Rover A FT 2243 machine we have for sale. Contact us for further details. Technical Data • Working Table Dimensions: 4,300 × 2,205 mm • Maximum X-Axis Speed: 80 m/min • Maximum Y-Axis Speed: 60 m/min • Maximum Z-Axis Speed: 20 m/min • Z-Axis Travel (3-/4-Axis Version): 325 mm • Z-Axis Travel (5-Axis Version): 430 mm • Maximum Workpiece Clearance in Z: 170 mm • Maximum Workpiece Clearance with Sweeping Arm: 120 mm • X-/Y-Axis Drive: Rack and Pinion • Z-Axis Drive: Ball Screw • Axis Guides: Linear Guides with Recirculating Ball Bearing Blocks • Vacuum Pump Capacity: 300 m³/h at 50 Hz • Vacuum System: 20 Independent CNC-Controlled Zones • Working Fields: 2 • Clamping Areas: 2 in X • Pneumatic Stops: 16 • Grid Table Pitch: 30 mm • Vacuum Module Dimensions: 132 × 146 mm • Vacuum Module Height: 29 mm • Vacuum Module Rotation Increment: 15° • Air Cushion Table Blower: Yes • Maximum Single Panel Thickness: 50 mm • Minimum Single Panel Thickness: 9 mm • Maximum Multiple-Panel Loading Thickness: 20 mm • Maximum Multiple-Panel Unloading Thickness: 60 mm • Protective Board Thickness: 8–25 mm • Maximum Panel Weight: 200 kg • Minimum Loadable Panel Size in Y: 800 mm • Unloading Conveyor Length: 4,800 mm • Maximum Unloadable Panel Length: 4,300 mm 5-Axis Machining Unit Ibsdpfx Aszuygqsbhsa • Number of Axes: 5 Interpolating Axes • Tool Interface: HSK F63 • Cooling: Liquid-Cooled • Power S1: 11 kW / 15 HP at 12,000 rpm • Power S6: 13 kW / 17.4 HP at 12,000 rpm • Maximum Spindle Speed: 20,000 rpm • C-Axis Rotation: 360° Continuous • C-Axis Speed: 12.4 rpm • B-Axis Positioning Range: ±100° • B-Axis Speed: 12.4 rpm • Spindle Bearings: Ceramic • Drive Motor: Brushless, Digitally Controlled • Gearbox: Harmonic Reduction Gear • Lubrication: Lifetime Lubrication Drilling Head • Type: BH 26 2L • Maximum Number of Tools: 26 • Vertical Drilling Spindles: 16 • Vertical Spindle Arrangement: 8 in X / 8 in Y • Vertical Spindle Pitch: 32 mm • Horizontal Drilling Spindles: 4 with Double Output • Horizontal Spindle Axis Distance: 32 mm • Grooving Saws: 2 • Grooving Saw Directions: X / Y • Grooving Saw Diameter: 120 mm • Maximum Grooving Depth: 25 mm • Motor Power: 1.7 kW at 2,800 rpm / 3 kW at 6,000 rpm • Maximum Drilling Speed: 6,000 rpm Tool Magazine • Type: Turret Tool Magazine • Capacity: 16 Tools • Tool Position Spacing: 114 mm • Maximum Tool Diameter with Full Magazine: 110 mm • Maximum Individual Tool Weight: 7.5 kg • Maximum Total Tool Weight: 55 kg Automatic Loading / Unloading • Loading Direction: Front • Material Flow: Right to Left • Loading / Unloading System: Type B • Suction Cups: 5 • Automatic Loading Capacity: Up to 3 Panels • Sweeping Arm: Yes • Automatic Table Cleaning: Yes • Loading Table: Automatic X/Y Alignment • Unloading Conveyor: Motorized • Conveyor Control: CNC-Controlled • Conveyor End Detection: Photocell WINSTORE 3D • System: WINSTORE 3D K1 • System Length: 16,000 mm • Beam Length: 8,000 mm • Additional Modules: 3,000 / 6,000 / 8,000 mm • Maximum Suction Frame Length: 5,200 mm • Cross Conveyors: Belt Type, 5,200 mm • Panel Handling: Raw and Thin Panels • Panel Weight Detection: Load Cell

Condition: used, Year of construction: 2007, - Working area: X = 4600 mm / Y = 1935 mm / Z = 275 mm - CE safety devices - 8 ATS plate holders - L = 1525 mm - 24 sliding rails - Automatic positioning of 8 plate holders and sliding rails (EPS X-Y) - Conveyor belt for removing chips and scrap - Pneumatic locking system, divided into 2 working areas in X - 8 rear reference stops with a stroke of 115 mm - 8 stops with a stroke of 140 mm, positioned at 1175 mm (L = 1280 - 1525 - 1800 mm) - 8 stops with a stroke of 140 mm, positioned at 770 mm (L = 1280, 1525, 1800 mm) - 4 lateral stops with a stroke of 140 mm (2 left + 2 right), including pneumatic system. - 4 removable center stops with a stroke of 140 mm (2 left + 2 right), including pneumatic system. - Sensor for detecting lowered stops. - Pneumatic system for lifting rod holders. - 6 lifting rod holders for easy loading - H = 74 mm modules. - Vacuum system for a 250 m3/h pump Ibedjzux Nwopfx Abhea - 250 m3/h rotary vane vacuum pump for standard vacuum system Composition C3-A1 - Device for mounting a chip deflector with a pneumatic or inductive sensor on a 5-axis machining unit. - Flange for mounting aggregates on a work unit with 5 interpolating axes. *Aggregates can only be used if the spindle is in the vertical position. Composition C3-P2 - Additional Z-slide for rear work units, controlled by an independent Z-axis - 16 vertical and 4 horizontal drilling spindles in the Y direction - Chain-type tool changer with 22 positions at 180 mm center distance - Iron gripper for chip deflectors with pneumatic or inductive sensor, positioned in the chain-type tool changer - RH chip deflector with inductive sensor for standard spindle or 15 kW 5-axis spindle * requires the device for the chip deflector * requires the flange for mounting aggregates when using a 5-axis spindle * requires the C-axis when using a standard spindle - Liquid cooling unit for liquid-cooled systems, can cool two spindles or one spindle and a liquid-cooled drilling head. - Automatic lubrication system - Control unit with 5 interpolating axes. This unit enables numerically controlled interpolation of the spindle on 5 axes. The spindle has high power while simultaneously having reduced dimensions. Note: - Additional overhauled 5-axis main spindle - 8 horizontal drilling spindles, 12 vertical drilling spindles, and nut saw are out of order.

Condition: used, Year of construction: 2017, The BIESSE ROVER A 1643 EDGE is a comprehensively equipped CNC machining center with a 5-axis machining head and an integrated edge banding unit. Working area, X-axis: 4,320 mm Swing machining in X: 1,620 mm Working area, Y-axis: approx. 1,580-1,660 mm Travel, Z-axis: 180 mm Edge banding Working area, X-axis: 3,300 mm Working area, Y-axis: 1,540 mm Maximum loading width in Y: 1,900 mm, expandable to up to 2,100 mm 5-axis unit 5-axis machining head C-axis: continuous 360° rotation B-axis: continuous 360° rotation B-axis speed: 18 rpm C-axis speed: 18 rpm Maximum spindle speed: 24,000 rpm Power 11 kW in S1 operation 13 kW in S6 operation Additional features Maximum undercut angle: -10° Collision monitoring for the 5-axis unit Prepared for the use of attachments on the 5-axis unit Work table and clamping system ATS work table 8 support rails 32 adjustable consoles 32 pneumatic vacuum cups Vacuum cups adjustable in 15 steps Pneumatic system divided into 2 working zones along the X-axis Ibodpfx Aezuwyzobhoa Vacuum system Vacuum pump capacity: 250 m³/h Additional equipment 6 lifting bars for easier loading and unloading 28 sensors for detecting lowered stops Stops and positioning 8 rear stops 8 center stops 4 side stops (2 left + 2 right) 2 additional side stops 4 removable center stops (2 left + 2 right) 2 additional center stops Pneumatic positioning and lowering of the stops Drilling unit BH 24L drilling head 13 independent vertical spindles 5 independent horizontal spindles Grooving saw, 120 mm Maximum groove depth: 25 mm Programmable spindle speed up to 6,000 rpm Tool changer 16-position rotary magazine Mounted on the X-axis carriage For tools and attachments Capacities Maximum tool/attachment weight: 7.5 kg Maximum total load of the magazine: 55 kg Edge banding unit GU60A edge banding unit For workpieces up to 60 mm thick Edge banding speed up to 20 m/min Double pressure roller system Glue pot with hot melt system Edge heating lamp, 600 W CNC-controlled edge feeding system Automatic edge trimming Sensor for closed geometric shapes Accessories for edge machining Edge magazine 2-roller edge magazine mounted on the X-axis carriage Maximum roller diameter: 800 mm Maximum edge height: 65 mm Additional units Rounding tool 85 mm, HSK F63 Saw unit HSK F63 for cuts and grooves Maximum saw blade diameter: 215 mm Maximum saw speed: 8,400 rpm Maximum cutting depth with a 215 mm saw blade: 68 mm Post-processing Combined glue joint and edge trimming blade units Tool sets for different edge thicknesses Software bSolid basic module 2D CAD environment Import of DXF, CIX and BPP files 3D machine simulation Tool management Management of 5-axis machining through positioning Assistant-supported program creation

Condition: used, Year of construction: 2014, Main spindle power: 13.2 kW Isdjzuwxdopfx Abheba Drilling unit motor power: 7 kW 3-axis machine Drilling unit: Technical data - Nut saw - 2 horizontal drilling spindles in the X-axis (left/right) - 1 horizontal drilling spindle in the Y-axis (left/right) - 10 vertical drilling spindles

Condition: used, Technical Specifications - Working range of the X-axis: 3,260 mm Ibjdpfx Abszutq Aohea - Working range of the Y-axis: 1,260 mm - Working range of the Z-axis: 165 mm - Machine design: Gantry - Tool magazine capacity: 16 positions - Power of the electric spindle: 19 kW - Total power consumption: 20 kW

Condition: used, Technical specifications: - X = 3,060 mm - Y = 1,320 mm - Z = 150 mm - Central automatic lubrication system - 6 ATS workpiece supports - 18 bearing consoles - Vacuum system with division into 2 working areas in the X-direction - Pneumatic system for console adjustment - 2 independent working areas in the X-direction - 4 workpiece supports - 12 clamping devices for clamping narrow workpieces - Conveyor belt for removing chips and cutting waste - Vacuum pump, 90 m³/h - 12 kW electric spindle with ISO 30 tool holder, air-cooled - The machine is additionally equipped with an integrated rotary unit that is integrated into the machine control system and functions as a 5th axis for drilling operations at different angles. Ibodpfx Abezutqvehsa - Tool changer with 10 tool positions - Manual laser barcode scanner Drilling unit BH 21L - 7 + 7 vertical drilling spindles - 6 horizontal drilling spindles (4 in the X-direction, 2 in the Y-direction) - 1 grooving unit (saw blade) in the X-direction

Condition: ready for operation (used), Year of construction: 2009, Travel ranges working area 1: X: 6450mm, Y: 1535mm, Z: 250mm, working area 2: X: 6200mm, Y: 1535mm, Z: 250mm, working area 3: X: 6200mm, Y: 1520mm, Z: 275mm, axis travel configuration 1: X: 6820.5mm, Y: 1963mm, Z: 350mm, axis travel configuration 2: X: 6820.5mm, Y: 1963mm, Z: 350mm, axis travel configuration 3: X: 6820.5mm, Y: 1963mm, Z: 663mm (5-axis head), Z: 350mm (additional machining units), control: Biesse XP600. Maintenance: complete C-axis was replaced in 2015 including accessories, vacuum pump was fully replaced in 2016 including bellows, hoses and additional components, in 2021 the machine was equipped with a new high-performance control PC running a current Windows 10 operating system. With extensive documentation. An on-site inspection is possible. Isdpfxjylziij Abhoba

Condition: used, Year of construction: 2007, total height: 2,500 mm, total length: 11,000 mm, total width: 2,400 mm, Colour: Grey Empty weight: 7.200 kg Price: On request - Machine available from: 2026-06-24 - Year: 2007 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 97649 - Number of milling spindles [pcs.]: 2 Iodpfx Absy Ipntjhoba - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 5 - - Min. spindle speed [rpm]: 1000 - - Max. spindle speed [rpm]: 20000 - - Main motor power [kW]: 9 - └ Milling spindle 2: - - Number of controlled axes [pcs.]: 3 - - Main motor power [kW]: 18.5 - Type milling table: Beam table - Tool holder: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: No - Tool changer positions [pcs.]: 22 - System/software: BiesseWorks - Safety feature: Safety mat - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: VTLF 250 - └ Year of manufacture: 2007 - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 250 - Tools included: No - CNC options: EPS system, Offcut conveyor, Manual control - CNC documentation available: USB stick, User keys/licenses - Table length [mm]: 6200 - Table width [mm]: 1320 - Working range X [mm]: 6200 - Working range Y [mm]: 1535 - Z-axis working range [mm]: 275 - X-axis maximum stroke [mm]: 6820 - Y-axis maximum stroke [mm]: 1963 - Transport dimensions: 11000mm x 2400mm x 2500mm (l x w x h) - Transport weight [kg]: 7200kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: ready for operation (used), Year of construction: 2020, travel distance X-axis: 3,765 mm, travel distance Y-axis: 1,560 mm, travel distance Z-axis: 378 mm, number of axes: 3, spindle motor power: 13,200 W, spindle speed (max.): 24,000 rpm, This 5-axis BIESSE Rover PLAST A FT 1536 was manufactured in 2020, featuring a robust electro-welded base and high-precision movement systems. It boasts a main electrospindle power of 13.2 kW, a programmable rotation speed up to 24,000 RPM, and an 8-position revolver tool magazine. Ideal for intricate woodworking, it includes a 21.5" LCD monitor and Industry 4.0 integration. Consider the opportunity to buy this BIESSE Rover PLAST A FT 1536 CNC Wood Machining Centre. Contact us for more information. • Maximum piece clearance: 170 mm • Axis speeds: X 85 m/min, Y 60 m/min, Z 20 m/min • Base: Electro-welded closed-circuit structure with high-thickness steel plates • Axis drives: X with two independent brushless motors and helical rack & pinion; Z with preloaded ballscrew, ISO5 precision • Work table: Phenolic laminate with 30 mm grid vacuum system; vacuum steps every 150 mm; M8 threaded inserts for templates/fixtures • Main electrospindle: 13.2 kW (17.7 HP), HSK F63, air-cooled, 1,000–24,000 rpm • Tool magazine: 8-position revolver on Y-carriage; max tool diameter 110 mm; max tool weight 7.5 kg (32 kg total magazine) Ibjdpjzug N Ssfx Abhoa • Tool measurement: Digital presetter for tool length measurement up to 130 mm diameter • Control system: BH660 PC-based with Windows Real Time (WRT); CPU Intel Core i5 or better; 8 GB RAM; 128 GB SSD or better; 21.5" LCD monitor • Power supply: 380/400/415 V, 50/60 Hz • Automatic lubrication system for moving parts • Software: bSolid 3D CAD-CAM for design, simulation, and process management • Connectivity: Industry 4.0 integration via TCP/IP and OPC-UA Additional equipment • Vacuum pump: 250 m³/h, dry-running • Air conditioner for the electrical cabinet • Safety guarding: 2 m high protection nets and front vertical photocells
