Compressor

BOGE S 90

Condition: used, Year of construction: 1998, pressure 160 t stroke 30 - 90 mm no. of strokes 50 - 300 /min distance between columns 1270 mm dayligth (stroke and adjustment up) 590 mm column travel -side 440 mm table surface area 1250 x 900 mm hole in the table 950 x 300 mm ram surface 1250 x 800 mm ram adjustment 100 mm material width 200 mm material thickness - 6,0 mm feed length 0 - 120 mm power requirement 64,5 kW Weight 21,00 t dimensions of the machine ca. 3,0 x 2,2 x 3,9 mxmxm permitted for automatic mode according to the CE-Norm with infinitely variable drive, hydraulic clutch/brake combination (make Desch), automatic stroke adjustment, motoric ram adjustment, fix table, circular oil lubrication mechanical roll feed Bruderer BBV 205/120 Gedpfjvut Uxsx Ad Hjua with drive via main shaft / pivot shaft of the press consoles Guethle CK 01/0800

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), movable working head. Vertical position of the panel (workpiece) Numerical Control TPA - Software Albatros Safety cabin (enclosure) of the working head Panels feeding by motorized chain/track Gujdpfx Aoihfiijd Hja Rubber-coated vertical rollers as fence and feeders during workpieces process In-feeding table (with motorized belts) - Out-feeding table (with motorized belts) With workpiece return system to the operator (180°) Min. useful working area (X - Y - Z) mm 260 x 40 x 10 (ca.) Max. useful working area (X - Y - Z) mm infinite x 1300 x 80 (ca.) Separate electric and command cabinet Total installed power (Kw) 35 WORKING GROUPS: Drilling heads with vertical spindles (No.) 1 Independent vertical boring spindles (No.) 24 (7 in X + 17 in Y) Drilling heads with horizontal spindles (No.) 2 Independent horizontal boring spindles (No.) 36 (9 LEFT + 9 RIGHT = 18 x 2) Drilling head motor-power (Kw) 3 x 3 (ca.) Vertical electro-spindle (No.) 1. Vertical electro-spindle motor power (Kw) 7,5 (ca.) Automatic Tools Changing System Revolver, with Tools storage plate (No. of folds-positions) 10

Year of construction: 2023, condition: ready for operation (used), A fully automatic SPEA bed-of-nails in-circuit tester for SMEMA production lines is available. Type: inline ICT tester, slots: 2x768/Core, conveyor width range: 50mm-380mm, conveyor length: 450mm, resistance measurement range: 1mΩ-1GΩ, capacitance measurement range: 0.5pF-1F, inductance measurement range: 1µH-1H, dimensions X/Y/Z: approx. 900mm/1000mm/1750mm. Including various feeders (8x2-56). Documentation available. An on-site inspection is possible. Guedpfoxghn Hox Ad Hoa

Year of construction: 2019, condition: ready for operation (used), An automatic optical inspection machine Göpel for inline quality control of electronic printed circuit boards is available. Inspection types: 2D/3D/360°/AOI, viewing angle: 45°, 3D camera module: ViewZ, resolution X/Y: 21µm/10.5µm, component clearance below/above the assembly: 50mm/40mm, max. inspection speed: 100cm²/s, max. inspection dimensions X/Y: 570mm/510mm, max. printed circuit board weight: 5kg, min. printed circuit board width: 80mm, machine dimensions X/Y/Z: approx. 1200mm/1450mm/1650mm, weight: approx. 950kg. Including licences. Documentation available. An on-site inspection is possible. Guodpoymfccsfx Ad Hja
