Punching and nibbling machine

BOSCHERT Compact 1250 Rota

Year of construction: 2013, condition: ready for operation (used), Main Drive Number of axis 3 Tjdpfjwvmy Ajx Agcsf This 3-axis BOSCHERT Compact 1250 Rota was manufactured in 2013. It features a working area of 1270 × 2000 mm and handles sheet thickness up to 6 mm. Equipped with a rotational tool changer, it offers versatile punching options and a user-friendly CNC control. Its compact design saves space while ensuring robust and durable construction. Ideal for batch and small to medium production runs. Contact us for more information about this machine. Application Types Punching

Year of construction: 2010, condition: ready for operation (used), A CNC turret punching machine Amada and an automatic loading and unloading unit LKI Käldman (Amada) are available. 1) CNC turret punching machine Amada EMZ3610, year of manufacture: 2010, pressing force: 300kN, travel X/Y: 2500mm/1525mm, travel X/Y with repositioning: 5000mm/1525mm, max. material thickness: 4.5mm, max. table load: 160kg. Traversing speed X/Y: 100m/80m/min, axis speed: 128m/min, positioning accuracy: +/-0.1mm. Turret stations 45, auto-index stations: 2xB/2xC, turret speed: 30rpm, stroke rate: 1000 strokes/min, machine weight: approx. 21000kg. 2) Loading and unloading system LKI Käldman (Amada) MP Sheetcat 3015, year of manufacture: 2017, min. sheet dimensions X/Y: 1000mm/300mm, max. sheet dimensions X/Y: 3050mm/1525mm, sheet thickness: 0.8mm-6mm, max. sheet weight per pallet: 3000kg, suction cups: 34, machine dimensions X/Y/Z: approx. 8400mm/3600mm/3100mm. Documentation available. On-site inspection is possible. Todpfxjv Rp Tco Agcjf

Year of construction: 2007, condition: ready for operation (used), An Amada CNC turret punching machine for medium format sheets including an MP300 M loading unit, Wilson X-Sharp grinding machine and numerous standard and special punching tools are available. 1) CNC turret punching machine Amada, year of manufacture: 2007, punching force: 300kN, max. sheet dimensions X/Y: 3000mm/1500mm, max. sheet thickness: 6.35mm, stroke rate: 600 strokes/min, simultaneous positioning speed: 128m/min, repeat accuracy: +/-0.1mm, machine dimensions X/Y/Z: approx. 5100mm/3200mm/2300mm, weight: approx. 18000kg. 2) Automatic sheet loading and unloading system Amada MP 300 M, max. sheet dimensions X/Y: 3000mm/1500mm, min. sheet dimensions X/Y: 1000mm/300mm, sheet thickness range: 0.8mm-6mm, max. load capacity per pallet: 3000kg, max. stacking height: 400mm, max. sheet weight: 170kg, max. pallets: 9, pallet change time: 25s, sheet loading time: 18s, weight: approx. 4900kg. 3) Wilson X-Sharp tool grinding machine. Documentation available. On-site inspection is possible. Tjdpfswhp N Dox Agcsf

Condition: used, Year of construction: 2022, controller manufacturer: Sonstige, controller model: AMNC-3i, _____ Description: Control : Sonstige AMNC-3i Movement X/Y/Z : 3000/1500 mm Technical data Punching machine:EMK-3612MII (58) Punching force:300 kN Positioning accuracy:± 0.1 mm Number of tool stations:58 Machine frame:Bridge frame Machine table type:Brush table Punching drive:Servo-electric dual drive Travel range (X x Y):1525 x 3050 mm Control:AMNC-3i (21.5" screen size) Features :Punch & forming function :Good parts flap :scrap conveyor system Tedpfx Aoxvv Tvogcsf Dimensions Length:5436 mm Width:6212 mm Height:2342 mm Weight:21500 kg

Year of construction: 2016, condition: ready for operation (used), General Data Measurements width 6212 mm Measurements depth 5436 mm Measurements height 2342 mm Machine weight 21500 kg Main Drive Number of axis 4 Movement X-Axis Movement 3050 mm Y-Axis Movement 1525 mm Z-Axis Movement 37 mm Turret Number of turrets 1 Additional Equipment Air-blow oil-mist lubrication Slug-vacuum system Digital tool ID / barcode system Integrated tapping: inch/metric taps (M2.5–M8) Tjdoxaqmropfx Agcsf Marking & deburring tools: on-board marking and deburring options This 4-axis AMADA EMZ3612M2 was manufactured in 2016, featuring a high-speed servo-electric turret punch press with twin AC servo direct drive. It boasts a 33-ton press capacity and an AMNC-F / AMNC-4ie CNC system for enhanced control. The machine handles sheet formats up to 3050x1525 mm and includes a "King" turret with up to 58 stations. Energy efficiency is optimized with AC servo drives. If you are looking to get high-quality punching capabilities consider the AMADA EMZ3612M2 machine we have for sale. Contact us for more information. Application Types Punching

Condition: used, functionality: fully functional, Year of construction: 2004, operating hours: 26,426 h, control type: CNC control, degree of automation: automatic, actuation type: hydraulic, punching force: 20 t, The punching machine is in good condition and has always been serviced on time by certified Amada service representatives. All documentation is included. The drum encoder was recently replaced. The machine is sold complete with software and tools. The punching machine is connected and can be tested on site. Tsdpfx Agjw E Emajcjf Specification: Year: 2004.07 Made in: France Operating hours: 26,426 Power-on hours: 65,006 Control unit: AMADA AMNC-F Punching force: 20 tons Stations: 45 Tools: sold with tooling Software: Linea 5 / Combi 5 (Only works with Windows XP) Sheet length: 2,500 mm Sheet width: 1,270 mm Sheet thickness: 3.2 mm Sheet repositioning: 5,000 mm Workpiece weight: 150 kg Dimensions: L 6080 x W 5120 x H 2318 mm Weight: 16,500 kg Location: Lithuania Test possible: Yes If you have further questions, we will be happy to answer them.

Condition: good (used), Year of construction: 1997, operating hours: 30,000 h, functionality: fully functional, machine/vehicle number: 5820387, punching force: 30 t, total height: 2,000 mm, total width: 5,000 mm, total length: 15,000 mm, sheet thickness steel (max.): 8 mm, working range: 3,000 mm, type of input current: three-phase, travel distance X-axis: 2,500 mm, Amada VIPROS 358 KING + LKI L III 250 automatic loader + PR III automatic unloader + noise protection cover . It can work complete automatic , also sorting your parts on the pallet . Tedpfx Asvb Dn Ajgcof The machine was verry well mentained , we bought this machine and did not finish installation because we bought a new machine . The machine has SICK light barriers and original protection fences . For more informations please contact me . CNC AMADAN 04 P-C N. 2 pneumatic punches Brush table for low noise operation & scratch free processing Device for automatic repositioning of the sheet metal Air Blow automatic tool lubrication

Condition: used, Offer 41414 Guide unit for punching tool suitable for AMADA type EMK 3612 Tsdpfx Agexhfhmocof
