Edgebander

Brandt Highflex 1650

Single-sided edge banding machine for processing straight workpiece edges as well as applying and post-processing various edge materials in both longitudinal and transverse feed directions.

OVERVIEW OF THE EQUIPMENT CONFIGURATION:
- POWER CONTROL PC 20+ electronic control
- PU upper pressure rollers instead of rubber rollers
- Workpiece gap optimization
- Infeed fence extension by 300 mm with additional device for laminate overhang
- JOINTING MILLING UNIT 2 x 2.2 kW 200 Hz
- GLUING UNIT A12 with automatic edge feeding
– Quickmelt application unit
– Standard application unit interchangeable for PU glue
- Pressure zone with motorized adjustment
- END TRIMMING UNIT BEVEL/STRAIGHT 2 x 0.35 kW
- PNEUMATIC ADJUSTMENT END TRIMMING BEVEL/STRAIGHT
- PNEUMATIC 2-POINT ADJUSTMENT END TRIMMING
- PRE-MILLING UNIT 2 x 0.55 kW counter-rotating
– with PNEUMATIC 2-POINT ADJUSTMENT (flush and radius/chamfer milling)
– Program control for side tracing rollers stepless and edge thickness
– Multi-roller tracing
- MULTIFUNCTION PROFILE MILLING UNIT 2 x 0.4 kW with exchange system and quick-change heads
- PROFILE SCRAPER WITH QUICK-CHANGE HEADS
- Special tracing for profile scraper
- PNEUMATIC ADJUSTMENT SCRAPER
- GLUE JOINT SCRAPER
- POLISHING UNIT
- RELEASE AGENT SPRAY UNIT WORKPIECE
- CLEANING AGENT SPRAY UNIT WORKPIECE
