Single Edgebanders

BRANDT KDF 870 AIRTEC

Condition: new, Year of construction: 2025, functionality: fully functional, Cutting range: 5300 x 2240/2100 x 80 mm Cutting depth: 80 mm Motor power: 5.5 kW Continuously adjustable scoring unit EPS.X – Electronic positioning system for the X-stop 12" touchscreen display Saw Frame • Manufacture of precision components to 1/100 mm accuracy • Solid, self-supporting, permanently welded, torsion-resistant saw frame • TRK1 full-surface support wall made of birch plywood with integrated small parts support • Auxiliary stop profile with its own measuring tape and 3 auxiliary stops for repeat cuts • Automatic detection of central support • Automatic roller locking during cutting Saw Beam • Stable, durable steel construction of the saw beam • Automatic saw beam locking with interface detection Saw Unit Nwodpjyx H Dtefx Agrsl • Play-free, easy-running guides • Robust bearing of the motor carriage ensures high cutting precision • Powerful, high-torque 5.5 kW motor (7.5 HP) • Increased operator comfort thanks to largely automated operation • Laser-assisted display for horizontal cuts • Automatic motor carriage clamping • Automatic plunging and swiveling of the saw motor • Pneumatic clutch for easy switch-over to manual operation • SUPERSILENT sound insulation to reduce saw blade noise • Electromagnetic motor brake • ProLock Easy-Fix tool clamping system Control • 12" touchscreen control panel with optimized user guidance • Multilingual user interface • Tool database for maximum flexibility and repeat accuracy • Fully automatic cutting process • Infinitely variable feed speed from 10–25 m/min • Selectable sawing cycle • Panel end detection • Constant return speed • Operating hours counter • Network connectivity • UPS 24VDC for touch PC (uninterruptible power supply) • Automatic saw beam positioning (ASP) Dimension Setting • Digital measuring system DMS.x (horizontal axis for vertical cuts) • Electronic positioning system EPS.y incl. ABO (vertical axis for horizontal cuts) Design, Ergonomics • Typical STRIEBIG product design • Multiple award-winner (including the Design Prize Switzerland) • Ergonomically optimized for function and user Installation • Wall-mounted or free-standing installation possible

Condition: excellent (used), Year of construction: 2015, I sell the fully equipped edge banding machine HOMAG KAL370 AMBITION 2474, year 2015: Configuration: Entry fence servomotorical adjustable Premilling pneumatic adjustable Edge banding with preheating tank + AirTec System Material pressure zone servomotorical adjustable End cutting saws pneumatic adjustable Tilting radius milling top + bottom servomotorical adjustable Corner rounding 4-motor pneumatic adjustable Radius R2 + multiradius scrapers servomotorical adjustable Glue scrapers servomotorical adjustable Polishing brushes Separation fluid spraying in the front Cleaning fluid spraying in the back Entry magazine for two bands in rolls automatic Working thickness adjustment servomotorical driven Material height 8-60mm Nwjdpfsxnb Uvox Agrsl Edge thickness 0,4-20mm Feeding speed up to 25m/min. Total length including feeding plate 8365mm Kilometerstatus 1.166.000 Meters edgebanded. Including full documentation and CE. Very good condition, fully working!

Condition: good (used), Year of construction: 2004, ALUP screw compressor TYPE SCK 31-10/SON 3.12 volume flow 10 bar final pressure 22.0 KW with refrigeration dryer and boiler Njdpswmwpiefx Agrswl

Condition: excellent (used), Year of construction: 2016, I sell the fully equipped edge banding machine IDM Stefani Solution MDR T-ER4S, year 2016: Configuration: Entry fence manual adjustable Premilling pneumatic adjustable Heating lamps Edge banding with preheating tank / AirFusion included Material pressure zone servomotoric adjustable End cutting saws pneumatic adjustable Tilting radius milling top + bottom servomotoric adjustable Corner rounding 4-motor servomotoric adjustable / Multiradius unit Radius R2 scrapers servomotoric adjustable / Multiradius unit Glue scrapers manual adjustable Polishing brushes Separator spraying front and back STARTOUCH control system Barcode reader Working thickness adjustment servo driven Material height 10-60mm Edge thickness 0,3-15mm Feeding speed up to 25m/min. PUR glue possible. FE-MA-TECH unit included Second glue tank absolutely new included. Only 344.000 meters edgenbanded ! Very good condition, fully working! Nsdsyw Aivspfx Agrjwl

Condition: used, Year of construction: 2023, operating hours: 489 h, Homag EDGETEQ 300 The machine will be available from approximately the end of December 2026. Nedpjz D U A Aefx Agrewl For further information about the machine, please see the images or feel free to request it.

Condition: used, Year of construction: 2013, total height: 2,100 mm, total length: 9,000 mm, total width: 1,050 mm, Weight: 6.000 kg - Details: - └ Description: Not working: Several loose sensors and the glue bin has been disassembled, machine has not yet been tested - Year: 2013 - Documentation available: No - CE certificate present: No - Serial number: - Number of units [pcs]: 9 - └ 1st unit type: Pre-milling unit - - Tools available: Yes - └ 2nd unit type: Glue unit - - Type/Brand: Nordson Nsdpfx Aeyrp Uajgrjwl - └ 3rd unit type: Pressure rollers - - Tools available: Yes - └ 4th unit type: Cap unit - - Tools available: No - └ 5th unit type: Rough milling unit - └ 6th unit type: Milling unit - └ 7th unit type: Fine milling unit - └ 8th unit type: Milling unit - └ 9th unit type: Milling unit - - Tools available: Yes - Glue system: Glue pot - Voltage [V]: 400 - Current consumption [A]: 69 - Fuse [A]: 80 - Transport dimensions: 9000mm x 1050mm x 2100mm (l x w x h) - Transport weight [kg]: 6000kg - Transport packages [pcs.]: 4 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), BRANDT KDF 340 edge banding machine - used Manual, self-clamping pressure bridge adjustment, Feed via transport chain, Workpiece support is retractable, Diamond jointing cutter for both forward and reverse rotation, Glue reservoir located underneath, Standby function, Miter saw with 2 HF motors, Miter saw is swiveling, Edge trimming/radius chamfering unit, Milling tools with carbide insert blades, Radius pulling blade, Chip collection box for radius pulling blade, Air nozzle on the radius pulling blade Nedpfx Agoz Ea Dzjrowl ----- Technical data ----- Edge thickness, roll material: 0.4-3 mm, Edge thickness, strip material: 0.4-3 mm, Workpiece thickness: 50 mm, Min. workpiece length: 250 mm, Feed speed: 9 m/min., Distance workpiece support: 400 mm, Support plate Ø for edge material: 810 mm, Dimensions jointing cutter: 100x62x30 mm, Dimensions miter saw blade: 100x2.6x32 mm, Cutting blade for roll material up to: 3 mm, Warm-up time: 17 min., Power jointing cutter: 2x2.2 kW, Power miter saw: 2x0.18 kW, Power milling station: 2x0.27 kW, Power chamfering unit: 2x0.09 kW, Dust extraction nozzle Ø jointing cutter unit: 120 mm, Dust extraction nozzle Ø milling unit: 100 mm, Dust extraction nozzle Ø pulling blade unit: 100 mm, Compressed air connection: 6 bar, Overall length: 3,550 mm, Dimensions (L x W x H): 3,550 x 1,250 x 1,450 mm Quality information: - All settings checked - Adjusted according to manufacturer's specifications - Complete basic inspection - Complete basic cleaning - Electrical system checked - Pneumatic system checked - Ready for immediate use
