Laser

Bystronic 3015

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2005, operating hours: 57,467 h, machine/vehicle number: 30003596, degree of automation: semi-automatic, laser type: CO₂ laser, laser source manufacturer: Bystronic, laser source model: Bylaser 4400, laser hours: 57,467 h, laser power: 4,400 W, table length: 3,000 mm, table width: 1,500 mm, working length: 3,000 mm, working width: 1,500 mm, power: 62 kW (84.30 HP), input voltage: 1,200 V, input current: 125 A, input frequency: 50 Hz, Equipment: CE marking, Bystar 3015 laser cutting machine from Bystronic. All maintenance has been carried out correctly by Bystronic and is up to date. The machine is ready for operation and is currently in use. Includes automation with Bytrans 3015 (year of manufacture 2006). Includes cooling system. Includes filter system. Includes 5-inch and 7.5-inch cutting heads. Includes accessories such as lenses, nozzles, etc. We have two laser machines that we need to decommission by the end of July 2026. The price is symbolic and can be significantly reduced if the buyer assumes the decommissioning costs. Bsdpfx Asyxcvfoggswn

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2001, operating hours: 90,000 h, laser power: 4,000 W, sheet thickness (max.): 12 mm, table length: 3,000 mm, table width: 1,500 mm, power: 4 kW (5.44 HP), We offer this ready for use Bystronic Bystar 3015 laser cutting machine, year of construction 2001. Manufacturer: Bystronic Model: Bystar 3015 Year of construction: 2001 The machine is in use Bwodsyt H Tpspfx Aggjn If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: used, Year of construction: 2012, Technical details: y-travel: 1500 mm distance between columns: 2300 (Brücke) mm Beam Hour: ca. 22000 h laser capacity: 6000 W control: CNC P 8109-10-600D table length: 4500 / Auflage: mm Table width: 2300 mm operating pressure: 120hPa Waterpressure - requiered: max. 6,0 bar voltage: 400 / 50 V / Hz dimension laser device LxWxH: ca. L: 3,0 x B: 1,5 m dimension filtering system LxWxH: ca. 1,4 x 2,0 x 2,2 m dimension coolant device LxWxH: ca. 2,55 x 1,0 x 1,9 m space requirements of the machine approx.: gesamt: ca. 12,8 x 5,3 x 4,3 m Bedpfx Asu Nu R Isggown Flatbed laser cutting machine Application: ind. Cutting and engraving Laser medium Co²; N²; compressed air Sheet dimensions/format 3000x 1500mm Cutting thickness: e.g. steel X5CrNi18-10 = 1 - 25mm / CNS 25mm / aluminum: 1 - 15mm (Tabb. available) Resonator - laser source ByLaser 6000W, wavelength 10.600mm, beamØ 20mm, circular polisariation Shuttle table LxWxH: 4500 x 2300 x 1000mm, load capacity 900kg, table support surface = 3200 x 2000mm Rf cooling type WKL 560, refrigerant R 407C, cooling capacity 65kW, high pressure 27bar, pump 220 l/min, fan Dedusting system, Donaldson type DFPRO6 (size approx. 1.4 x 2.0 x 2.2m) Cross conveyor by Kabelschlepp type SRF 040 (size LxW.H: approx. 3630 x 705 x 1000mm) Light barrier Sick type M 4000 Cutting bridge: Y-path 3000mm, stand width 2300mm, cutting carriage size LxWxH: 400 x 300 x 650mm Operating terminal with complete cabinet combination and manual control unit Cut Control *

Condition: used, Year of construction: 2021, Outstanding Bystronic fiber laser with 10000W laser output, automatic loading station and 2 storage towers. Can be inspected under power upon appointment. Availability: 10/2026 Including: Automatic nozzle change (64 nozzles) Detection camera Kerf scan Bedpfx Aey T Nc Uoggewn Cut control Automatic centering of laser beam and nozzle Linear axes Full technical specifications available on request. Working dimensions: 3000 x 1500 mm Laser output: 10000W Automation: ByTrans Modular 3015 Flex + Antil AWL9 2T (V1) cutting hours: 6105h

Condition: excellent (used), functionality: fully functional, Year of construction: 2017, laser power: 4,000 W, sheet thickness steel (max.): 20 mm, sheet thickness aluminum (max.): 15 mm, sheet thickness brass (max.): 8 mm, total length: 3,000 mm, working range: 1,500 mm, Equipment: safety light barrier, Bystronic BySprint Fiber 3015, 4000W Bwjdpfx Aoup Tfcoggsn Maximum cutting area: X-axis: 3048 mm, Y-axis: 1524 mm, Z-axis: 70 mmNominal sheet size: 1500 x 3000Materials and maximum thicknesses of materials to be cut: Steel 20 mm, Stainless steel 15 mm, Aluminium 15 mm, Brass and copper 8 mm.Cutting accuracy: 0.1 mmPacking accuracy: 0.05 mmMaximum workpiece weight: 890 kg

Condition: used, Year of construction: 2007, x-travel 1562 mm y-travel 772 mm z-travel 100 mm laser capacity in Watt 2200 positioning speed x 100 / y 100 m/min. working area 3000 x 1500 mm fuse 80 A Power connection 37 kVA Bwsdpfxjy R Ecxs Aggsn weight of the machine ca. 13,5 t dimensions of the machine ca. 13,5 x 2,2 x 5,60 m Co2 ByLaser 2200M Flue gas extraction with water cooling WKL 300-F Laser power: 2.2 kW (2200 W) Maximum sheet thickness (mild steel): 8 mm Maximum sheet thickness (stainless steel): 6 mm Maximum sheet thickness (acid-resistant steel): 6 mm Maximum sheet thickness (aluminum): 4 mm Maximum workpiece dimensions (L x W): 3000 x 1500 mm 2x cutting head 5" 1x cutting head 7.5" various copper nozzles

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2010, operating hours: 26,000 h, machine/vehicle number: R1011250, laser power: 4,400 W, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 170 mm, workpiece weight (max.): 890 kg, Laser source and frequency converter have been renewed! TECHNICAL DETAILS Working Area and Cutting Area Nominal plate size X: 3,000 mm Nominal plate size Y: 1,500 mm Cutting area X-axis: 3,048 mm Cutting area Y-axis: 1,524 mm Cutting head Z-lift: 170 mm Workpiece weight: max. 890 kg Dynamics and Accuracy Positioning deviation: ±0.1 mm Positioning scatter: ±0.05 mm Edge detection accuracy: ±0.5 mm Positioning speed X/Y-axis (axial parallel): max. 80 m/min Positioning speed X/Y-axis (simultaneous): max. 113 m/min Axis acceleration: max. 4.5 m/s² Laser Source Laser power: 4,400 W Laser source: Bylaser 4400 Possible laser sources: Bylaser 3000 / Bylaser 4400 / Bylaser 5200 ARC / Bylaser 6000 MACHINE DETAILS Dimensions and required space Transport system standard height: 3,650 mm Transport system height to magazine: 4,350 mm Material trolley length: 3,000 mm Additional length for extension magnet: 200 mm Material trolley width: 1,600 mm Material trolley height without plate stack: 917 mm Standard lifting height: 550 mm Lifting height to magazine: 1,150 mm Lifting height with stacked tables: 800 mm Transport data and weights Travel unit with lifting unit: 1,300 kg Vacuum gripper frame with double fork system: 1,200 kg PLC cabinet: 500 kg Material trolley: 800 kg Total transport weight ByTrans 3015: 3,800 kg Equipment and Features Vacuum gripper frame plate thickness (loading): max. 25 mm Vacuum gripper frame plate weight (loading): max. 900 kg Number of vacuum grippers: 42 Weight per gripper: max. 45 kg Compressed air: 6 bar Vacuum: -0.6 bar Double fork system plate thickness (unloading): max. 25 mm Bwjdpfoy Rt Ezjx Aggsn Double fork system plate weight (unloading): max. 900 kg Fork travel path: 2 x 790 mm Cutting hours: 26,000 h EQUIPMENT ByTrans 3015 Extended Bylaser 4400 Shuttle table Loading arm Integrated 4th rotary axis Vacuum gripper frame Loading unit with suction gripper frame Double fork system Material trolley Vacuum pump Plate separator Double sheet detection Cassette trolley Air conditioning Control cabinet with signal lamp and emergency stop Safety fence Photoelectric sensors ByTower storage system

Condition: good (used), functionality: fully functional, Year of construction: 2005, control type: CNC control, laser power: 4,400 W, sheet thickness steel (max.): 25 mm, sheet thickness stainless steel (max.): 20 mm, sheet thickness aluminum (max.): 12 mm, with ByLaser 4400 with turning axis ByVision cnc control Bwsdpsy N Rgmofx Aggen with changing table Technische Daten / technical details: Blech-Nennmass X, Y / sheet nominal size X, Y 3000, 1500 mm Schneidbereich X, Y / cutting range X, Y 3048, 1524 mm Hub Schneidkopf Z / stroke cutting head Z 170 mm Drehachse: / turning axis: Profilaufnahme Spannfutter / profile taper clamping chuck 15-315 mm Profilzuführung durch das Spannfutter / profile feed through the clamping chuck 15-155 mm max. Profilbearbeitungslänge / max. profile working length 2700 mm Laserleistung / laser capacity 4,4 kW Materialdicke Stahl / thickness of the material steel 25 mm Materialdicke Edelstahl / thickness of the stainless steel 20 Mm Materialdicke Alu / thickness of the material Aluminium 12 mm Gewicht ca. / weight ca. 13500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, functionality: limited functionality, Year of construction: 2010, operating hours: 8,472 h, machine/vehicle number: 10036188/30012864, control type: CNC control, controller manufacturer: Bystronic, laser type: fiber laser, laser source manufacturer: IPG, laser source model: YLS-2000, laser hours: 8,472 h, laser power: 2,000 W, sheet thickness (max.): 12 mm, sheet thickness steel (max.): 12 mm, sheet thickness stainless steel (max.): 6 mm, sheet thickness aluminum (max.): 8 mm, sheet thickness brass (max.): 4 mm, sheet thickness copper (max.): 3 mm, working length: 3,048 mm, working width: 1,524 mm, travel distance X-axis: 3,048 mm, travel distance Y-axis: 1,524 mm, travel distance Z-axis: 70 mm, positioning speed: 140 m/min, repeat accuracy: 0.1 mm, workpiece weight (max.): 890 kg, input voltage: 400 V, input current: 63 A, input frequency: 50 Hz, type of input current: three-phase, type of cooling: water, compressed air connection: 6 bar, overall weight: 15,000 kg, total length: 11,018 mm, total width: 6,055 mm, total height: 2,565 mm, Equipment: CE marking, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, Bystronic Bysprint Fiber 3015 Immediately available Manufacturer: Bystronic Model: BySprint Fiber 3015 Year of manufacture: 2010 / new resonator and cutting head in 2013 Sheet format: Large format 3000mm x 1500mm Operating hours: 8,472 laser hours / 42,600h machine on Prospective buyers are welcome at any time; we can gladly demonstrate and test the machine on-site. Standard equipment: - BySprint Fiber 3015; Fiber 2000 - Shuttle table system with 2 shuttle tables - Scrap cart with rollers - Restart Manager - Uninterruptible power supply (UPS) - Piercing jet - Nozzle cleaning - Operator safety in the cutting area - Operator safety in the loading/unloading area TECHNICAL DATA: - Max. positioning speed (X/Y axes parallel): 100 m/min - Max. simultaneous positioning speed: 140 m/min - Positioning deviation Pa (VDI/DGQ 3441): +/- 0.1 mm - Positioning scatter Ps (VDI/DGQ 3441): +/- 0.05 mm - Edge detection accuracy: +/- 0.5 mm - Max. workpiece weight: 890 kg - Table changeover time: 35 seconds - Laser power: 2,000 watts Bwodpoy I Dgksfx Aggjn - Max. sheet thickness: - Steel: 12 mm - Stainless steel: 6 mm - Aluminum: 8 mm - Brass: 4 mm - Copper: 3 mm - Machine weight (without extraction, chiller): approx. 12,000 kg - Machine dimensions without platform: approx. 11,000 mm length, 6,055 mm width, 2,565 mm height (extraction H=3,000 mm) - Machine dimensions with platform (as installed at our site): approx. 11,000 mm length, 4,200 mm width, 5,500 mm height (recommended H=7,000 mm) Platform is not included in the sale! Dismantling, loading, and transport should preferably be organized by the buyer to ensure proper reassembly. Various aids can, if available, be provided by arrangement. All information and dimensions are provided to the best of our knowledge and belief; however, we cannot guarantee completeness or accuracy! The sale is as seen, without guarantee, return, or similar. Subject to prior sale.

Condition: used, Year of construction: 2018, Excellent Bystronic fiber laser with 8000W laser output and ByTrans cross automation. Viewing possible upon appointment. Bwsdsy Eqk Ijpfx Aggsn Availability: Aug-Sept 2026 Working dimensions: 3000 x 1500 mm Laser output: 8000W Power on hours: 32.249 Cutting hours: 11.594 Automation: By Trans Cross
