CELASCHI double sided tenoning machine

CELASCHI

Condition: used, machine/vehicle number: 007960, Squaring: First and Second Pass Max Panel Thickness: 200 mm Max feed speed: 36 m/min Dodpfx Akswl Dnietskn Distance between dogs: 450 mm

Condition: like new (used), Year of construction: 2012, Profiling parquet machine for longitudinal side 5+5 motors Speed up to 60 m/min Min. Working width 70 mm (65 mm without bevel) Kit of Diamond tools for T&G profile Dkedpfx Akexwnhbetjn +infeed belt conveyor with lateral guide Installed, visible at our factory in working condition

Condition: excellent (used), Independent machine (standing alone) and/or Universal machine (First & Second in a line) It is 2nd DET in the X10023 LINE Electronic Programmer OMRON Safety and sound-proof enclosure Electric and command cabinet No. 3+3 Vertical columns to support the working units As a second machine, it accepts panels 1900 mm deep Min. useful working width (mm) 300 Max. useful working width (mm) 2500 Min. useful working thickness (mm) 6 (ca.) Max. useful working thickness (mm) 60 Distance between center-axes of the disappearing dogs (mm) 400 Adjustable (min/max) feeding speed (m/min) 4-24 Total installed power Kw 65 Djdpfx Akjyz Si Hstskn No. 3 Working groups (for each machine's side): - 1 Jumping vertical NC Milling Unit (useful height 300 mm), belt drive motor (9.2 kW at 3000 rpm) - 1 Standard vertical NC Milling Unit (useful height 500 mm ca.), belt drive motor (9.2 kW at 3000 rpm) - 1 Jumping vertical NC Milling Unit (useful height 300 mm), belt drive motor (9.2 kW at 3000 rpm) NOTE: These 3 main vertical Milling units are NC controlled, with horizontal and vertical adjustment - 1 Free space

Condition: excellent (used), Independent machine (standing alone) and/or Universal machine (First & Second in a line) It is the 1st Double End Tenenor in the X10023 LINE Electronic Programmer OMRON Safety and sound-proof enclosure Electric and command cabinet No. 2+2 Vertical columns to support the working units Min. useful working width (mm) 300 Max. useful working width (mm) 2000 Dkedpfx Ajyz Siaokten Min. useful working thickness (mm) 6 Max. useful working thickness (mm) 60 Distance between center-axes of the disappearing dogs (mm) 400 Adjustable (min/max) feeding speed (m/min) 4-24 Total installed power Kw 60 No. 4 Working groups (for each machine's side): - 1 Jumping vertical NC Milling Unit (useful height 300 mm), belt drive motor (9.2 kW at 3000 rpm) - 1 Standard vertical NC Milling Unit (useful height 300 mm), belt drive motor (9.2 kW at 3000 rpm) - 1 Jumping vertical NC Milling Unit (useful height 300 mm), belt drive motor (9.2 kW at 3000 rpm) NOTE: These 3 main vertical Milling units are NC controlled, with horizontal and vertical adjustment - 1 Vertical Milling Unit (1.5 kW at 1470 rpm)

Condition: used, Year of construction: 1990, Double tenoning machine with 3+3 motors, equipped with protective and soundproof cabins, 6-metre opening. Dsdeyzralopfx Aktokn

Condition: excellent (used), 4-SIDED SIZING-SHAPING LINE (currently for Internal Doors). Composed by of the following machines: X10023A) Motorized infeed rollers table "CELASCHI"" X10023B) Double End Tenoner "CELASCHI" Mod. TSA 3 B 480 A Installed power KW 65 Dkodpfx Akswzmbqoten X10023C) 90° Motorized Transfer ("L-shape") conveyor "CELASCHI" Mod. X10023D) Double End Tenoner "CELASCHI"" Mod. TSA 2 B 360 Installed power KW 60

Condition: refurbished (used), DIFFERENT TYPE OF MOTOR AND SLIDE for CELASCHI DET SECOND-HAND, FULLY RECONDITIONED Dododvlcyjpfx Aktekn

Condition: excellent (used), Year of construction: 2000, Double end tenoner Celaschi 4+4 motors Dksdpfx Akevx Afnjtsn Opening side up to 3000 mm

Condition: new, Year of construction: 2022, SPARE PARTS FOR CELASCHI DOUBLE END TENONER, second-hand and brand new. Dkedpjd E Ul Ajfx Aktjn

Condition: excellent (used), Independent machine (standing alone) and/or Universal machine (First & Second in a line) Electronic Programmer EasyLing Safety and sound-proof enclosure No. 3+3 Vertical columns to support the working units Min. useful working width (mm) 240 Max. useful working width (mm) 3100 Djdewhmdfspfx Aktskn Min. useful working tickness (mm) 3 Max. useful working tickness (mm) 150 Distance between center-axes of the disappearing dogs (mm) 800 Adjustable (min/max) feeding speed (m/min) 4 - 24 Total installed power No. 4 Working groups (for each machine's side): Scoring Unit Jumping Scoring Unit 1 x Kw 3 (RPM 6000) Hogging Unit 1 x Kw 6 (RPM 6000) 0-10° Jumping Milling Unit 1 x Kw 6 (RPM 6000) 0°-90° Milling-Shaping unit 1 x Kw 6 (RPM 6000) 0°-90°
