Automatic bar lathe

Citizen L20

Condition: ready for operation (used), Year of construction: 2016, General Data Measurements width 1085 mm Measurements depth 2300 mm Measurements height 1835 mm Machine weight 2220 kg Control Unit Brand MITSUBISHI Model Meldas 700 Additional Equipment Swarf Conveyor LNS MH-HB FMB Minimag 20/3200 bar feeder Clamping unit Ø25 mm Pump 15 bar for rinsing the counterspindle SAU819 adapters up to Ø8 mm Ibjdexwqrvepfx Adrsd This 8-axis Citizen Cincom L20E-2M8 was manufactured in 2016, designed for precision Swiss-type turning, comes with FMB bar feeder and LNS chip conveyor. It features a main spindle with a speed of up to 10,000 rpm and a counter spindle operating at 8,000 rpm. The machine accommodates up to 37 tools, enhancing its capability for complex machining tasks. It includes a Mitsubishi Meldas 700 controller for efficient operation. Consider the opportunity to buy this Citizen Cincom L20E-2M8 Swiss type turning machine. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2007, used in very good condition Ibedpfx Ajwnqxgjdrjd

Condition: excellent (used), Year of construction: 2008, operating hours: 9,000 h, functionality: fully functional, TECHNICAL DETAILS Control: Mitsubishi Meldas 700 Main Spindle Machining diameter: 20 mm Machining length without repositioning: 200 mm Spindle bore: 24 mm Spindle speed: 200 - 10,000 rpm Spindle indexing C-axis: 0.001° Motor power (built-in motor): 2.2 / 3.7 kW Sub-Spindle Machining diameter: 20 mm Spindle speed: 200 - 8,000 rpm Spindle indexing C-axis: 0.001° Motor power: 0.75 / 1.5 kW Driven Tools at Vertical Holder Speed: 200 - 4,500 rpm Motor power (AC servo motor): 1.0 kW Number of tools: 6 Tool System Turning tools (12x12x130): 5 Tool holder/parting-off blade (16x12x130): 1 Drilling tools (front): min. 3 Drilling tools (rear): 5 Tool holders, quills (diameter): 19.05 mm Tool holders, turning tools (shank cross-section): 12 mm Collets and Guide Bush Collet main/sub-spindle: F25 (145E) Guide bush (Neukomm): T223 (22.001) Rapid Traverse All axes: 32 m/min Machine Specification Required space (without magazine) L/W/H: 2,430 x 1,085 x 1,770 mm Spindle height: 1,050 mm Isdoxf Hqqjpfx Adrobd Machine weight: 2,150 kg Power supply: 8 kVA EQUIPMENT - 6 turning tools (12 mm shank cross-section), - 3 driven tools for cross machining - 3 driven tools for face machining on the main spindle - 3 driven tools for face machining on the sub-spindle - Main spindle with C-axis - Sub-spindle with C-axis - 3x powered tool rear side machining - Yellow warning light - Interior lighting - Workpiece conveyor belt - FMB Turbo 3-26 bar feeder - Option for long parts - Spindle flushing (Scherzinger pump)

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 16380, CNC automatic lathe CITIZEN CINCOM L-20 VIII with Fedek STM-326 bar feeder, year 2008. Machine is fully controlled by Citizen. Supplied with geometric protocol. Ibsdpfx Asw T Stzedred

Condition: good (used), Year of construction: 2016, CNC sliding headstock automatic lathe CITIZEN Cincom L 20E-2M8, no. QF5759, year of manufacture 2016, with EPSON robot automation 3 identical machines available Ibedpfsunw Dyjx Adrod

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 20 [mm] - Max. machining length : 200 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 3,7 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 1.5 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 5000 [rpm] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 3 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2.110 x 1.085 [mm] - Machine height : 1.832 [mm] - Machine weight : 2.200 [kg] MACHINE HOURS - Number of working hours : 44.325 [h] EQUIPMENT - CNC : Meldas - Rotating guide bush - Parts catcher - Parts conveying strip - Ejection of workpiece - Coolant tank : CoolBlaster Iodpfx Aeuhazmjdrjbd * with high-pressure pump : 138 [bars] - Bar loader : LNS Alpha ST320 - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: ready for operation (used), Year of construction: 2005, operating hours: 56,729 h, functionality: fully functional, spindle speed (max.): 10,000 rpm, bar diameter (max.): 20 mm, No minimum price – guaranteed sale to the highest bid! TECHNICAL DETAILS Max. spindle speed: 10,000 rpm Number of spindles: 2 Bar through-hole: 20 mm Driven tools: yes Main spindle speed range up to: 10,000 /min Counter spindle speed range up to: 8,000 /min Cross-slide speed range up to: 4,500 /min MACHINE DETAILS Total weight: 2,150 kg Total height: 2,000 mm Required space length: 3,000 mm Required space width: 1,400 mm Connection voltage: 400 V Mains frequency: 50 Hz Operating hours: approx. 56,729 h Ijdjwqgwdepfx Adrjbd EQUIPMENT - CNC control CINCOM M7 - Bar loader LNS Hydrobar Express 220 - Fire extinguishing system

Condition: good (used), Year of construction: 2014, operating hours: 17,300 h, functionality: fully functional, turning length: 200 mm, spindle speed (max.): 10,000 rpm, turning diameter: 20 mm, spindle bore: 26 mm, TECHNICAL DETAILS Control: Mitsubishi Main and counter spindle diameter: 20 mm Spindle bore: 26 mm Maximum machining length for long turning: 200 mm Maximum machining length for short turning: 50 mm Main spindle speed: 10,000 rpm Counter spindle speed: 8,000 rpm Rear side machining Rear block: with Y-axis Stations for rear side machining: 8 units Deep hole drilling stations on counter spindle: 6 units MACHINE DETAILS Operating hours: approx. 17,300 h Bar loading magazine: FMB Turbo 2-20 EQUIPMENT - Conversion kit D20 Ijdpfxjwhmrco Adrsbd - Müller CL3 high pressure system with 8-way switchable valves, 130 bar, and automatic backwash filter - Automatic fire extinguishing system Kraft + Bauer included Fire damper - Angle-adjustable driven holder 3-way

Condition: like new (used), Year of construction: 2018, functionality: fully functional, turning diameter: 20 mm, overall weight: 2,350 kg, For sale Citizen L20E-2M12 lathe with 3 meter bar feeder. Ibodpsvdyi Uofx Adred

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 20 [mm] - Max. machining length : 200 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 3,7 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 1.5 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 10 - Number of motorized positions : 5 - Live tools speed : 5000 [rpm] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 3 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2.110 x 1.085 [mm] - Machine height : 1.832 [mm] Ibjdpsuhazgefx Adred - Machine weight : 2.200 [kg] MACHINE HOURS - Number of working hours : 32.264 [h] EQUIPMENT - CNC : Meldas - Rotating guide bush - Parts catcher - Parts conveying strip - Ejection of workpiece - Chips conveyor - Coolant tank * with high-pressure pump - Bar loader : FMB MINIMAG 20
