Weldnig positioner

CORMAK PS-500

CORMAK PS-500 Welding Positioner

The CORMAK PS-500 welding positioner is a versatile auxiliary device designed for a wide range of production applications. Its extensive capabilities make it an excellent solution wherever precise manipulation of components is required.

The welding, painting, and mechanical industries appreciate the quality, durability, and functionality of CORMAK positioners. These devices are the ideal choice for applications where components or assemblies need to be rotated, wound, or positioned.

Additionally, the machine is equipped with a tool holder adjustable in multiple planes, increasing its versatility and ease of use.

Main features
Rotation switch and direction selector – allow precise control of the rotary table rotation direction.
Smooth speed adjustment – enables adjustment of table rotation speed according to specific work requirements.
Compact construction – a robust and rigid design ensures durability and long service life.
Foot control pedal – provides convenient and precise operation control.
Thermal protection fuse – additional protection against overheating.
Brushed motor – efficient and versatile, suitable for various industrial applications.
Table tilt range of 0–90° – enables welding in different working positions.
Possibility of mounting a centering chuck – supports accurate positioning and alignment of components.
Universal grounding slot – allows connection of the welding ground without reconnecting it after each table rotation, improving convenience and work efficiency.
Advantages
Higher productivity – improves the efficiency of assembly and welding processes.
Reduced production costs – automated component rotation contributes to savings.
Repeatable weld quality – ensures consistent and uniform results.
Operational flexibility – adjustable speed and rotation direction make the device suitable for many applications.
Improved working conditions for welders – enables more comfortable and ergonomic working positions.
Standard equipment includes
PS-500 welding positioner
Foot control pedal
Power cable
User manual
Welding torch holder mast
Optional equipment
Self-centering three-jaw chuck for tubes WP400
Self-centering three-jaw chuck for tubes WP500
Technical specifications
Parameter Value
Horizontal load capacity 300 kg
Vertical load capacity 150 kg
Working table diameter Ø500 mm
Centering hole diameter 140 mm
Tilting angle 0° ~ +90°
Rotation speed 0.2 ~ 2.5 rpm
Motor power 200 W
Tilting speed Manual
Voltage 220 V – 1PH – 50 Hz
Dimensions 700 × 650 × 710 mm
Weight 97 kg

Note: The three-jaw chuck is not included in the standard package.

Dkjdsrigmgspfx Akhor
The CORMAK PS-500 welding positioner is an indispensable tool for the welding industry, significantly simplifying the rotation and positioning of components while improving work quality, efficiency, and operator comfort.

The WP400 and WP500 self-centering chucks are perfectly suited for the PS-500 welding positioner. These advanced solutions provide precise and stable component clamping, significantly improving welding quality and productivity. Choosing these chucks ensures comfortable operation and excellent results.
