Vertical Turret Lathe - Single Column

DÖRRIES VCE 2000/1800

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 Bsdpfx Aeq U R T Njh Iewi New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Total weight of the machine: 84.000 Kg

Condition: used, Technical details: faceplate diameter: 1000 mm swing diameter: 1600 mm turning height: 1200 mm main drive: 75 kW faceplate speeds from - to: 7 - 800 U/min milling motor: 25 kW milling head speed: 7 - 3000 U/min Bodpevb Dcaofx Ah Ijwi milling spindle - taper: ISO 50 cross rail adjustment - vertical: 800 mm ram head dimension: 240 x 240 mm weight of the machine ca.: 40 to dimensions of the machine ca.: 9 x 7,8 x 6,0 m Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor *

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of retrofit: 1996/1997 Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Main motor Siemens: 68 kW Spindle speeds: I gear: 3 - 202 rpm II gear: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Z travel: 2,400 mm (supporting sleeve □ 520 mm/travel 1200 mm + W axis 1200 mm) Mount: SK60 (SK50) Facing slide: yes Milling head: 2 units Prepared for CNC rotary table (4th axis) Without rotary table and clamping field (available separately) Full documentation Bjdpfxoqc Umgs Ah Iewi Net weight: approx. 140 tons Video available!

Condition: ready for operation (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, Bwjdpfxov I T Ewj Ah Iji 2 x 18” 3 point steadies, 24”/28” Steady.

Condition: ready for operation (used), controller model: Num, empty load weight: 35,000 kg, total length: 11,000 mm, total width: 2,950 mm, total height: 2,000 mm, swing diameter over cross slide: 6,500 mm, Robuuste draaibank met 4 geharde lineaire geleidingen Maximaal werkstukgewicht: 20 ton bestemd voor staalfabrieken, walsgieterijen, smederijen voor het maken van producten zoals turbinerotoren, grote assen en staafproductie Swing over bed: 1400 mm Swing over cross-slide: 1100 mm Power on the spindle: 81 kW Bwedpfx Ahswaiu Re Iji Chuck: 900 mm

Condition: reconditioned (used), Year of construction: 1998, operating hours: 44,675 h, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 140 mm, spindle speed (max.): 60,000 rpm, spindle speed (min.): 9,000 rpm, workpiece weight (max.): 800 kg, table width: 860 mm, table load: 1,500 kg, travel distance W-axis: 635 mm, Equipment: documentation/manual, Fully overhauled and in perfect condition as per original specifications and accuracy. 6 Axis X-Y-Z-C-U 7th axis CNC-rotary table with tailstock in option Control: Fanuc 15 MB Bodowb Db Uopfx Ah Iewi Grinding Spindle 60S speed 9,000 to 60,000 rpm Hi-Cut system with full enclosure CBN Form rotary dressing with Fischer spindle and Dr. Kaiser diamond wheel This machine is under power and can be seen in our facility in Gals, Switzerland Garantee of 6 months Shipment, installation and training can be provided

Condition: used, TECHNICAL DETAILS - Spindle speeds : 5 - 300 [rpm] - C axis indexing precision : 0.001 [°] - Vertical travel of the main spindle : 130 [mm] - Vertical travel of the main spindle (manual mode) : 140 [mm] - Rotational speed of the grinding spindle with motor : 4500 - 80.000 [rpm] - Rotational speed of the grinding spindle with turbine : 100.000 - 160.000 [rpm] - Cylindrical grinding without/with intermediate plate max. : 230 / 360 [mm] - Maximum grinding length Z (with block) : 125 [mm] - Maximum acute angle in conical grinding : 16 [°] - Maximum grinding depth in conical grinding with angle : 44 [mm] LINEAR AXES - Travels on X/Y/Z axes : 700 / 500 / 500 [mm] - Rapid traverses rates (X/Y) : 4000 [mm/min] - Cutting feed rates (X/Y) : 0 - 2000 [mm/min] TABLE - Table dimensions : 770 x 630 [mm] - Maximum weight upon table : 500 [kg] - Distance table / spindle nose (min./max.) : 0 - 600 [mm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2650 x 2577 [mm] - Machine height : 2677 [mm] - Machine weight : 5600 [kg] MACHINE HOURS - Number of working hours : 44995 [h] EQUIPMENT - CNC : Fanuc Bjdpfx Ahox Av Ade Ijwi - Coolant tank * with high-pressure pump * with paper filtering unit - Oil mist extractor - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, Max. turning diameter: 650 mm Min. turning diameter: 200 mm Max. turning length: 4000 mm Max. workpiece weight: 10 tons Bodjvk T S Ajpfx Ah Ijwi Center height: 400 mm Faceplate diameter: 650 mm Speed: 1 - 58.4 rpm Drive power: 45 HP Tailstock

Condition: used, Year of construction: 2013, Year 1978 Retrofit 2013 max. turning diameter 1300 mm table diameter 1000 mm workpiece height max. 1500 mm working lenght 1050 mm 280 U/min. T-slots 48 x 28 speeds 4,75 - 250 U/min rapid traverse 6000 mm/min In our opinion, the machine is in good used condition and can be inspected condition and can be inspected under power by appointment. Retrofit 2013 Precision class: IT7 Technical features - 4-fold swivel head Accessories, illustrated tools and clamping devices are only included in the scope of delivery Bwedpfxjxmk E Uo Ah Isi if this is noted in the additional information . Changes and errors in the technical data and information as well as prior sale reserved. subject to prior sale

Condition: new, Year of construction: 2025, functionality: fully functional, turning height: 1,600 mm, turning diameter: 2,000 mm, CNC Vertical Turning Center Model: VTC-16/20R with Fanuc 31i-B Table Diameter: Ø1,600 mm Max. Swing Diameter: Ø2,000 mm Max. Turning Height: 1,600 mm Table Speed: Max. 250 rpm Table Load Capacity: 8,000 kg Table Indexing Speed: 720°/min Table Indexing Accuracy: 0.001° X-Axis (Ram horizontal): -100 mm to 1,170 mm Z-Axis (Ram vertical): 900 mm Drive Spindle Speed: Max. 2,000 rpm Ram Size: 240 mm x 240 mm Milling Spindle Taper: ISO 50 Tool Shank Size: 40 mm x 40 mm Crossrail (vertical travel): 250 mm x 3 stages (hydraulic) Table Drive Motor: AC 37/45 kW (continuous/30 min. duty) Milling Spindle Drive Power ISO 50: 15/18.5 kW (continuous/30 min. duty) Bjdjxp Nb Tspfx Ah Iowi Control System: Fanuc 31i-B Display Unit: 15-inch TFT-LCD Memory Capacity: 1 MB Automatic Tool Changer: 24 positions (for 7 turning tools + 1 cover + 16 milling tools) Standard Tool Holders: New 240 TCR-01 (2 pcs) Splash Guard: Table version (R-Type standard design) External Coolant System: 3 bar (80 l/min) Chip Conveyor: Hinged belt type Table Bearing Cooling Device 4-Jaw Independent Manual Chuck Foundation Anchor Bolts / Base Plates Maintenance Tools and Toolbox Hydraulic Power Unit Work Area Lighting Signal Lamp: 3 colors (green, red, yellow) Operating Manuals (English): 1 CD with Fanuc manuals and 3 books with mechanical/electrical manuals Power Supply: 220 V, 60 Hz, 3-phase Machine Color: Manufacturer standard OPTIONAL ACCESSORIES (#1) Turning Tool Holder: Type 240TCR, 4x included Rigid Tapping: 1x included OPTIONAL ACCESSORIES (#2) Automatic power-off for N.C. - on request Turning tool holder type 240TCR - on request Through-spindle coolant supply: 30 bar (pump pressure) - on request Transformer 415 V, 50 Hz, 3-phase - on request Linear scales X-, Z-axis (Fagor, Spain) - on request Workpiece measuring device - on request Tool measurement TS27R, Renishaw - on request Other information: INSTALLATION, COMMISSIONING, TEST OPERATION, AND TRAINING - not included in the price INSURANCE AND FREIGHT - not included in the price Image shows machine with pallet changer. The offered machine DOES NOT INCLUDE A PALLET CHANGER! Errors in technical data excepted. The scope of accessories is as described in the text of this article only. There is no entitlement to any other accessories, such as those shown for illustration purposes. The general terms and conditions of JS-Werkzeugmaschinen GmbH apply.
