DECKEL MAHO DMC 70H duoBlock

DECKEL MAHO DMC 70H duoBlock

Condition: ready for operation (used), Year of construction: 2007, operating hours: 32,510 h, functionality: fully functional, machine/vehicle number: 11670000823, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, rotational speed (max.): 10,000 rpm, number of slots in tool magazine: 180, TECHNICAL DETAILS X-axis travel: 800 mm Bedpfx Ahexf Htxj Iswi Y-axis travel: 800 mm Z-axis travel: 800 mm Drive: Variable-speed asynchronous motor with liquid cooling Control: Sinumerik 840D powerline Work spindle Tool holder: HSK-A63, hydraulic-mechanical tool clamping Spindle speed: 0 – 10,000 rpm, continuously programmable Feed Drive: AC brake motors on the X, Y, Z, and B axes Feed range on the X, Y, and Z axes: 0 – 60,000 mm/min Rapid traverse on the X, Y, and Z axes: 80 m/min Measuring system Resolution on the X, Y, and Z axes: 0.001 mm Position tolerance on the X, Y, and Z-axis: 0.008 mm Pallet Number: 2 Size: 630 × 630 mm Hole pattern: 108 × bushing Ø 16.02 H6 Centering bushing: Ø 16.02 H6, 38.5 mm deep NC rotary table Max. tabletop rotation: 30 rpm Tabletop holding torque at 40% duty cycle: 5,000 Nm Tabletop holding torque at 100% duty cycle: 3,250 Nm Workpiece weight Per pallet: max. 800 kg Difference with different loads: max. 800 kg Tool magazine Type: Vertical chain magazine HSK-A63 Positions: 180 Tool changing system: Double gripper Max. tool diameter standard: 80 mm Max. tool diameter with free adjacent positions: 160 mm Max. Tool length from spindle nose: 550 mm Max. tool weight: 12 kg Max. magazine load: 630 kg MACHINE DETAILS Space requirement: 6.0 x 6.0 m Height: 3.2 m Weight: 18 t Power requirement: 71 kVA Machine dimensions: approx. 4.7 x 5.6 x 3.2 m EQUIPMENT - Internal coolant supply - Chip conveyor - Belt filter system - Cooling unit - Rotoclear - Tool breakage detection (laser) - Mist separator - Measuring probe - Handheld control unit - Flushing gun - Blow-air cooling system - 4-color signal lamp - Dynamic package

Year of construction: 2006, operating hours: 44,825 h, condition: excellent (used), functionality: fully functional, machine/vehicle number: 1167000036, TECHNICAL DETAILS X-axis travel: 700 mm Y-axis travel: 800 mm Z-axis travel: 800 mm B-axis: 360º B-axis step size: 0.001º Bwjdpslu Ex Rjfx Ah Isi spindle speed: max. 10.000 rpm spindle drive power: 30/20 kW (40%/100% ED) CNC control: SIEMENS 840D Powerline ShopMill Classic number of pallets: 2 pallet dimension: 500 x 500 mm workpiece diameter: 800 mm workpiece height: max. 1.350 mm tool holder: SK-40 number of tools in magazine: 45 MACHINE DETAILS hours under power: 64.431 h Spindle working time: 44.825 h Total power consumption: 60 kVA Supply voltage: 400 V / 50 Hz Connected current: 100 A Coolant supply: 40 bar Tank capacity: 980 l EQUIPMENT - chip conveyor - rotating sight glasses - operating mode 4 - high pressure pump - Laser tool measurement for measuring tool length and diameter - Prepared for HEIDENHAIN probe
