2005 Deckel Maho DMC75V linear

Deckel Maho DMC75V linear

Condition: used, Year of construction: 2007, x-travel 885 mm y-travel 600 mm z-travel 600 mm control iTNC 530 Heidenhain Max. rpm 1 - 28.000 min/-1 power capacity - main spindel 35 / 25 kW max. Torque 119 / 85 Nm tool taper HSK A63 Swivel range milling spindle B: -10° / +110° ° spindle bearing diameter 80 mm table diameter 750 mm rotation range C: 360 ° rotary speed max. 100 min/-1 max. table load 600 kg feed speeds 1 - 90.000 mm/min rapid traverse 90 m/min Feed force X/Y: 13,8 kN Feed force Z: 10,35 kN Dodpfetqmpiox Aghsku number of toolpositions 30 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 140 mm max. tool length 300 mm max. tool weight 10 kg max. workpiece height 460 mm Max. Workpiece Area ca. 750 x 600 mm passage max. 600 mm total power requirement 60 kVA weight of the machine ca. 12 t dimensions of the machine ca. 4,5 x 4,5 x 3,0 m CNC-Machining Center Vertical DECKEL MAHO - DMC 75 V linear - 5-Axis-Machining - NEW SPINDLE from 12/2022 ! - Swiveling Milling Spindle (-10° / 110°) - Rotary Table 360° - extensive tool package - only approx. 900 spindle hours (after exchange) - WITHOUT clamping devices, WITHOUT exhaust!

Year of construction: 2006, condition: ready for operation (used), Travels X/Y/Z: 885mm/600mm/600mm, travels B/C: -10° - 110°/360°, rapid traverse X/Y/Z: 9000mm/min, speed: 28000rpm. Table dimensions X/Y: 950mm/650mm, operating hours: 90711h, spindle hours: 19457h. Including workpiece measuring probe, tool changer with 100 places. Dksdpfxeta H S So Aghou

Condition: used, Year of construction: 2005, x-travel 750 mm y-travel 560 mm z-travel 600 mm Control HEIDENHAIN iTNC 530 total power requirement 70 kW weight of the machine ca. 11.000 kg dimensions of the machine ca. m D E C K E L M A H O (Germany) Vertical CNC Machining Centre with high speed linear drives in 3 Axis and in double column design for high precision work Model DMC 75 V LINEAR Year 2005 _____ Working range: Longitudinal stroke X Axis 750 mm Vertical stroke Z Axis 600 mm Cross stroke Y Axis 560 mm Table clamping size 950 x 650 mm Max. Table load 1.000 kg Max. height of workpiece 600 mm Tool holder Cone HSK 63 Spindle (KESSLER) speeds 18,000 rpm Torque, max. 86/130 Nm Spindle run-up time / stop time 3.2 sec Feeds / Quickfeeds, X, Y and Z Axes max. 90,000 mm/min Feed force 11.000/9.500 N Axis acceleration, X / Y / Z Axes 15 / 12 / 18 m/s Spindle drive 25/35 kW Total electrical load, approx. 75 kW - 400 V - 50 Hz Weight, approx. 11.000 kg Accessories / Special Features: This machine is very interesting because of the very stable double Column Portal Design and with the modern linear technology for fast and powerful high precision work. * HEIDENHAIN modern CNC Control System Model iTNC 530 in 3 axes, with all Djdpjt Hw Trefx Aghoku the usual options, cycles and sub programmes. * Table moves only in x axis and allows a comfortable loading of heavy workpieces * 30-position disktype tool magazine for max. tool Ø 100, 140 and 200 mm x max. length 300 mm. Max. weight 10 kg. Cut-to-cut time 6 sec. Pick-Up by main spindle. * BLUM tool-breakage control, Blum Receiver for RENISHAW –Head, no head available. * Double linear motors ensure very fast feed motions and strong feed power, equipped with own cooling system. * KESSLER Milling Spindle, Liquid-cooled, steplessly programmable up to 18.000 rpm * Completely covered working area with 2 sliding doors, one with spin-type bull-eye. * KNOLL Coolant device with scraper-type chip conveyor and pressure pomp. * Spindle working hours approx. 23.000 h Condition : Very good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: ready for operation (used), Year of construction: 2005, operating hours: 69,995 h, Control Unit Brand HEIDENHAIN TNC 530 Main Drive Number of axis 3 Movement X-Axis Movement 885 mm Y-Axis Movement 600 mm Z-Axis Movement 600 mm Table Table load 600 kg This 3-axis DECKEL MAHO DMC 75 V Linear was manufactured in 2005. It features a travel range of 885 x 600 x 600 mm and a maximum feed speed of 90 m/min. The machine includes a high-capacity coolant system and an efficient scraper belt conveyor for swarf disposal. If you are looking to get high-quality milling capabilities, consider the DECKEL MAHO DMC 75 V machine we have for sale. Contact us for more information. Dodpfev A Amgox Agheku Application Types Milling

Condition: excellent (used), Year of construction: 2005, operating hours: 18,436 h, functionality: fully functional, travel distance X-axis: 885 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, swivel angle B-axis (min.): -10 °, swivel angle B-axis (max.): 110 °, No reserve price - guaranteed sale at the highest bid! TECHNICAL DETAILS X-axis: 885 mm Y-axis: 600 mm Z-axis: 600 mm Rotary axes: B-axis -10° to +110°, C-axis 360° Feed, dynamics and tool holder Maximum feed rate: 90 m/min X-axis acceleration: up to 15 m/s² Y-axis acceleration: up to 12 m/s² Z-axis acceleration: up to 18 m/s² Tool holder: HSK-A63 Table and load NC rotary table diameter: 750 mm Maximum load: 600 kg Cooling lubricant system & chip conveyor Container capacity: 500 liters Coolant supply: 40 l/min at 2.3 bar Chip disposal: Efficient scraper belt conveyor (Discharge height 850 mm) MACHINE DETAILS Operating hours: 18,436 h Switch-on time: 46,702 h Rated power: 73 kVA Rated current: 105 A Operating voltage: 400 V Dsdpsvrxcpsfx Aghoku Operating pressure: 6 bar Compressed air connection delivery rate: 30 Nm³/h Submitting a bid obliges you to collect the machine on time by February 19, 2025!

Condition: used, Year of construction: 2006, x-travel 750 mm Dodpfx Aevxwxiegheku y-travel 600 mm z-travel 560 mm Control SIN840D pl table-size 950 x 650 mm workpiece weight max. 1.000 kg feed X/Y/Z/-axis 1 - 90.000 mm/min rapid traverse X/Y/Z 90,00 m/min spindle turning speed - stepless 1 - 18.000 U/min power capacity at 100 % load 25,00 kW power capacity at 40 % load 35,00 KW tool taper HSK-A63 tool magazin: 30 tool diameter 80 mm tool diameter with 2 vacant positions 140 mm tool length - max. 300 mm weight of tools max. 10,00 kg total power requirement 58,00 kW weight of the machine ca. 11,00 t dimensions of the machine ca. 7,00 x 4,00 x H3,50 m Control SIEMENS Sinumerik 840D powerline with ShopMill, EROWA pallet system MTS500, tool breakage control, coolant-unit, coolant through the spindle (23 l/min at 40 bar), chip conveyor, electronic handwheel
