Tool milling machine

Deckel FP1

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, Technical details x-travel 300 mm y-travel 160 mm z-travel 290 mm table surface area 600 x 210 mm tool taper SK 40 spindle turning speed range (16) 40 - 2000 U/min Ncsdjymln Sspfx Aaqen feeds -stepless- 5 - 500 mm/min rapid traverse 1,2 m/min spindle motor 1,5 / 1,9 kW total power requirement 9,5 kVA weight of the machine ca. 830 kg dimensions of the machine ca. 2000 x 2200 x 1655 mm Additional information The machine is in very good condition and comes from a training workshop. Equipment: * 3-axis positioning control with active digital display Heidenhain TNC 123 - Manual mode: Manual operation and positioning with manual input - Automatic mode: Single-block programme run, programme storage * Fixed angle table * Movable vertical milling head, swivel range +/- 90 degr., quill stroke 60 mm * Coolant equipment * Central lubrication * Tailstock with counter bearing * Manual

Year of construction: 1974, condition: like new (used), As good as new Deckel FP1 tool milling machine overhauled by FPS with 3-axis Heidenhain digital readout , Adjustable angle table , SK 40 spindle mount. Spindle brake , accessories : Counter holder , various collets. Very good working condition, can be demonstrated under power by arrangement. Ncodpfx Aeq A Icqsaqsn

Condition: used, Year of construction: 1980, x-travel 300 mm y-travel 160 mm z-travel 340 mm tool taper SK40 Speed 40-2000 U/min. Nedpfx Aew A Apyeaqocn control Aktiv HEIDENHAIN table-size 600 x 210 mm total power requirement 2 kW weight of the machine ca. 0,73 t dimensions of the machine ca. TBH 1200x1100x1600 m - Active feed in the X and Z axes - Additional swiveling table 600 x 210 mm - Coolant system - Counter bearing for horizontal milling - Several fixtures and clamping devices/milling cutters - Operating instructions

Condition: used, Year of construction: 1980, x-travel 300 mm y-travel 160 mm z-travel 340 mm tool taper SK40 Speed 40-2000 U/min. control Aktiv HEIDENHAIN table-size 600 x 210 mm total power requirement 2 kW weight of the machine ca. 0,73 t dimensions of the machine ca. TBH 1200x1100x1600 m - Active feed in the X and Z axes - Additional swiveling table 600 x 210 mm - Coolant system Ncodpfow A Ap Hox Aaqsn - Counter bearing for horizontal milling - Several fixtures and clamping devices/milling cutters - Operating instructions

Condition: used, Universal tool milling machine DECKEL type FP 1 Machine no.: 52185 Year of manufacture: 1968 Travel X: 300 mm Y: 150 mm Z: 340 mm Table size: 600 x 250 mm Spindle taper: SK 40 - S20 x 2 Spindle speed: 40-2000 rpm, 16 steps Motor power: 1.0 and 1.4 kW, pole-switchable Mains connection: 380 Volt, 50 Hz - Feed on X and Z axes - Two motor speeds and 8 gearbox speeds - Quill stroke on vertical milling head: 60 mm - Fixed angle table - Coolant system in the machine base Njdpedzqb Sjfx Aaqocn - Free-standing control cabinet - Counter support with counter bearing for horizontal milling SK 40 Required space (L x W x H): 1200 x 1100 x 1600 mm Weight: approx. 1000 kg Very good condition

Condition: used, Univ. tool milling machine DECKEL type FP 1 Machine No. 28317 Year of construction approx. 1960 travel X: 245 mm Y: 150 mm Z: 340 mm table size 600 x 210 mm spindle admission horizontal MK 4 - S20 x 2 spindle speed vertical 95-1900 rpm. 12 steps Spindle speed horizontal 60-1200 rpm. 12 steps motor power 0,8 and 1,1 kW pole-changing Mains connection 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and 6 gear steps - feed in X- and Z-axis - Coolant device with mechanical pump in machine base Ncsdpfx Aajiy Ekvsqjn - Pinol shift at vertical milling head 60 mm - vertical milling head +/- 90° tiltable - Metal base made of angle iron with machine feet space requirement L x W x H 1100 x 900 x 1650 mm weight 650 kg good condition

Condition: used, Universal tool milling machine DECKEL type FP 1 Machine No. 33064 Year of manufacture approx. 1960, overhauled in 2012 Travel X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: MK 4 - S20 x 2 Vertical spindle speed: 95–1900 rpm, 12 steps Horizontal spindle speed: 60–1200 rpm, 12 steps Motor power: 1.1 and 1.4 kW Ncsdpfx Aaedzp T Eoqsn Power supply: 380 Volt, 50 Hz - Feed on X and Y axes - Quill adjustment on the vertical milling head - Fixed angle table - Coolant system with mechanical pump in the machine base - Separate control cabinet with cable connector Space requirement L x W x H: 1100 x 900 x 1600 mm Weight: approx. 900 kg Good condition Machine was overhauled in 2012

Condition: excellent (used), Tool milling machine DECKEL FP 1, three-axis digital readout TNC 113, from educational institution - CE marking - Travel X / Y / Z 300x160x340 mm - Heidenhain TNC 113 / plug-in control - Spindle speed range 40 - 2000 rpm - Infinitely variable feed in all three axes - Rapid traverse in all three axes - Vertical head adjustable by 100 mm - Vertical-horizontal milling facility - Tool holder ISO 40 - Drive power 1.5 / 1.9 kW - Fixed angle table - Chip tray Ncedpoyln Irefx Aaqen - Coolant system - Work light - Documentation Dimensions: LxWxH 1.3x1.2x1.7 m / Weight: 950 kg Errors and omissions excepted

Condition: excellent (used), Deckel FP1 AKTIV (3-Axis Active) Machine no.: 2102-3240 Year of manufacture: approx. 1988 Travel paths: X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2,000 rpm Motor power: 1.6 and 2 kW Power supply: 380 V, 50 Hz Equipment/Accessories: - Active digital readout, 3 axes, HEIDENHAIN type TNC 113 - Infinitely variable feed in X, Y, and Z axes - Vertical milling head quill travel: 60 mm - Vertical milling head swivels and extends 100 mm horizontally - Coolant system (coolant tank in machine base) - Documentation - Central lubrication system - Machine vice - Various toolholders/collets/tools Space required (L x W x H): 1,350 x 1,100 x 1,700 mm Weight: 850 kg The machine has been visually reconditioned and technically inspected. Geometry inspection videos can be provided upon request. Backlash Y axis: 0.1 mm Ncsdpfxoyll A Ts Aaqen Backlash X axis: 0.2 mm Backlash Z axis: 0.15 mm Runout horizontal spindle: 0.001 mm Runout vertical spindle: 0.001 mm Parallelism deviation Y axis: 0.002 mm (measurement path: 150 mm) Parallelism deviation X axis: 0.01 mm (measurement path: 300 mm) Geometry inspection videos can be provided upon request. The following parts have been renewed: - Gears in horizontal head replaced and gear shaft newly mounted - New guide cover for Z axis + various attached parts - Machine refurbished - New LEDs installed - Y-axis chain tensioner overhauled - Reference point programming checked - Function test carried out

Condition: excellent (used), functionality: fully functional, spindle mount: MK 0, Accessory device for milling machine Deckel FP 1 The slotting head is suitable for keyway slotting operations on the milling machine. It is suitable for planing operations in the vertical direction (Z-axis) on the milling machine. The slotting head can be swiveled 360 degrees. The stroke of the ram is adjustable from 0 mm to 80 mm. Number of strokes: 16 to 200 strokes per minute. Tool holder approx. 16 x 16 mm. Accessories: 5 slotting tools with widths of approx. 5 mm, 7 mm, 9 mm (tool shank 16 x 15 mm). The slotting head is used. This is an original Deckel accessory device. The unit was only used by us for precision work. The slotting head is in very good condition. Weight: approx. 30 kg Price: Ex works, VAT can be shown separately. Payment: Invoice with VAT indicated. Payment upon collection or in advance. Delivery: Shipping via a parcel service is possible. Self-collection is possible. Terms of delivery: We deliver according to the Machineseeker standard contract, Standard purchase contract for used machinery from Machineseeker. A standard contract can be downloaded from Machineseeker. Ncedpfsyk In Nex Aaqon Delivery time: Available immediately.

Condition: used, Universal Milling Machine DECKEL FP1 Travel X: 300 mm Travel Y: 150 mm Travel Z: 300 mm Horizontal + vertical spindle Cone SA40 DECKEL Spindle speed: from 40 to 2000 RPM Table size: 600 x 210 mm Horizontally tiltable head Straight table Ncedpfoxxpp Nsx Aaqen Spindle motor: 2 speeds Motor: 1,3 kW Feeds: X - Z auto / Y manual Voltage: 380 V Width: 1200 mm Depth with electrical panel: 1200 mm Height:1600 mm Weight: approx 900 kg
