Universal milling machine

DECKEL FP4 M

Condition: good (used), Year of construction: 2021, functionality: fully functional, Internal article number: 26082 Universal milling machine Deckel FP4M Overhauled by FPS in 2021 + Hydraulic machine vice, Röhm 135 Tsdpfx Aezxgy Sontob + Machine lamp / protective cover + Operating manual Dimensions (L x W x H): 140 x 210 x 200 cm Weight: approx. 1500 kg The machine comes from a training workshop and is in very good condition.

Condition: used, machine/vehicle number: 2820-0419, x-travel:500 mm y-travel:400 mm z-travel:400 (340) mm table surface area:710 x 430 mm turning speed range:40 - 4000 U/min feed range:02 - 3600 mm/min rapid feed:4,0 m/min milling-head swivable +/-:90° quill stroke:80 mm spindle taper:SK 40 control:Contour 3 total power requirement:5,5 kW weight of the machine ca.:1,9 kg dimensions of the machine ca.:2 x 1,4 x 1,8 m Deckel Model FP3 A - Spilndle Head can be swiveled 90 ° (Left of Right) - Universal tilting rotary swivel table (Size - 710 x 430 mm - Deckel Contour 3 CNC control Systems. - Hydralic Tool clamping system SK40 with Pull studs DIN 2080 or DIN 69872 - Portable Electronic Handwheel for All Axis Control Tsdpfxeh Ra Nie Antjb Central Lubricant system, Chip tray with Splash cabin will provide complete protection, clean and safe working Area.

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Universal milling machine Deckel FP4M with 3-axis digital display Heidenhain in special light gray paint!!! Technical data: >> Year of manufacture 1986, machine no. 2203-2308 >> Fixed angular table >> Speed: 50 - 2500 RPM >> Feed rate: 8 – 630 mm/min >> Drive power: 3.7 / 4.4 kW >> Spindle brake >> Rapid traverse rate: 1300 mm/min >> Travels X/Y/Z: 500/400/400 mm >> Vertical milling head on spindle head, adjustable by 150 mm >> Vertical quill and horizontal quill - SK40 >> Vertical quill extendable by 90 mm >> Clamping system M16 >> Weight approx. 1500 kg Accessories and equipment: Tsdpfxozv Sdqj Antsb >> 3-axis digital display Heidenhain >> Coolant system >> Chip tray >> Central lubrication About the machine: Offered is a Deckel FP4M universal milling machine in very good condition. The machine has little backlash and all spindles can be moved easily and smoothly. Even at maximum speeds, the milling machine runs smoothly. Rapid traverse in all axes. A reliable and user-friendly machine. An oil change has been performed. Mechanically and electrically inspected. The Heidenhain digital display makes the work easier and even more precise. Take advantage of the opportunity to inspect and test the machine on site while it is powered up. CE marking available for an additional charge.

Condition: used, Year of construction: 1987, FRIEDRICH DECKEL PRECISION MILLING MACHINE MODEL: FP4M YEAR: 1987 approx. HEIDENHAIN DIGITAL READ OUT CLEAN Todpezv Eg Sefx Antob

Condition: new, Universal tool milling machine according to DIN 8615. The torsion-resistant machine stand made of MEEHANITE® quality casting and the high-precision, hardened and ground guides in all axes guarantee high precision and durability. With the 3-axis digital display, all values can be called up directly and with the user-friendly control panel on the jib arm (OPTION), it can be positioned individually. Clamping area of the fixed angle table: 900 x 500 mm Max. Workpiece weight: 360 kg Horizontal and vertical tool holder: ISO 40 Main spindle motor power / 100% ED: 3.75 kW Power feed motors X/Y/Z-axis: 1.0 / 1.0 / 1.5 kW Total connected load: 7.4 kVA Tsdpjuxt N Iofx Antjb Speed range: 40 - 3800 1/min Speed steps: 18 Manual drill sleeve stroke: 120 mm Swivel range: +/- 90 Travel X (automatic/manual): 600 mm Travel Y (automatic/manual): 460 mm Z travel (automatic/manual): 380 mm Feed range, infinitely variable X/Y/Z: 10 - 650 mm/min Rapid traverse: 1000 mm/min Dimensions LxWxH, approx.: 1850 x 1650 x 1900 mm Weight, approx.: 1780 kg Equipment: - 3-axis digital display (e.g. FAGOR® Innova), with various comfort functions, on user-friendly swivel arm (OPTION) - DC servo motors for all X/Y/Z axes, e.g. from DELTA® - Spindle concentricity max. 0.005 mm, incl. test report to DIN 8615 (SKF®/NSK® roller bearings) - Spring-loaded safety handwheels in all axes, e.g. from GANTHER® - Torsion-free machine bed made of MEEHANITE® quality casting - High-precision, hardened and ground guideways in all axes with TURCITE®-B coating - Backlash-free HIWIN® precision ball screws in all axes - Electrical overload protection in all axes - Multi-adjustable spindle protection device secured via micro limit switch - Automatic interval central lubrication - Drilling quill - Swivel-mounted control panel on extension arm (approx. 1,600 mm) (OPTION) - Hydraulic tool clamping - SIEMENS®, BALLUFF® electrical equipment - Coolant device - Horizontal device - LED machine light - Spacious chip collection tray - Test report according to DIN 8615 - Operating tool - Operating instructions, spare parts list, incl. electrical circuit diagrams etc. in German - CE

Condition: excellent (used), Year of construction: 1986, X-axis: 500 mm Y-axis: 400 mm Z-axis: 400 mm Tool holder: SK 40 Drive power: 8.1 kW Tjdpfxezkhubj Antjb Includes Heidenhain 3-axis digital display Includes various tools Includes machine vise Includes rotary table Includes additional angled milling head

Condition: like new (used), Year of construction: 2022, functionality: fully functional, Universal milling machine DMG FP4M Special Edition With 3-axis digital display ND7013 by Heidenhain, in new condition, Made in Germany, CE compliant!!! Technical data: >> Year of construction 2022 >> Fixed angular table, clamping area 480x800 mm >> Spindle drive, speed range 25-3000 rpm, stepless adjustment with input on the control panel >> Controlled main drive 6 kW >> Vertical milling head, swiveling +- 90 degrees (180 degrees) >> Linear axes, feed range 6-500 mm/min >> Rapid traverse 1500 mm/min >> Space requirement (W+D) approx. 2.2 x 1.9 meters >> Weight approx. 1600 kg Accessories and equipment: >> Heidenhain digital display ND 7013 >> Coolant system >> Minimum quantity lubrication >> Central lubrication >> Machine feet >> Operating manual, etc. About the machine: Tsdpfezung Esx Antob Offered is a universal milling machine DMG FP4M Special Edition with a 3-axis digital display by Heidenhain ND 7013, in new condition. A reliable and user-friendly machine, Made in Germany. An oil change has been performed. Mechanically and electrically inspected. Take the opportunity to inspect and test the Deckel machine on-site while it is powered on.

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 50 rpm, quill stroke: 90 mm, Dear Sir or Madam, We hereby offer you a very well-maintained milling machine of the type Deckel FP4M (K) aktiv, featuring a rotary-tilt-swivel table and a 4-axis digital readout. With its extensive equipment, this model truly stands out among conventional machine tools. The machine has been thoroughly inspected in our workshop, is therefore in excellent condition, and is immediately ready for operation. We look forward to your inquiry! Delivery time: Immediately available Machine No.: xxxx-xxxx Year of manufacture: xxxx Table version: Rotary-tilt-swivel table Spindle speed: 50 - 2500 rpm Feed rate: 8 - 630 mm/min, infinitely variable Rapid traverse: 1300 mm/min Drive power: 3.7kW / 4.4kW Travel (X/Y/Z): 500/400/400 mm Tool holder: SK40 Clamping system: hydraulic Vertical quill stroke: 90 mm Weight: approx. 1600 kg Further features and accessories include: 4-axis digital readout (Heidenhain), 3-axis active control, hydraulic tool clamping, rotary-tilt-swivel table, coolant system, machine feet, operating manual, and much more upon request... Our service promise to you: - We are a certified master workshop in mechanical engineering - All machines are thoroughly checked - All lubricants and any worn parts are replaced beforehand - Upon request, we can completely or partially overhaul the selected machine - You are free to choose the paint color of your selected machine - If desired, you can order additional accessories such as tools, etc. directly - On request, we can install other accessories such as safety devices Tsdjvvtlgjpfx Antob - We are happy to take care of shipping and/or installation

Condition: ready for operation (used), Year of construction: 1984, functionality: fully functional, feed length X-axis: 500 mm, feed length Y-axis: 400 mm, feed length Z-axis: 400 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, rotational speed (max.): 2,500 rpm, rotational speed (min.): 50 rpm, input voltage: 400 V, Deckel FP4M Universal Milling Machine in excellent technical and optical condition. Tjdpfx Anoytb Uhstjb Machine no. 2203-1389 Year of construction: 1984. Technical specifications: - Working travel X/Y/Z: 500/400/400 mm - Spindle speed range: 50 - 2500 RPM - Power: 3.7 / 4.4 KW - Spindle brake - Automatic feed: X-Y-Z, continuously adjustable, 6.3 / 630 mm/min - Rapid traverse X-Y-Z: 1300 mm/min - Fixed angle table - Vertical quill with 90 mm stroke - Tool holder: ISO 40/M16 - Weight approx. 1500 kg Machine options: - 3-axis digital readout Heidenhain - Coolant system - Chip tray - Central lubrication - Automatic pulse lubrication on the milling head - Machine manuals with spare parts list and electrical diagrams - Cabinet with accessories, see photos

Condition: good (used), Year of construction: 1987, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, total height: 2,100 mm, total width: 2,100 mm, total length: 2,200 mm, overall weight: 1,800 kg, workpiece weight (max.): 400 kg, 3 Axis digital read out Active digital read out Fixed table 800 x Central lubrication Coolant system with pump X-Axis: 500mm Y-Axis: 400mm Z-Axis: 400mm Table Length: 800mm Table Width: 460mm Table load: 400 Spindle speeds: 2500Rpm Feed rate X-Axis:1300mm/min. Feed rate Y-Axis:1300mm/min. Feed rate Z-Axis:1300mm/min. Stroke pinole: 90mm Length: 2200mm Width: 2100mm Height: 2100mm Weight: 1800kg Tjdpszdf Efofx Anteb Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Universal Milling Machine Deckel FP4M with 3-Axis Active Digital Readout Heidenhain, Excellent Condition, CE Compliant!!! Technical Data: - Year of manufacture: 1992, Machine no. 2203-8449 - Fixed angle table - Spindle speed: 50 - 2500 rpm - Feed rate: 8 – 630 mm/min - Drive power: 3.7 / 4.4 kW - Spindle brake - Rapid traverse: 1300 mm/min - Travel (X/Y/Z): 500/400/400 mm - Vertical milling head traverseable on column - Vertical and horizontal quill - SK40 taper - Vertical quill extendable by 90 mm - Hydraulic drawbar system - Approx. weight: 1600 kg Equipment and Accessories: - 3-axis active Heidenhain digital readout - Coolant system - Chip tray Tjdpfeu Tuk Hsx Antjb - Central electric lubrication - Operating manual, spare parts drawings About the Machine: For sale is a Deckel FP4M Universal Milling Machine (Active) in very good condition. The machine has minimal backlash, and all slides move smoothly. Even at maximum spindle speeds, the milling machine runs quietly. The machine features hydraulic tool clamping. The FP4M was only occasionally used in a state-run facility for training purposes. On this newer FP4 model, the feed rates are steplessly adjustable in all three axes, and each axis also features a rapid traverse. A major advantage is the active 3-axis digital readout. With the Heidenhain control, you can input measurements that the machine will approach automatically. Oil change has been performed; mechanically and electrically tested. The Heidenhain digital readout makes work easier and even more precise. Take advantage of the opportunity to inspect and test this machine under power on site.

Condition: good (used), Year of construction: 1984, functionality: fully functional, Travel range X: 500 mm Travel range Y: 400 mm Travel range Z: 400 mm Spindle speed: 31.5 – 2000 rpm Tool holder: SK 40 with S20x2 draw-in thread Table type: Fixed table Table clamping surface: 700 x 330 mm Weight: 1600 kg Dimensions: approx. 1700 x 1300 x 1900 mm Tedpfx Aezi Uy Uentsb Paint finish: RAL 6011 Reseda green Digital display: 3-axis HEIDENHAIN Accessories: Central lubrication, coolant tank, other accessories available upon request.
