Bottom block P DH PK DK DC

Demag

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 130 mm, ejector force: 139,000 N, opening stroke: 1,030 mm, plate width: 1,500 mm, plate height: 1,620 mm, TECHNICAL DETAILS Clamping force: 8,000 kN Plate size (h x v): 1,620 x 1,500 mm Clear width between tie bars (h x v): 1,120 x 1,000 mm Mold height: 500 - 1,050 mm Maximum plate distance: 2,080 mm Opening stroke: 1,030 mm Ejector stroke: 350 mm Ejector force: 139 kN Mold weight: 7,200 kg Dodpfx Asy T Hz Ijktokn Injection system Screw diameter: 130 mm Displacement: 7,300 cm³ Injection weight (PS): 6,640 g Injection pressure: 1,300 bar Screw length: 20 l/d Electrical and hydraulic equipment Rated power of pump motor: 110 kW Heating power: 79 kW Oil tank capacity: 1,300 L MACHINE DETAILS Machine dimensions LxWxH: 12.3 m x 2.7 m x 2.7 m Total weight: 33,500 / 9,700 kg

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 8673 0023, clamping force: 15,000 kN, screw diameter: 145 mm, injection pressure: 1,454 bar, plate width: 1,880 mm, plate height: 2,150 mm, Regularly maintained machine - see repair history TECHNICAL DETAILS Clamping force: 15,000 kN Mounting plate dimensions (H x V): 2,150 mm x 1,880 mm Clear distance between columns (H x V): 1,500 mm x 1,250 mm Min./Max. mold height: 700 mm - 1,400 mm Maximum opening distance: 2,900 mm Control: DIAS Injection unit Screw diameter: 145 mm Injection volume: 10,981 cm³ Injection weight: 9,880 g Injection pressure: 1,454 bar Electrical and hydraulic equipment Rated power of pump motor: 165 kW Heating power: 97 kW MACHINE DETAILS Net weight with control cabinet: 21,000 t Dimensions (L x W x H): 14.4 m x 3.4 m x 2.9 m Electrical connection Main connection: 3 × 400 V, 50 Hz Control voltage: 3 × 400 V, 50 Hz Repair history 2010: New screw with RSP and tube 2015: New Ibed 2015: New wiring board 2017: Motor and pump 2 new Dodpey T Hy Djfx Aktokn 2017: Injection cylinder BS piston rod new with seals 2017: Circulation pump oil cooler replaced 2017: Teachbox replaced (Rob) 2018: Pumps P 1 + 3 replaced (at 65,800 h) 2018: Hydraulic oil change 2019: New injection valve 2019: Dosing inverter overhauled by Fa. Eichler 2021: Motor P1 new 2022: New RSP EQUIPMENT - Wittmann W 753 Robot - 2008 - Cage and conveyor belt

Condition: used, Year of construction: 1992, machine/vehicle number: 0554, Anhänge-Kompressor, Mannesmann DEMAG, Baujahr 1992 , abgelesene Betriebsstunden 1219h, Typ SC20DS-2, Gewicht 600kg, Maße mit Deichsel 3160 x 1480 x 1180, Leistung 2,0 m³ je min, 2 Luftanschlüsse, 2 Zyl. Deutz Motor, Kugelkopfkupplung (PKW), Beulen und Rostschäden, siehe Bilder, Diese Beschreibung stellt kein verbindliches Angebot dar und kann Fehler beinhalten, keine Gewähr auf alle Angaben. Dksdjzcblxopfx Akten Anhänge-Kompressor, Mannesmann DEMAG, Baujahr 1992 , abgelesene Betriebsstunden 1219h, Typ SC20DS-2, Gewicht 600kg, Maße mit Deichsel 3160 x 1480 x 1180, Leistung 2,0 m³ je min, 2 Luftanschlüsse, 2 Zyl. Deutz Motor, Kugelkopfkupplung (PKW), Beulen und Rostschäden, siehe Bilder, Diese Beschreibung stellt kein verbindliches Angebot dar und kann Fehler beinhalten, keine Gewähr auf alle Angaben.

Year of construction: 1983, condition: excellent (used), machine/vehicle number: 20020233 UG 1 Brücke, DEMAG KBK crane canopy crane runway with dimensions approx. 29 x 6m (6m bridge - double girder crane) Payload / lifting capacity 1000 KG - 1to Technical data of the system: Dkjdpfxjty Tdbo Aktsn Crane runway made of Demag KBK2 rails with internal current routing System is supplied complete: KBK rails, rail joiners, trolleys, end plates, cable trailing, brackets/hangers etc. incl. Demag PK5 - 1000KG chain hoist - lifting height approx. 4m Crane is disassembled and immediately available Used condition, see pictures Item location is 75053 Gondelsheim Shipping by forwarding agent or collection by appointment only Demag KBK1 KBK2 and KBK3 tracks are stock items ! Other KBK installations are also in stock. Payload 125KG - 1600KG Please ask for your crane runway with load capacity and dimensions without obligation.

Condition: excellent (used), functionality: fully functional, Year of construction: 1989, machine/vehicle number: SI73, Technical data: 1x Demag KBK 1 column-mounted slewing crane, SWL 250kg Safe working load at full outreach: 250kg / 0.25t Height: approx. 2.83m Underside of jib: approx. 2.3m Jib outreach: 3m Hook height: approx. 1.85m Total weight approx. 400kg including anchor plate 71x71cm With Demag PK chain hoist 250kg Includes pin, cable trolley, travel trolley, end cap, etc. Slewing range: 300° Connection: 400V 16A Crane is dismantled and immediately available Item location: 75053 Gondelsheim Dkodpfxjwv N Ezs Akten Further cranes available, capacity 80-5000kg, please inquire See images Shipping by freight carrier or collection by appointment only

Year of construction: 2006, condition: good (used), machine/vehicle number: WIZ, Payload / lifting load 500 KG - 0.5 tons Technical data of the system: Crane runway made from Demag KBK2 rails External dimensions of steel construction (space required) 13.2 x 5.5m Height of steel construction 4.85 m, UK steel construction 4.65 m UK runway crane 4.4m, UK bridge 4m, hook height 3.8m Support spacing 4 + 4 + 4.9m The system is delivered complete: KBK rails, rail connectors Undercarriages, end plates, drag cables, holders/hangers, etc + complete steel construction (HEA180) incl. Demag DC 500KG chain hoist Crane is dismantled and available immediately Item location is 75053 Gondelsheim Good condition, see pictures (contaminated by oil mist - can be easily cleaned) Djdpfx Akoiwdaqetokn Dispatch by forwarding agent or pick-up only by appointment Demag KBK1 KBK2 and KBK3 rails are stock items!

Condition: used, functionality: fully functional, Year of construction: 1989, machine/vehicle number: ROD396, DEMAG KBK Crane Ceiling Crane Runway with dimensions approx. 19.5x7m (2x 7m bridge) Payload / Lifting Capacity: 2x 250 kg - 0.25 t Technical Data of the System: Runway made from Demag KBK2 rails, one side with KBKII-R rails featuring integrated power feed System is supplied complete: KBK rails, rail connectors, trolleys, end plates, brackets/hangers etc. including 2 bridges, each 250 kg including 2x 250 kg Demag DC chain hoists Crane is dismantled and immediately available Used condition, see pictures Item location: 75053 Gondelsheim Shipping by freight carrier or collection only by appointment Demag KBK1, KBK2 and KBK3 rails are in stock! Other KBK systems available. Load capacities from 125 kg to 1600 kg Please inquire about your crane runway with required capacity and dimensions, non-binding. Dkodpsxdvn Aofx Akton

Condition: ready for operation (used), Year of construction: 2017, operating hours: 3,548 h, clamping force: 1,600 kN, screw diameter: 45 mm, injection weight: 294 g, overall weight: 6,983 kg, Hydraulic injection moulding machine manufactured in 2017. This SUMITOMO SHI DEMAG Systec 160/520-600 features a clamping force of 1600 kN and a tie bar distance of 520 mm. The machine includes an injection unit with a screw diameter of 40 mm, 45 mm, and 50 mm, and a maximum shot weight of 313 g. If you are looking to get high-quality injection moulding capabilities, consider the SUMITOMO SHI DEMAG Systec 160/520-600 machine we have for sale. Contact us for further details. • Tie bar distance: 520 mm • Injection unit: 600 • Control: S-Dias Dodpfx Aozbh Epsktjkn • Screw diameter: 45 mm • Injection pressure: 1914 bar • Shot volume: 294 cm³ • Shot weight (PS): 254 g • Injection stroke: 469 mm • Installed heating capacity: 11.3 kW • Oil tank capacity: 290 l • Pump drive: 25 / 45 kW • Noise level: 69 dB(A) • Dimensions: 5.6 x 2.1 m • Main electrical connection: 3/400 V, 50 Hz, 167 A • Max pressure: 190 bar • Platen size: 770 x 770 mm • Max mold weight: 1300 kg • Max opening stroke: 500 mm • Min/Max mold height: 275 / 685 mm • Distance between platens: 1085 / 1185 mm

Condition: excellent (used), Year of construction: 2015, year of last overhaul: 2025, Demag Systec 210-840 (2015) Manufacturer: Sumitomo SHI DEMAG Type of machine: Systec 210/580-840 Clamping force [kN]: 2100 Shot volume [cm³]: 358 Clearance between tie bars hor. [mm]: 580 Clearance between tie bars vert. [mm]: 580 Mold height min. [mm]: 340 Mold height max. [mm]: 690 Opening stroke max. [mm]: 575 Daylight max. [mm]: 1365 Year of manufacture: 2015 Machine dimensions L/W/H [mm]: 6022 / 1556 / 2090 Control unit and software version: NC3 Max. weight of entire molding tool [kg]: 3300 Screw diameter [mm]: 45 Screw design: 3 zone Dkodpfxezbg Eze Aktsn Screw relation (length/diameter): 20:1 Screw back flow valve: Yes Ejector system type: Hydraulic Installed heating power [kW]: 39 No. of integrated hot runner circuits: 12 Number of temperature control electrical valves: 28 Number of cascade controls: 2 Connection to central drying system: Yes Unloading robot system available: Yes Number of tempering units: 3 Tempering units max. temperature [°C]: 160 Machine oil capacity [l]: 400 Net power of hydraulic pump engine [kW]: 26

Condition: good (used), Year of construction: 2007, Ref. no.: 18615 Manufacturer: DEMAG Type: IntElect 80/370-100 NC4 All Electric Year of construction: 2007 Clamping unit Clamping force: 80 ton Opening stroke: 340 mm Distance between tie bars: 370 x 370 mm Mould height min.: 150 mm Injection unit Screw diameter: 25 mm Injection volume: 51 cm³ Dkjdpfxjza Dc Uo Aktjn Shot weight: 45 g Injection pressure: 2000 bar Measurements and weight Dimensions: 4,3 x 1,3 x 2,3 m Machine weight: 4750 kg Further information: A Technology That Stands Out in Energy Efficiency: Less Energy, Higher Precision The Demag IntElect series is one of the pioneering machines that introduced all-electric drive technology to the plastic injection moulding industry in the late 2000s. Unlike conventional hydraulic systems where pumps and cooling circuits run continuously, the IntElect's servo drive only activates when movement is actually required. This fundamental difference delivers 50 – 70% energy savings compared to hydraulic machines, dramatically reducing annual operating costs. Motor System — Siemens MOTICS 3 Main Drive Motor · Water-Cooled Servo Motor The main drive unit that controls all clamping and injection movements with high precision. Plasticising Motor · Water-Cooled Servo Motor Based on the same Siemens MOTICS 3 platform, this motor melts material homogeneously through precise speed and torque control; its water-cooled design ensures stable operation during long-term intensive production. 5-Axis Full Servo Control The machine is equipped with 5 independent servo motors. Clamping, injection, screw retraction, ejector and plasticising axes all operate under full servo control. Since each axis can be programmed independently, all movements can be executed simultaneously. This architecture delivers micron-level repeatable precision, shorter cycle times and minimum mechanical loss compared to hydraulic systems. NC4 Control System The keyboard-based NC4 system manages all machine parameters — including injection profile, mould protection and cycle analysis — from a single screen.
