Press brake

Dener Abkantpresse DDS4013

Energy-saving, precise and fast press brake
Driven by Sevo motors and ball screw

Dcjdpfsq D Dv Djx Acwen
Bending length 1300 mm
Pressing force 40 t
Stroke 150 mm
Installation height 375 mm
X-path 440 mm
X- speed 1000mm/sec.
R- stroke 150mm
R- speed 100mm/sec.
Y- infeed speed 150 mm/s
Bending speed max.20 mm/s
Retraction speed 150 mm/s
Motor power 2x3.8 kW
Machine length 1880 mm
Machine width 2435 mm
Total height 2320 mm
Machine weight 3400 kg

Standard equipment:
European clamping system (Promecam) top
60mm die holder at the bottom
Stable X + R axis back gauge CNC controlled
2 pcs. Back gauge fingers manually adjustable on linear guide
Foot pedal with emergency stop button

incl. the options:
DA66T control unit
Fiessler AKAS 2M laser finger guard
+ FPSC Safety PLC (manual)

1 set of upper tools for the entire bending length:
Angle (°): 85°
H: 104,65
R: 0,8
Max T/m: 100
Material: C45

1 set of lower tools for the entire bending length:
Type: Die Multi-V (4-fold)
Angle (°): 85°
H: 60
V: 16 - 22 - 35 - 50
Max T/m: 80
Material: C45

The listing was translated automatically. Translation errors are possible.
