Hydr. pressbrake

DENER DD-M 10030

Condition: used, Year of construction: 2001, Used hydraulic press brake Speedy - Model SC 16.5 CNC small - mobile - versatile Working length 550 mm Technical data: Year of manufacture: 11/2001 Manufacturer: TEDA Model: SC 16.5 CNC The machine is powered and can be inspected by appointment! Max. pressing force: 160 kN Max. return stroke force: 0.8 kN Distance between uprights: 380 mm Overhang: 200 mm Length, max: 550 mm Distance between table and ram: 400 mm Stroke, max: 250 mm Speed: - Approach, max: 100 mm/s - Working stroke, max: 10 mm/s Fedpfxszzafys Afuepn - Return stroke, max: 125 mm/s Back gauge: X-axis – travel: 400 mm Rapid traverse: 200 mm/s Speed 50 mm before lower tool: 33 mm/s R-axis – travel: 120 mm Working pressure: 210 bar Installed power: 1.6 kVA Weight, unpacked: 1320 kg Connection voltage: 380 V Frequency: 50 Hz Measured settling time: 60 ms Safety distance: 96 mm Tool weight, max: - Model 31301-90-P08 L=550 mm: 25 kg - Model 41004-85 L=550 mm: 8 kg Processable sheet metal cutouts (approximate values) - Dimensions: 550 x 800 mm - Thickness: 5 mm - Weight: 16 kg

Condition: used, Year of construction: 2008, Hesse E 2040 - Hydraulic press brake - Cybelec DU 6000 CNC control system - 3 controlled axes (Y1, Y2, X) - manual Wila crowning table - 2 adjustable support arms Fsdpfx Afezl Tkdouepn - light barriers - incl. bending tools & operating manual - year of manufacture 2008 Technical data - Press capacity: 40 t - Bending length: 2050 mm - Distance between uprights: 1650 mm - Rapid traverse: 150 mm/s - Bending speed: 15 mm/s - Retraction speed: 100 mm/s - Stroke: 160 mm - Overhang: 350 mm - Motor power: 4 kW - Operating voltage: 3x 400 V - Oil tank capacity: 60 l - Machine dimensions WxHxD: 2800 x 2400 x 1600 mm - Weight: 4060 kg

Condition: new, Year of construction: 2025, neu 2025 080091 prompt, Zwischenverkauf v Türkei 51120 € 781.19 € 1 40900 € 60 to 2550 mm Y1 / Y2 und X Achse 160 mm 2150 mm 250 mm 350 mm hydraulisch 120 mm/s 9 mm/s 70 mm/s 620 (mit optionaler R-Ach mm 250 mm/s 813 mm 104 mm 100 l 5.5 kW 3250 mm 1200 mm 2350 mm 4250 kg Special price for demo machine Like-new condition 3 axes (Y1, Y2, and X axis) CNC control DT-10 - intuitive touch-screen control (simple drawing of the bending outline with your finger) - user friendly programming in dialogue form - automatic calculation of bending sequence Fpodpfxjwva Igs Afusn - automatic calculation of the blank sheet size - graphic product and tool memory - correction possibility - USB interfaces for backup and programm transportation - PC software, generating programms on the PC and transfer to the machine by USB CNC controlled back gauge with linear guide and ball screw spindles CNC controlled crowning table intermediate clamps for upper tool upper tool1010/A/75°/0,8, sectioned,bending radius hardened and ground die holder for 60 mm dies die type2009/85°(V 16, 22, 35, 50 mm)sectioned, geteilt, bending radiihardened and ground laser safety device Fiessler AKASmounted on the upper beam sheet support arms protection covers on the sides andback side according to CE rules oilfilling users manual in GERMAN orENGLISH (sample photo shows mod. PBF 30200) OPTIONS: CNC controlled R-axis (adjustment range in X = 500 mm) DBend, 3D CAD/CAM importing- and simulation program (step, iges and dxf file import) WE HAVE MORE THAN 600 REFERENCES!

Condition: new, pressure: 63bending length: 2500column width: 1980motor: 11slide stroke - max.: 150opening width: 400CNC Press break KK Industries 63x2500 4 Axis Y1-Y2-Y-X-R mit CNC Bombing Technical Parameters:Pressing Force: 63 t Bending Length: 2500 mm Distance Between Columns: 1980 mm Throat Depth: 300 mm Slider Stroke: 150 mm Maximum Opening: 400 mm Slider Down Speed: 180 mm/s Slider Return Speed: 170 mm/s Slider Working Speed: 14 mm/s Main Motor Power: 11 kW CNC System: ZY68 Number of Control Axes: 4+1 Oil Tank Capacity: 150 L Back Gauge:X-Axis:X-Axis Travel: 600 mm X-Axis Speed: 200 mm/s Positioning Accuracy: ±0.10 mm Repeat Positioning Accuracy: ±0.015 mm Motor Power: 0.85 kW R-Axis:R-Axis Travel: 150 mm R-Axis Speed: 100 mm/s Positioning Accuracy: ±0.10 mm Fodpfxsv Trgqo Afuspn Repeat Positioning Accuracy: ±0.015 mm Dimensions and Weight:Length: 2750 mm Width: 1350 mm Height: 2320 mm Weight: 4000 kg Delem T53 Control System (additional cost 5,000¤)

Condition: new, Year of construction: 2023, pressure 6,2 t chamfer lenght 285 mm mm distance between columns 230 mm dayligth 215 mm throat 70 mm stroke 100 mm working feed 9,8 mm/sec return speed 50 mm/sec quantity of oil 10 l Control DELEM DA 41T Fodpfx Aezlulcjfuepn total power requirement 0,7 kW weight of the machine ca. 250 kg dimensions 900 x 1300 x 550 mm Demonstration Machine â?¢ Basic C-frame design â?¢ Compact benchtop model â?¢ Ideal for prototypes and small production runs â?¢ Very short setup time â?¢ Functionally simple â?¢ Wide range of applications â?¢ Low noise level â?¢ Low power consumption â?¢ Easy to operate Includes optional equipment: - DELEM DA 41T CNC control
