Wide belt sander

DMC - ITALY EUROPA 120

Condition: excellent (used), Year of construction: 2016, Blockmold body, tightly welded, annealed, machined, and pressure- tested, executed according to European Standards and P.E.D. - 97/23/EC heat-resistant steel for steam pressure boilers Maintenance platform with ascent aid and fall protection. Block dimensions: • Height: 4,100 mm • Depth (usable depth): 1,300 mm • Width: 1,040 mm • Block gross volume: 5.5 m³ Cycle times: • 12-16 g/l density - 20-22 blocks/hour • 17-19 g/l density - 18-20 blocks/hour • 20-23 g/l density - 16-18 blocks/hour • 24-28 g/l density - 14-15 blocks/hour • 29-35 g/l density - 12-14 blocks/hour Filling system: • Filling silo volume - 1 x 10 m³ • High-pressure suction blower - 11 kW • Number of filling pistols - 2 pcs. • Filling diameter - 300 mm Ksdpfxopwbmbj Ahujll • Drive - hydraulic Mechanics: • Hydraulic system - 15 kW • Demolding - hydraulic • Door movement - hydraulic Electrical equipment: • Servo inverters: Mitsubishi • Frequency inverters: Mitsubishi • PLC: Siemens Simatic • HMI panels: Siemens Simatic • PC: Axiomtek

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : HSK63 - Spindle power : 17.5 [kW] - Spindle speeds : 18.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 915 / 500 / 500 [mm] - Rapid traverses rates (X/Y/Z) : 30 / 30 / 20 [m/min] TOOL CHANGER Kjdpfxoup Hwxe Ahusll - Tool magazine capacity : 28 TABLE - Table dimensions : Ø 630 [mm] - Maximum weight upon table : 500 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3620 x 3160 [mm] - Machine height : 3000 [mm] - Machine weight : 7300 [kg] MACHINE HOURS - Number of working hours : 50223 [h] EQUIPMENT - CNC : Heidenhain iTNC 530 - Coolant tank - Chips conveyor - Oil mist extractor : ELBARON - Cooling unit : HYDRAC COOLING FLKS 170S/2.3W/TP/400-50/1/14 - Workpiece probe : Renishaw - Tool breakage detection : BLUM

Condition: like new (used), Year of construction: 2021, Fabric cutting machine Lectra VIRGA.FA.CUT.MOTIF-E, year 11/2021, useful width 1.70 cm. Single cut, specific machine for cutting lines, squares and panels. Hours worked 86. Connected machine available for any tests. Klodpfx Ajvva Uujhuol

Condition: good (used), Code: 0749 Brand: TAGLIABUE - COSTA LEVIGATRICI Model: TT 3 1300 Automatic sanding machine for worktops, furniture, panels, tables Technical data: Working width mm 1300 Max working thickness mm 130 Min working thickness mm 1 Composition: 1° Transversal belt - Motor Hp 15 - Electronic speed variator with display 2° Transversal belt - Motor Hp 15 - Electronic speed variator with display Transversal sanding belt size mm 1350 x 150 Chevron belt size mm 5510 x 140 Belt blowers Kledpfx Ajh T Dzqshuol Belt feed speed mt/min 5/25 Fixed table and mobile head for on-line set-up Panel cleaning rotary blowers Vacuum table Belt cleaning brush Infeed roller conveyor Installed power Kw 32 Compressed air 7 Atm Suction inlets: n° 2 diameter mm 200 - n° 2 diameter mm 150 - n° 2 diameter mm 100 Overall dimensions mmm 4400 x 2500 x 1600 h Weight kg 5000

Condition: good (used), Loypack One shot chocolate depositor Stainless one shot moulding machine, 100Kg twin hopper, moulds are loaded into a denester, adjustable temp control, variable speed, heated water tank, comes with over 300 different moulds for making neopolitans, 3Ph Kodpsmqm E Ujfx Ahuell

Condition: like new (used), Year of construction: 2022, Polishing Machine – Ital Plastick PA-2 CNC START Kodpewbqkpofx Ahusll • CNC cleaning machine equipped with two reversible knives for white and coated profiles, and a blade for cleaning various profile shapes, with movement on two controlled axes. • Automatic insertion and positioning of the profile thanks to the centering device, which operates through proximity sensors to ensure precision and accuracy. • Maximum workable profile dimensions: up to 190 mm in height and a minimum of 35 mm. • Intuitive 4” Touch Screen panel with the possibility to store up to 99 working programs.

Condition: good (used), Year of construction: 2008, HAAS VF-5D / 40 MACHINING CENTER TRAVELS : X : 1,270 mm Y : 660 mm Z : 635 mm DISTANCE BETWEEN PLANE – TABLE AND SPINDLE NOSE : 178 – 813 mm TABLE : DIMENSIONS : 1,321 x 584 mm LOAD CAPACITY : 1,815 mm NUMBER AND SIZE X PITCH OF T-SLOTTS : 7.14 X 80 mm SPINDLE : ROTATIONAL SPEED : 8,000 RPM Ksdpfx Ahjvf Nw Djusll SPEED RANGES : 2 SPINDLE NOSE : ISO 40 HIGH PRESSURE / INTERNAL COOLANT FEEDS : RAPID SPEED : 18,000 mm / min. WORKING SPEED : 12,700 mm / min. JOG : 0 – 1,260 mm / min. TOOL MAGAZINE : 24 POSITIONS POWER : 15 KW WEIGHT : KG. 7,000 YEAR OF FIRST INSTALLATION : 2008

Year of construction: 2017, condition: ready for operation (used), A spinning, drawing and winding line for the production of monofilament yarns, multifilament FDY and POY is available. Spinning positions: 24, yarn ends: 192, drafting: cold and hot godets, package change: without yarn breakage, number of godets heated/cold: 50/50, number of winders: 24 (+2 reserve winders). Including various spare parts for the machine and electronics. Documentation available. On-site inspection is possible. Kedeuanq Tepfx Ahuoll

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, total width: 6,100 mm, total length: 1,550 mm, total height: 2,350 mm, overall weight: 1,800 kg, warranty duration: 6 months, power: 3 kW (4.08 HP), input voltage: 400 V, Sarp Line for pasteurization of stuffed pasta - Hourly output from 250 to 400 kg. The line consists of the following units: 1) Pasteurizer feeding conveyor belts. 2) Pasteurizer model SPA610VD, electric power 1.2 kW, heat output 120400 cal/h (140 kW), belt width mm. 1000, pasteurization tank length mm. 6000, overall dimensions mm. 10163 x 1600 x 2210 (h), total weight Kg. 1000 3) Belt elevator model SNZ 4) Wrapper - Cooler model SIR4105-A 5) Complete electrical cabinet The line is constructed entirely of stainless steel and has the following features: - width of the belts mm. 1000 - pasteurization belt speed adjustable from 1 to 3.3 meters / minute - wrapping belt speed adjustable from 0.65 to 1.95 meters / minute - cooling belt speed adjustable from 0.43 to 1.3 meters / minute - pasteurization chamber temperature from 96 to 99° C - internal temperature of the wrapper from 65 to 70° C - internal temperature of the cooler +3° C - pasteurization time from 1'50" to 5'30" - wrapping time from 3'40" to 10'55" - cooling time from 7'58" to 24' A steam generator suitable for this line is available but not included in the price listed. Electrical system 220 / 400 V - 3 phase - 50 / 60 Hz., fully serviced, guaranteed 1 year, CE and USDA compliant. 1 year warranty !!! WHY BUY FROM A DEALER ?!! BUY DIRECTLY FROM THE MANUFACTURER !!! For more information, contact Ostoni in Italy ! Kledpfeui Rixex Ahuol WE HAVE THE LARGEST ONLINE SELECTION OF MACHINES AND MOLDS FOR THE PRODUCTION OF RAVIOLI, TORTELLINI, CAPPELLETTI, TORTELLONI, GNOCCHI, PELMENI, PIEROGI, VARENIKI AND MANY OTHER PASTA SHAPES !!!

Condition: good (used), machine/vehicle number: 85382, UNIVERSAL MACHINING CENTER MAHO MH 800 C, series: 85382 X axis stroke 800 mm Y axis stroke 500 mm Z axis stroke 600 mm Work table dimensions: 900x625 mm Maximum weight allowed on the table: 600 kg Spindle rotation speed: from 20 to 5.000 rpm, 15 kW Tool taper: ISO 40 cone Tool shop with 30 positions Kledpjldgf Hofx Ahuol MAHO numerical command Machine dimensions: 3,350mm x 2,520mm X 2,500mm; Car weight: 6,200 kg Good technical condition Price EURO 13.000 + VAT Irrtum, Anderungen und Zwischenverkauf vorbehalten / Subject to errors, changes and prior sale / Ne rezervăm dreptul la greșeli, modificări și vânzare We speak English. /Wir sprechen Deutsch./ Beszélünk magyarul. /Nous parlons français/Vorbim romana
