CNC Milling Machine

DMG Mori CMX 1100 V

Condition: good (used), Year of construction: 2016, operating hours: 6,400 h, DMG MORI EcoMill 1100V CNC Milling Machine In well-maintained condition, DMG MORI Ecoline milling machine. Year of manufacture: 2016. Technical data: Hnedpfx Aey Ulb Nep Hjn Spindle speed: 20–12,000 rpm, continuously adjustable 14 kW main motor Spindle mounting: SK40 Travel ranges: X: 1100 mm, rapid traverse: 36 m/min Y: 560 mm, rapid traverse: 36 m/min Z: 510 mm, rapid traverse: 30 m/min Table dimensions: 1400 × 560 mm Maximum table load: 1000 kg Control system: Siemens SLIMline 3D Multi Touch 19" Weight: approx. 5830 kg External dimensions: 4898 × 2770 × 2935 mm Equipped with: IKZ (internal cooling through the spindle) Large tool magazine and tool changer with 30 positions Renishaw Power Probe 3D probing system Chip conveyor Documentation and maintenance history Tool cart with various holders and Renishaw OMP40-2.

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Max. bar diameter : 22 [mm] - Spindle speed : 10,000 [rpm] - Spindle power : 8.7/15 [kW] - Torque : 10/18 [Nm] - Number of counter-spindles : 2 - Spindle speed : 10,000 [rpm] - Number of slides : 10 - Travels : X x Z = 62 x 85 [mm] - Number of counter-operation slides : 2 - Travel : X = 62 [mm] - Dimensions : 3330 x 1830 x 2860 [mm] - Weight : 5700 [kg] - Connected power : 75 [kVA] Hodjw Ah R Nepfx Ap Honn - Production hours : 20,000 [h] EQUIPMENT - CN Siemens 840D SL - 2 NCU - TRANSMIT / TRACYL function - ARTIS - 2 additional electronic shaft preparations - 2 SCARA counter-spindles - 2 parts catchers with conveyor belt - Bar scrap recuperator - Index bar guide - Bar feeder predisposition - Fire protection system

Condition: ready for operation (used), Year of construction: 2018, - USED - 3-AXIS VERTICAL MACHINING CENTRE   X-AXIS TRAVEL: 1100 mm Y-AXIS TRAVEL: 560 mm Z-AXIS TRAVEL: 510 mm DISTANCE SPINDLE NOSE-TABLE: 120-630 mm RAPID FEEDS X-Y-Z: 30 m/min SPINDLE: 20 - 12000 rpm; 9 - 13 kW; ISO 40 - DIN TABLE SIZE: 1400 x 560 mm MAX ADMITTED LOAD: 1000 Kg HIGH PRESSURE COOLANT: 12 Bar TOOL MAGAZINE: CHAIN-TYPE ; 30 POS CONTROL UNIT: HEIDENHAIN TNC 620 Hnjdpfewh Dg Rox Ap Hon WEIGHT: 5830 Kg OVERALL DIMENSIONS: 4028 x 2750 x 2950 mm ACCESSORIES: SWARF CONVEYOR ; PORTABLE HANDWHEEL NOTE: WITH No 30 TOOLS-HOLDERS ISO 40

Condition: used, Year of construction: 2017, operating hours: 60,300 h, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 510 mm, feed length X-axis: 1,100 mm, feed length Y-axis: 560 mm, feed length Z-axis: 510 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 620, table width: 560 mm, table length: 1,400 mm, rotational speed (min.): 20 rpm, rotational speed (max.): 12,000 rpm, overall weight: 5,830 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 32,000 h, number of spindles: 1, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, DMG MORI CMX 1100 V / 2017 / HEIDENHAIN TNC 620 / spindle replaced by DMG For sale: a used DMG MORI CMX 1100 V vertical machining center, manufactured in 2017. The machine is located at our facility in Bydgoszcz, Poland. The planned production run on this machine has just been completed, and the machine is ready for sale. The machine is still connected to power, so it is possible to start it up, inspect it, and view it on-site after arranging an appointment in advance. The main spindle was replaced by DMG service in November 2024. Since the replacement, the spindle has operated for approximately 3,700 hours. A DMG service report confirming the spindle replacement is available. Key specifications: Manufacturer: DMG MORI Model: CMX 1100 V Year of manufacture: 2017 Control: HEIDENHAIN TNC 620 3D Travel in X/Y/Z: 1100 / 560 / 510 mm Table: 1400 × 560 mm Hsdpfxjy I A Duj Ap Hsnn Spindle speed: 20–12,000 rpm Spindle taper: SK40 DIN 69871 Tool magazine: 30 positions Linear scales in X/Y/Z axes Wireless HEIDENHAIN measuring probe Chip conveyor Electronic handwheel Coolant tank: 250 l Machine weight: approx. 5830 kg Operating hours: Approximately 3,700 hours since spindle replacement Spindle hours according to the counter: approx. 33,000 hours Machine on-time hours: approx. 61,800 hours Current meter readings are available in the documentation dated May 12, 2026.

Condition: used, Year of construction: 2024, INDEX MS22-8 Mfd. 2024 2 NCU (4) Y-Axis SL Control Cutting hours: 1,000 Turnkey Available Located in Europe 4-Meter IEMCA SIR MS22-8/43/P Rack loader 50 Hz D9-13-19-25 Bar length 4300 mm with drilling unit and minimum quantity lubrication unit additional end-of-bar sensor Bar stock 500mm (D12-D24) Bar stock 340 mm (D5-D11). Additional storage chain for 22 bars with Profinet interface. 1 11007253 (21711) Hsdsxnrtcepfx Ap Hjnn 1 set (8 pieces) bar stock pushers, external clamping for bar stock diameters D7-D10 mm, internal clamping for bar stock diameters D13-D18 mm, consisting of: 8 bar stock pushers D12 8 rotating sleeves D12 1 10287026 (21712) 1 set (8 pieces) bar stock pushers, external clamping for bar stock diameters D11-D16 mm, internal clamping for bar stock diameters D19-D24 mm, consisting of: 8 bar stock pushers D18 8 rotating sleeves D18 1 10536056 (21713) 1 set (8 pieces) bar stock pushers for bar diameters D17 mm-D22 mm, consisting of: 8 bar stock pushers D23 8 rotating sleeves D23 1 10414481 (21702) 1 set (8 pcs.) of internal clamping sleeves D12mm for bar diameters D13 mm - D18 mm Drill diameter D8 mm. 1 10472413 (21704) 1 set (8 pcs.) of external stops D12 mm for bar diameters D13 mm - D18 mm pre-machined. 1 10264327 (21703) 1 set (8 pcs.) of internal clamping sleeves D18mm for bar diameters D19 mm - D24 mm Drill diameter D15mm. 1 10058206 (21705) 1 set (8 pcs.) of external stops D18 mm for bar diameter D19 mm - D24 mm pre-machined. 1 12123486 Drill for drilling unit consisting of: 1 indexable insert drill D 15 mm 10 indexable inserts for steel 2 solid carbide drills D 8 mm

Condition: ready for operation (used), Year of construction: 2017, travel distance X-axis: 1,100 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 510 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 620 (3D), spindle speed (max.): 12,000 rpm, spindle motor power: 13,000 W, number of axes: 3, This 3-axis DMG MORI CMX 1100 V was manufactured in 2017. It features impressive axis travels of 1100 mm in X, 560 mm in Y, and 510 mm in Z. The machine is equipped with a 30-position tool magazine and a HEIDENHAIN TNC 620 control system. If you are looking to get high-quality machining capabilities, consider the DMG MORI CMX 1100 V vertical machining centre we have for sale. Contact us for further details. • Operating hours: • Spindle hours after replacement: 2,900 h • Spindle hours (machine counter): 32,420 h • Power-on hours (counter): 60,300 h • Condition: Powered on and running in production; inspection possible (operation, geometry, overall condition) • Worktable size: 1400 × 560 mm Hedpfxjylkl Te Ap Henn • Axis dynamics: Rapid traverse 30 m/min (linear axes) • Spindle: • Tool clamping: DIN 69872 • Tool magazine: 30-position chain-type magazine with double gripper • Cooling/media: Coolant–air switching via M-function (external), chip tray • CNC control: HEIDENHAIN TNC 620 (3D) with ASCII keyboard and 15" monitor • Measuring systems: Direct measuring systems (linear scales) on X/Y/Z; air purge for measuring system • Additional machine options: • Safe voltage package: X and Y axis motors with brake, overvoltage limiter, undervoltage monitoring with emergency stop trigger • Software options – HEIDENHAIN: • Option 3 (#21): M120 tool radius compensation for contouring, LOOK AHEAD up to 99 blocks, 3D machining, M118 handwheel positioning during program execution Additional equipment • Scraper-type chip conveyor (left side) • Coolant tank, 250 l • Manual wash gun for machining area • 4-color signal tower • HEIDENHAIN probing package: Wireless workpiece measuring probe and probe calibration ring • Manual handwheel (portable control panel) Technical Specification Taper Size SK 40

Condition: used, Year of construction: 2007, functionality: fully functional, 6-spindle Hainbuch Spanntop Axfix D22 ARTIS integrated process monitoring system Slide units - Slide unit 1.1: X-axis fixed, Z-axis NC-controlled - Slide unit 2.1: X-axis fixed, Z-axis NC-controlled - Slide unit 1.2: X-axis and Z-axis NC-controlled - Slide unit 2.2: X-axis and Z-axis NC-controlled - Slide unit 3.1: X-axis and Z-axis NC-controlled - Slide unit 3.2: X-axis and Z-axis NC-controlled - Slide unit 4.1: X-axis and Z-axis NC-controlled - Slide unit 4.2: X-axis and Z-axis NC-controlled - Slide unit 5.1: X-axis and Z-axis NC-controlled - Slide unit 5.2: X-axis and Z-axis NC-controlled - Slide unit 6.1: swiveling axis and Z-axis NC-controlled - Slide unit 6.2: X-axis and Z-axis NC-controlled Synchronization device, position 6.1 Part discharge via chute Workpiece conveyor belt at spindle position 6 High-pressure pump Fire extinguishing system Hedpfx Asyymbzsp Hjnn Coolant cleaning system Hinged belt chip conveyor Flat loading magazine: IEMCA SIR MS 22/33 P

Condition: used, Year of construction: 2006, functionality: fully functional, Description Headstock and tailstock manually adjustable. Ideally suited for machining one crankshaft type with different strokes. Workpiece Max. center-to-center distance of the outer main bearings: 920 mm Max. roll arm length (½ stroke + counterweight radius): 195 – 270 mm Max. number of machineable bearings: 8 main bearings, 6 pin bearings Main bearing diameter, min. / max.: 30 / 88 mm Pin bearing diameter, min. / max.: 30 / 84 mm Bearing width, min.: 18.5 mm Stroke, max.: 140 mm Bearing pitch, min.: 29.5 mm Deep rolling machines Max. deep rolling force: 30,000 N Headstock Main drive motor power: 20 kW Deep rolling speed: 120 rpm / 60 rpm Leveling rolling speed: 30 min¯¹ Hnsdpfewm Elfex Ap Hen Machine Weight including auxiliary units: approx. 13,800 kg Dimensions including integrated control cabinet and hydraulics (L/W/H): approx.: 4.5 x 2.5 x 2.2 m Max. machining height: 1,100 mm

Condition: good (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 270144, MS22C including bar feeder Cucchi PB24/3300 Knoll lubrication system VRF 500 with chip conveyor Kraft und Bauer fire extinguishing system The machine has 11 cross slides and a synchronous spindle. Included are: 5 turning holders 1 double holder 2 tailstocks with collet chucks Bar feeder parts for Ø20 The machine can be inspected while powered on. Hsdjy Sxm Hjpfx Ap Hsnn The operating hours are not accurate. They realistically correspond to approximately 10.5 years of operation in a 3-shift system. We need to free up the space, so we would like to sell the machine as quickly as possible.
