SPECIAL OFFER guillotine shears

Durma MS 2504

Condition: good (used), functionality: fully functional, Year of construction: 2007, Used 2.5 meter guillotine shear from Durma Hedpfx Aey Dpwgohzjnp Model: MS 2504 Capacity: 2500 x 4 mm Electric back gauge

Condition: used, Year of construction: 1995, Technical details: sheet width: 3000 mm plate thickness: 12 mm distance between columns: 3500 mm control: Cybelec DNC 10 G back gauge: 1200 motorisch mm cutting angle: 1,2 - 2,73 ° cutting gap adjustment: ja mm cutting capacity : 66.000 daN daN Knife length: 3100 mm down holder: 17 Stück interface: RS232 Table dimensions: 3200 x 600 mm total connected load: 22 kW weight of the machine ca.: 11,0 + (1,0 to Anbauteile+Zubehör) t space requirements approx. LxWxH: ca. 4,5 x 2,6 x 2,1 m transport dimensions LxWxH: ca. 5,0 x 2,25 x 2,2 m The guillotine shear was put into operation for the first time in 1998. The DNC 10 G control unit was specially designed for guillotine shears. It has a numerical axis for controlling the backgauge and automatically calculates and regulates the cutting gap, the cutting angle and the cutting depth, taking into account the material to be cut. (Data from the manufacturer) Table with side stopL:930 x W:105 x H:42 mm 2 table extensions L:1600 x W:100 x 83 mm Angle fence (attached to table extension) Operation via control panel with swivel arm and foot control Equipment: Drain with rollers for clippings Hnedpfx Ajvc Amtjhzep 2x protective grid *

Condition: good (used), Year of construction: 2006, machine/vehicle number: 313406334, Offer 24236 Hnjdpfx Ajwd Nu Sjhzep Technical specifications: - Max. working width 2550 mm - Max. cutting capacity St 40 4.0 mm - Cutting angle 1.30° - Position-controlled backgauge 20 - 750 mm - Front angle stop + support arms - Electric foot switch - Stroke rate up to 34 per minute depending on cutting length - Drive 400 V / 3 kW - Table height approx. 850 mm - Space required including backgauge, without front support arms - Approx. W 3250 x H 1250 x D 2000 mm - Weight approx. 3500 kg

Condition: used, Year of construction: 2008, sheet width 1530 mm plate thickness 4.0 mm thickness at "Niro-steel" 2.0 mm no. of strokes max. 34 Hub/min cutting angle 2.70 Grad distance between columns 1540 mm work height max. 920 mm Control konv. voltage 400 V engine output 3.2 kW weight of the machine ca. 1115 kg. range L-W-H 2275 x 2220 x 1400 mm Features: - Robust motorized swing-arm guillotine shear - Break-resistant, torsion-resistant welded steel construction - Compact and easy-to-use machine design - Manual backgauge, adjustable from the rear Hsdoxyln Rjpfx Ahzsnp * Stepless adjustment across the entire travel range - 1x hold-down bar - 1x freely movable foot switch - Front, extendable table extension - Rear safety device - Original operating instructions * Optional accessories included: - Sheet metal holding device for thin sheet metal blanks

Condition: excellent (used), Year of construction: 2014, 3 kW resonator power Hnedeyxc Afspfx Ahzop

Condition: used, Year of construction: 1969, Technical details: Hnjdpfxou Icp Aj Ahzop sheet width: 2000 mm plate thickness: 1,5 mm distance between columns: 2100 mm table-size: 2150 x 450 mm height over floor: 850 mm knife length: 2100 mm down holder: ja mm back gauge: 460 manuell mm strokes per minute: ca. 50 Hübe/min cutting gap adjustment: ja cutting angle: nein total power requirement: ca. 5,5 kW weight of the machine ca.: ca. 3,0 t transport measurements machine: 2,7 x 1,6 x 1,8 m Further features: - incl. Table extension (L: 1750 x W: 1000 mm) and adjustable limit stop - back gauge with linear scale, operation with hand crank i.D. *
