Surface grinding machine

ELB-Schliff Optimal 4250 NC-K

Condition: excellent (used), Year of construction: 1986, grinding length 800 mm grinding width 375 mm workpiece height 375 mm magnetic clamping plate, electical 900 x 300 mm spindle turning speed range 1500 - 3000 U/min table surface area 1550 x 370 mm Itodpfjunt Iujx Akwsl table longitudinal travel 100 - 1000 mm max. workpiece weight 350 kg dimensions of grinding wheel 300 x 50 mm total power requirement 9 kW weight of the machine ca. 4,6 t dimensions of the machine ca. 4,0 x 2,3 x 2,6 m

Condition: used, Year of construction: 1991, Technical details: grinding length: 600 mm grinding width: 375 mm workpiece height: 375 mm max. table load: 300 kg grinding range: 350 - 600 mm Table dimensions: 900 - 350 mm magnetic plate size: 600 x 350 mm dimensions of grinding wheel: 300 x 50 x76,2 mm mm total power requirement: 12 kW weight of the machine ca.: 5,2 t dimension machine xH: 3,3 x 2,6 x 2,4 m dimension coolant device LxWxH: 0,8 x 0,8 x 0,8 m Iedpfoxu D Huex Akwotl -Longitudinal table stroke = 700mm -transverse travel of table = 800mm Coolant pump *

Condition: used, Year of construction: 2016, x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm Control iTNC 530 HSCI Heidenhain distance between columns max. 5.090 mm distance spindle center to table 1.825 mm type 175149A-0007 turning speed range - main spindle max. 19.800 min/-1 Iodpfozf Nn Sex Akwotl power capacity - main spindel 20 kW tool taper HSK-A63 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° type 178099-0005 turning speed range - main spindle max. 10.020 min/-1 power capacity - main spindel 20 kW tool taper HSK-A100 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° table surface area 6.000 x 3.000 mm max. table load 50,0 t height over floor 100 mm number of T-slots 12 T-slot - width 28H12 mm T-slot - distance 250 mm number of toolpositions 62 (38+24) pos. number of toolpositions HSK A63: 37+1 pos. number of toolpositions HSK A100: 23+1 pos. max. tool diameter HSK A63: 52 mm max. tool length HSK A63: 250 mm max. tool weight HSK A63: - kg max. tool diameter HSK A100: 80 mm max. tool length HSK A100: 450 mm max. tool weight HSK A100: - kg rapid traverse ( X / Y / Z ) 40.000 mm/min rapid traverse B/C: 4.320 °/min feed speeds X/Y/Z: 30.000 mm/min Working speed B/C: 2.160 °/min Accelaration max. 3,2 m/s² x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm b-axis +115° / -115 ° c-axis +/- 200 ° total power requirement 180 kVA dimensions of the machine ca. 12,5 x 15,0 x 7,0 m 5-Axis-High-Speed-Gantry-Big-Machining-Center DROOP & REIN - FOGS 40 60 C - Fork head

Condition: used, Year of construction: 1990, grinding length 600 mm grinding width 375 mm Itsdey Tpqrepfx Akwol workpiece height 350-375 mm
