Circular saw for light metal & aluminium

Elumatec

Year of construction: 2005, condition: ready for operation (used), functionality: fully functional, power: 14 kW (19.03 HP), input current: 80 A, workpiece length (max.): 4,000 mm, machine/vehicle number: 6080008129, TECHNICAL DETAILS Maximum profile width: 130 mm Maximum profile height: 205 mm Maximum workpiece/profile length: 4,000 mm Processing capacity: 80 units MACHINE DETAILS Connection: 3 N/PE 400 V Frequency: 50 Hz Current: 80 A Power: 14 kW EQUIPMENT Powered, continuously adjustable gripper Lifting function for smooth feeding Profile guidance on rollers Nljdpezlnvuofx Adrjd Internal gripper to prevent damage to the profiles Integrated measuring sensors for workpiece length control Workpiece removal via outfeed table Portal design for high profile cross-sections Industrial PC with Windows operating system Barcode scanner

Year of construction: 2010, condition: ready for operation (used), functionality: fully functional, working length: 7,600 mm, machine/vehicle number: 1400040505, number of axes: 4, TECHNICAL DETAILS Njdszhuyfspfx Adrsld Max. machining length with end face machining: 7,600 mm Max. machining length without end face machining: 7,720 mm EQUIPMENT 12 pneumatic collet chucks 2 work areas 4-axis profile machining center; stepless machining between -90° and +90° with each available tool Automatic clamping position adjustment with absolute measuring system Two separate machining zones for tandem operation 4-axis control 18.5" color monitor, USB ports, and network connection Windows operating system EluCam software Automatic profile length measurement (on both sides) Barcode scanner The traversing tool magazine ensures short tool change times and thus optimal machining cycles; the magazine can be equipped with eight tools. 8x tool holders with collet chucks

Year of construction: 2007, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 280 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 21,000 rpm, working length: 3,750 mm, TECHNICAL DETAILS Machining length with bar support: 3,750 mm Machining length without bar support: 3,500 mm Travel range X-axis: 3,500 mm Travel range Y-axis: 280 mm Travel range Z-axis: 300 mm Nlsdjznczkjpfx Adrsd Positioning speed: 30 m/min Positioning accuracy: ±0.1 mm Spindle power: 6 kW Spindle speed: 21,000 rpm Spindle interface: HSK F63 Tool positions: 5 Max. tool diameter (manual): 200 mm Max. tool diameter (automatic): 92 mm Max. saw blade diameter: 500 mm MACHINE DETAILS Air consumption: approx. 50 l/cycle Compressed air requirement: > 7 bar Power supply: 400 V, 3-phase Note: The machine's operating hour counter is defective and cannot be read. The machine was only used in a single-shift operation.

Condition: used, Year of construction: 2020, functionality: fully functional, For sale: ELUMATEC SBZ 610 cutting center, manufactured in 2020. The machine is in perfect working order and ready for operation. Nlodpfx Aezpwzbsdrsd

Condition: good (used), Year of construction: 2008, machine/vehicle number: 0733337017, Swivel range: 0° to 45° adjustable in both directions, steplessly. Locking points: At 15°, 30°, and 45°. Saw blade diameter: 380 mm. Njdpfx Adszphi Njreld Saw blade speed: 2800 rpm. Power output: 3 kW. Compressed air connection: 7 bar. Dimensions L x W x H: 850 x 900 x 1450 mm. Weight: 250 kg.

Year of construction: 1996, condition: used, Max. cutting length: 6,000 mm Nljdpfx Aeznyyqodrod Max. saw blade diameter: 380 mm Automatic positioning of the saw head via E 255 control Cutting area at 90°: 195 x 120 mm Cutting area at 45°: 135 x 120 mm Minimum quantity spray device Pneumatic material clamps Miter cuts possible on both sides 2-Hand-Bedienung Machine is partially disassembled on squared timbers (about 3000 mm assembled)

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, cutting length (max.): 6,000 mm, saw blade diameter: 420 mm, total length: 6,100 mm, total width: 1,200 mm, total height: 1,400 mm, type of input current: three-phase, air pressure: 7 bar, Elumatec DG104 double-blade saw. Nsdpjznn Ivofx Adrold

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, machine/vehicle number: 26126, cutting length (max.): 4,500 mm, total length: 6,000 mm, total width: 1,950 mm, total height: 2,000 mm, We are offering this ready-to-use Elumatec DG 104/01 double miter saw, manufactured in 1993. The machine is fully functional. 6 m long, 3 axes. Manufacturer: Elumatec Model: DG 104 Year of manufacture: 12/1993 Machine type: Double miter saw Saw blade diameter: 420 mm Distance between saws, max. at 90°: 4,500 mm Distance between saws, min. at 90°: 335 mm Distance between saws, min. at 45°: 335 mm Saw blades can be tilted up to 45° Main motor: 4 kW Saw units can be swiveled Saw blades can be tilted Spray device Pneumatic clamping system Digital display Nljdpfx Adjzmrk Serod Positioning control Cutting from below Control: ELUMATEC E 255 Conformity marking: CE mark Space requirement, length: 6 m Space requirement, width: 1.95 m Space requirement, height: 2 m If you have any questions or require further information, please send us a message or call us. Subject to errors and omissions, all information without guarantee.

Year of construction: 2018, condition: excellent (used), For machining aluminium and steel profiles Fully functional, in very good condition Machining length: 7200mm 3-axis control with 15" screen Tool changer: 8 positions / turret 8 pneumatic horizontal material clamps Autonomous clamp positioning Two separate work zones, suitable for pendulum operation 2 pneumatic material stops 8 tool positions / BT30 turret Nodpfezmrhkex Adreld Barcode scanner Handheld control unit Safety light barrier at the front and side safety fence Minimal quantity lubrication Central lubrication Thread cutting without compensating chuck Simple programming at the control panel High-speed spindle up to 18,000 rpm Including 3 angle heads X-axis [mm]: up to 7,200 / 7,200 Y-axis [mm]: up to 485 / 310 Z-axis [mm]: up to 340 / 260 Rapid traverse speed X/Y/Z axis [m/min]: 60/60/60 Max. milling cutter diameter: 25mm Max. saw blade diameter: 180mm Max. tool length: 200mm (tool + holder) Max. spindle speed: 6,000 rpm Spindle power: 6 kW Weight: approx. 5.5 t Total operating hours: 30,844 h Total spindle hours: 11,583 h

Condition: like new (used), Year of construction: 2000, machine/vehicle number: 1780020742, functionality: fully functional, The machine was used very little. Top routing unit: Cutting range using stops or copy templates 340 x 100 mm Travel 110 mm Bottom routing unit: Cutting range using stops or copy templates 240 x 85 mm Travel at front 95 mm Travel at back 45 mm Spindle speed 12,000 rpm Nodpfx Adezmn N Rsrjld Clamping range for profiles 115 x 100 mm Power supply 230/400 V, 3~, 50 Hz Power output per motor 0.74 kW Compressed air supply 7 bar Air consumption per working cycle 12 l without spraying, 24 l with spraying Length 980 mm, depth 1,250 mm, height 1,610 mm, weight 360 kg
