Universal cylindrical grinding machine

EMAG Weiss W 11 CNC

Condition: used, _____ Description: Year of manuf. : 2020 Control : Sonstige WEISS CNC Centre width : 6 mm In Generel: ear of construction:2020 Control system:WEISS CNC Centre width:6 mm Centre height:200 mm Grinding wheel dimensions:400x60 mm + 0x60 mm Workpiece headstock: Speed:1 rpm Workpiece weight max.:25 kg Sanding diameter max.:390 mm Mounting:MK4 Grinding headstock: Peripheral speed:2 m/s Grinding disc dimensions right:0 x 60 mm Grinding disc dimensions left:400 x 60 mm X-axis:380 mm Z-axis:1,1 mm B-axis:torque motor, infinitely variable Tailstock: Pinole diameter: mm Pionole stroke:45 mm Mounting:MK 4 Cylinder fine adjustment:+/- 0.04 mm Equipment: Positioning sensors:Direct scales Grinding spindles:2x grinding spindle (left/right) GAP / Crash Controll:Structure-borne sound (Sensotronik) Balancing:MPM balancing device Workpiece measurement:Marposs PF ME Automation:Robot interface prepared Set-up mode:Electronic handwheel Emulsion mist separator:Mechanical Dresser:For external grinding wheel left/right Accessories:Various grinding discs + flanges Codpov Armcofx Ah Iopw

Condition: used, TECHNICAL DETAILS - Number of axes : 5 - Distance between tips : 400 [mm] - Effective diameter : 180 [mm] LINEAR AXES - X1 and X2 x Z travel : 220 [mm] - Z travel : 850 [mm] - X x Z resolution : 0.0001 [mm] TURRET : - Number of fixed positions : 12 - Tool holders : VDI30 WHEEL CARRIER - Right-hand external grinding : * Grinding wheel dimensions (Ø x width x bore) : 400 x 50 x 127 [mm] * Drive power : 6.8 [kW] WORKPIECE CARRIER - Max. speed : 7500 [rpm] - Speeds (synchronous operation) : 1 - 5000 [rpm] - Taper type : CM4 - Drive power : 10.5 [kW] - C axis : 0.001 [°] SYNCHRONIZED COUNTER SPINDLE - Max. speed : 7500 [rpm] - Rotational speeds (synchronous operation) : 1 - 5000 [rpm] - C axis : 0.001 [°] - Inner cone : MK4 - Micrometric adjustment : +/- 40 [microns] - Drive power : 10.5 [kW] POWER SUPPLY - Power rating : 45 [KVA] DIMENSIONS - Floor dimensions : 2800 x 3960 [mm] Cpjdpfx Ahovxw A Uo Ijw - Machine weight : 7600 [kg] MACHINE HOURS - Powered hours : 57000 [h] EQUIPMENT - NC FANUC 310i-modelA - Software Studer WIN - RS232 / USB interface - Remote electronic handwheel - Turret with Renishaw LP2 length self-calibration device - Marposs feelers for diameters (multirange) + Z4 axes for positioning - Semi-automatic wheel balancing MPM.3 BMT100 M.24 - 480 L coolant tank * with paper filter * with magnetic filter - Chip conveyor - Fog extraction - Cooling unit for grinding wheel motor cooling - Electronic contact detection Dittel AE6000 - Fixed dressing device on workhead - Electrical cabinet air conditioning - Balancing shaft - Interface for automatic loading system

Condition: used, Year of construction: 2020, operating hours: 6,875 h, machine/vehicle number: IntNr231185, EMAG WEISS cylindrical grinding machine EMAG WEISS type W11-CNC / UNIVERSAL CYLINDRICAL GRINDING MACHINE W 11-CNC SL650 Spindle hours: approx. 6,850 hours Power on hours: 20,422 hours This machine is characterized by its 2 in 1 control concept: 100% conventional cylindrical grinding or switching to 100% CNC cylindrical grinding Technical data: • Control: CNC-controlled (depending on year of manufacture Heidenhain, Siemens or Fanuc) Grinding length max. mm 650 / 1,500; in 25.5 / 59 Centre height mm 200 in 8 Grinding diameter outside mm1 / 390 in 0 / 15.5 Max. weight flying MK 4 kg 100 / lb 220.5 Max. workpiece weight between centres kg 250 /lb 551 Feed: X-axis travel mm 380 / 480 /in 15 / 19 Feed: Z-axis travel mm 1,150 / 1,650 in 45.5 / 65 Grinding wheel diameter mm 400 / 500 in 15.5 / 19.5 Rated power (100% ED) kW 9 / 11 hp 12 / 15 Peripheral speed m/s 20 - 50 Machine equipment: • Grinding wheel drive: Powerful Motor for precise grinding results • Tailstock: Adjustable tailstock for different workpiece lengths • Workpiece holder: Chuck or centering points (depending on the application) • Coolant system: Integrated, to avoid overheating and for optimal grinding results • User-friendly interface: Intuitive CNC user interface for easy programming and control • Measuring systems for real-time monitoring and quality assurance • Machine bed Cast bed Karstens base with high static-dynamic rigidity • X-axis High-precision linear guides, ball screw and glass scale • Z-axis V-flat or linear guides, ball screw and glass scale • Control Touch screen with integrated CNC control based on Windows Dialog programming, DIN programming, program memory. • Technical equipment Electrical cabinet according to VDE with CE mark • Coolant system and extraction system • Paper belt filter system with 250 | Container • Mechanical fume extraction with 1600 m²/3 with control without support foot • Measuring axis for moving to multiple diameters with wide range • Measuring head. Measuring position freely programmable. • Prepare robot interface. • Only provide 10 x l / O without interface plug software and PLC Applications: • Cylindrical external and internal machining • Precision grinding for mechanical engineering, the automotive industry and toolmaking • Production of shafts, bushings, rollers and other rotationally symmetrical workpieces Special features: • High rigidity of the machine body for vibration-free work Cpodex Sv U Uepfx Ah Iew • CNC control for complex grinding cycles and flexible processing • Adaptation to customer-specific requirements possible Optionally retrofittable Equipment: • Automated loading and unloading systems • Special mounts and special grinding wheel holders Optional grinding wheels available: • See photos The machine can be inspected by appointment. Subject to changes and errors in the technical data and information as well as prior sale! EMAG WEISS Cylindrical Grinding Machine EMAG WEISS Type W11-CNC / UNIVERSAL CIRCULAR GRINDING MACHINE W 11-CNC SL650 Spindle Hours: approximately 6,850 hours Power On Hours: 20,422 hours 2 in 1 control concept characterizes this machine: 100% conventional cylindrical grinding or switch to 100% CNC cylindrical grinding Technical data: - Control: CNC-controlled (Heidenhain, Siemens or Fanuc, depending on year of manufacture) Grinding length max. mm 650 / 1,500 ; in 25.5/59 Center height mm 200 in 8 External grinding Ø mm1 / 390 in 0 / 15.5 max. weight fl

Condition: used, Year of construction: 2020, grinding diameter 390 mm grinding length 650 mm Cpsdpsx Rn Uqjfx Ah Iew centre height 200 mm workpiece weight max. 250 kg x-axis 380 mm z-axis 1150 mm sanding disc diameter 400 mm peripheral speed 20-50 m/sec workpiece spindle stepless 1 - 650 U/min tailstock quill taper MT 4 quill stroke 45 mm dia. of quill 50 mm total power requirement 22 kW

Condition: as good as new (ex-display), Year of construction: 2025, Offered is a conventional cylindrical grinding machine EMAG Weiss W 11 Evolution. The conventional external-internal face cylindrical grinding machine fits perfect for single parts, prototypes and small batches. The basis of the EMAG Weiss W 11 Evolution machines is the established KARSTENS cylindrical grinder concept. Cjdetmrlhspfx Ah Ispw No hydraulics, axis drives with servo motors and screw spindle drive, technology entry of the grinding parameters via touchscreen, automatic dressing with compensation, automatic axis release. TECHNICAL DATA Workpiece lenght: max. 1,500 mm Center height: 200 mm | Ooption 320 mm Workpiece weight: 250 kg External grinding wheel diameter: max. 500 x 80 mm Workpiece headstock: MK4 | Option MK5 / MK6 Tailstock: MK 4 Price, delivery time and equipment of the machine according to agreement.

Condition: ready for operation (used), Year of construction: 2017, operating hours: 20,995 h, functionality: fully functional, machine/vehicle number: W11106617/144, grinding length: 1,000 mm, grinding wheel diameter: 400 mm, grinding diameter: 390 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 12 m/min, TECHNICAL DETAILS Grinding length: 1,000 mm Grinding diameter: 0–390 mm Internal and external grinding: up to 1 m Max. workpiece weight, unsupported (MK 4): 100 Nm Max. workpiece weight between centers: 250 kg X-axis Feed Rapid traverse: 350 mm Rapid feed rate: 12 m/min Fine feed increment: 0.0001 mm Z-axis Feed Cpodpfjw Nwxuox Ah Isw Max. travel: 1,150 mm Travel speed: 12 m/min Linear scale resolution: 0.0001 mm Spindle Data Internal grinding spindles: 80 x 350 mm Grinding Wheel Spindle Head Grinding wheel diameter: 400 mm Drive power: 5.5 – 7.5 kW Peripheral speed: 25 – 50 m/s Workpiece Spindle Head Speed range: 1 – 1,000 rpm Internal taper: MK4 Centering diameter: 63 / 80 mm Tailstock Quill taper: MK4 Quill stroke: 45 mm Filtration and Extraction Paper band filter system: 350 l tank Mechanical mist extraction: 600 m³/h MACHINE DETAILS Operating hours: 20,995 h EQUIPMENT Full enclosure Manual balancing system Touch-trigger longitudinal position indicator Leveling shoes for alignment Grinding centers MK 4 solid and half center (carbide-tipped) Dressing tool 0.5 carat diamond

Condition: good (used), Year of construction: 1984, Grinding wheelhead: - motor power : 2,2 kW - spindle speeds : 1 000 - 8 000 rpm - spindle inclination (A-axis): -10° up to +27° - setting accuracy 1 min - height adjustment (Y axis) : 130 mm - stroke range (X axis) : 220 mm - oscillation stroke, steplessly adjustable during oscillation : 0-30 mm - oscillation frequency : 30/60 1/min Workhead: Cpsdovmpabepfx Ah Isw - radius setting (Z axis) : 0.01-50 mm - setting accuracy: 0,01 mm - retraction of slide from the grinding to the measuring position : max. 49 mm - cross table, clamping surface : 155 x 205 mm - travel X - Y : each 60 mm - maximum swivelling angle (B axis): 260° - supply voltage : 380 V - weight : 1200 kg Accessories/options: - grinding pressure variable - projector fixed in measuring position - 1 cabinet with accessories - different grinding wheels, flanges - coolant tank - documentation Under power in our warehouse.

Condition: used, Year of construction: 1995, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm Teilüberholte Maschine mit Messprotokoll nach Neumaschinentoleranz NEUE Steuerung Eckelmann ENC mit BEMA Schleifsoftware Cpodpfeyatx Sex Ah Ijw KEL-ASSIST für Kelco 90 numerisch gesteuerte B-Achse Innnschleifrinrichtung Dia 80mm Schleifscheibe links Durchmesser 400mm Schleifscheibe rechts Durchmesser 300mm Innenschleifspindel HJN 828 hydraulischer Reitstock Mikroverstellung KEL SET Messsystem

Condition: used, Year of construction: 2005, functionality: fully functional, machine/vehicle number: 2808, total height: 2,400 mm, total length: 3,300 mm, total width: 2,200 mm, feed length X-axis: 450 mm, feed length Y-axis: 250 mm, feed length Z-axis: 350 mm, overall weight: 7,000 kg, travel distance X-axis: 450 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 350 mm, CNC grinding center for external, internal, and profile grinding with three linear axes and a swiveling grinding head. Modularly configurable for various grinding tasks, featuring automated dressing cycles, modern control system, tool management, and options for measurement systems as well as peripherals such as coolant treatment and extraction. Cpsdpfxsxuiche Ah Ijw
