Strung vertical

EMAG VL 4

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: 109238, Technical characteristics: Work Area - Chuck diameter: 260 mm - Maximum workpiece weight: 150 kg - Swing diameter: 280 mm - Maximum workpiece diameter/height: 200/200 mm - X-axis stroke (working stroke): 760 mm / Rapid traverse in X: 60 m/min / Feed force: 6.9 kN Kedpsxxkgpofx Aaajdw - Z-axis stroke: 415 mm / Rapid traverse in Z: 30 m/min / Feed force: 18.7 kN - Loading time: 5 to 6 seconds - Standard closed automation (number of loading stations by workpiece diameter): 14 (80–200 mm), 18 (30–160 mm), 30 (30–85 mm) Main Spindle - Spindle interface according to DIN 55026: Size 6 - Maximum speed: 4,500 rpm - Motor output at 100% / 40% duty cycle: 25 / 18 kW - Torque at 100% / 40% duty cycle: 280 / 200 Nm Tool Holder with Driven Tools - Toolholders with cylindrical shank according to DIN 69880: 12 positions – BMT65 - Number of positions: 12 - Maximum tool length including holder: 200 mm - Maximum speed: 6,000 rpm - Maximum torque (10% duty cycle): 27 Nm, (100% duty cycle): 14 Nm Electrical Equipment - Operating voltage: 400–480 V, 100 A - Connected load: 36 kVA Dimensions - Overall dimensions: Length = 5,300 mm (with chip conveyor), Width = 2,300 mm, Height = 3,650 mm - Weight: 9,000 kg Main Features and Capabilities: - Vertical design for optimal chip removal and easy workpiece loading/unloading - CNC control: GE Fanuc FS 32i B - High positioning accuracy on X and Z axes: ±0.001 mm (Heidenhain linear scales) - Main spindle: High power output and wide speed range - In-process measurement: Marposs T25 measuring probe - Automated loading/unloading: EMAG O-Type. Parts are loaded and unloaded via integrated automation - Driven tool capability extends machining operations to drilling and milling - Chip conveyor, coolant unit, switchable double cartridge filter, high-pressure pump (15 bar) - Tool life monitoring with sister tool management - Completely enclosed work area with workstation lighting - Documentation: Electronic version available; printed version incomplete Machine status: NOT WORKING - Requires replacement of hydraulic actuator and electrical motor - Live tool motor needs attention

Condition: used, Year of construction: 2014, functionality: fully functional, Travel path - X axis: 740 mm Travel path - Z axis: 400 mm Kodpfxjw Imtfj Aaaodw Travel path - Y axis: 30 mm (optional) Chuck diameter: 260 mm Max. turning diameter: 200 mm Spindle speed: 4,500 rpm Tool speed: 6,000 rpm Rapid traverse Z-axis: 15 m/min Rapid traverse X-axis: 60 m/min Rapid traverse Y-axis: 30 mm Machine weight approx.: 9,000 kg

Condition: used, Year of construction: 2017, functionality: fully functional, machine/vehicle number: 109242, Technical specifications: Work Area - Chuck diameter: 260 mm - Maximum weight: 150 kg - Swing diameter: 280 mm - Max. workpiece diameter/height: 200/200 mm - X-axis stroke (effective travel): 760 mm / Rapid traverse in X: 60 m/min / Feed force: 6.9 kN - Z-axis stroke: 415 mm / Rapid traverse in Z: 30 m/min / Feed force: 18.7 kN - Loading time: 5–6 sec - Standard closed automation (number of loading positions per workpiece diameter): 14/(80...200), 18/(30...160), 30/(30...85) Main Spindle - Spindle interface according to DIN 55026: Size 6 - Max. speed: 4,500 rpm - Power at 100% / 40% duty cycle: 25 / 18 kW - Torque at 100% / 40% duty cycle: 280 / 200 Nm Tool Turret with Driven Tools - Tool holder with cylindrical shank per DIN 69880: 12 positions - BMT65 - Number of tool stations: 12 - Max. tool length (incl. holder): 200 mm - Max. speed: 6,000 rpm - Max. torque (10% duty cycle): 27 Nm, (100% duty cycle): 14 Nm Electrical System - Operating voltage: 400 – 480 V, 100 A - Connected load: 36 kVA Dimensions - Overall dimensions: Length = 5,300 mm (with chip conveyor), Width = 2,300 mm, Height = 3,650 mm - Weight: 9,000 kg Kodpfx Aexxit Usaaedw Main Features and Capabilities: - Vertical design: Optimized for efficient chip removal and easy part loading/unloading - CNC control: GE Fanuc FS 32i B - High precision: Positioning accuracy (X/Z axes) ±0.001 mm; equipped with Heidenhain linear scales - Powerful main spindle: High output and large speed range - In-process measurement: Marposs T25 probing system - Fully automated loading/unloading: EMAG O-Type—parts are loaded and removed by integrated automation - Live tooling: Allows for drilling and milling operations beyond standard turning - Tool life monitoring with sister tool management - Chip conveyor and coolant filtration unit: Micron filter with paper filter and 40 bar pumps (suitable for filtering two machines) - Fully enclosed work area, illuminated for safe and easy operation - Documentation: Electronic documentation available (hard copy not complete) Machine status: Operational (in production)

Condition: used, Year of construction: 2017, functionality: fully functional, machine/vehicle number: 109239, Technical characteristics: Work Area # Chuck diameter: 260 mm # Maximum workpiece weight: 150 kg # Swing diameter: 280 mm # Maximum workpiece diameter/height: 200/200 mm # X-axis travel (working stroke): 760 mm / Rapid traverse in X: 60 m/min / Feed force: 6.9 kN Kodpfx Aasxxir Deaodw # Z-axis travel: 415 mm / Rapid traverse in Z: 30 m/min / Feed force: 18.7 kN # Loading time: 5-6 sec # Standard enclosed automation (number of loading stations based on workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4,500 rpm # Power at 100% / 40% duty cycle: 25 / 18 kW # Torque at 100% / 40% duty cycle: 280 / 200 Nm Turret with Driven Tools # Tool shank interface according to DIN 69880: 12 positions - BMT65 # Number of tool stations: 12 # Maximum tool length including holder: 200 mm # Maximum speed: 6,000 rpm # Maximum torque: 27 Nm at 10% duty cycle, 14 Nm at 100% duty cycle Electrical Equipment # Operating voltage: 400 - 480 V, 100 A # Connected load: 36 kVA Dimensions # Overall dimensions: Length = 5,300 mm (with chip conveyor), Width = 2,300 mm, Height = 3,650 mm # Machine weight: 9,000 kg Main Features and Capabilities: # Vertical design: Optimized for chip removal with easy loading/unloading. # CNC control: GE Fanuc FS 32i B. # High precision: Positioning accuracy in X, Z axes ±0.001 mm with Heidenhain linear scales. # Powerful main spindle: High power and broad speed range. # In-process control: Marposs T25 measuring probe. # Fully automated loading/unloading: Emag O-Type; workpieces are automatically loaded and unloaded via integrated automation. # Driven tools: Enables drilling and milling operations within the machine. # Tool life monitoring with sister tool management. # Chip conveyor and coolant filtration unit: Micron filter with paper filter, 40 bar pumps (suitable for filtering two machines). # Fully enclosed work area, internal work light. # Documentation: Electronic version available (book version incomplete). Machine status: OPERATING
