Vertical lathe

EMAG VSC 250

Condition: ready for operation (used), Year of construction: 2014, General Data Measurements width 1500 mm Measurements depth 3900 mm Measurements height 3200 mm Machine weight 7000 kg Golhewg Ibvocdw Ajub Control Unit Model SINUMERIK 840Dsl Brand SIEMENS Main Drive Spindle speed range 4500 rpm Spindle motor power 18kW at 100% duty cycle, 28kW at 40% duty cycle Tool taper DIN 55026 - A6 Number of axis 2 Movement X-Axis Movement 745mm X-Axis Rapid Traverse 60m/min Z-Axis Movement 300mm Z-Axis Rapid Traverse 30m/min Media Chip conveyor Yes Internal cooling Yes Additional Equipment Coolant tank capacity: 360 liters This EMAG VSC 250 vertical turning machine was manufactured in 2014. It features a powerful main spindle drive with up to 28kW power at 40% duty cycle and a speed range of 0-4500 rpm. Equipped with a Siemens SINUMERIK 840Dsl control system and a robust 12-position EMAG flange turret, it ensures precise and efficient operations. Ideal for handling workpieces up to 6kg with its specialized hydraulic chuck. For more information about this vertical turning machine, please reach out to us. Application Types Turning

Condition: used, Year of construction: 2015, Technical details: turning diameter: 200 mm Gjljq Sc Huehcdw Aoub swing diameter: 260 mm turning height: 60 mm

Condition: like new (used), Year of construction: 2014, machine/vehicle number: 105488, Technical data: Chuck diameter max. 250 / 315 mm Swing diameter 350 mm Workpiece diameter max. 250 mm Traverse path: X-axis:745 mm Z-axis: 300 mm Loading times: Loading times (depending on workpiece) s 4 - 6 Main spindle: Spindle flange DIN 5502: 6 Spindle bearing, front through. Max. 110 mm Speed max. 5500 min. Disc turret: Number of tool holders: 12 Gjlhswfgzlecdw Aeub Shank diameter: 40 mm Driven tools Maximum power: 8,5 kW Speed: max. 6000 min Turret swivel time: 0.3 s Control: Bosch Rexroth MTX

Condition: good (used), Year of construction: 2015, operating hours: 35,000 h, chuck outer diameter: 250 mm, feed length X-axis: 680 mm, feed length Z-axis: 200 mm, spindle speed (min.): 6,000 rpm, power: 39 kW (53.03 HP), rapid traverse X-axis: 45 m/min, rapid traverse Z-axis: 30 m/min, type of input current: three-phase, controller manufacturer: Siemens, controller model: 840 DS, input voltage: 400 V, coolant supply: 6 bar, nominal power (apparent): 45 kVA, EMAG VERTICAL SINGLE-SPINDLE TURNING AND GRINDING CENTER EMAG - REINECKER VSC 250 DS Used machine: Year of manufacture: 2015 Control: Siemens 840 DS The attached emulsion mist extraction system (air filter) and the matching base frame can be purchased separately. Condition: Used machine, very good Machine runtime approx. (hours): 35,000 Program runtime approx. (hours): 22,000 Operating voltage: 400V Air supply: 6 bar Total power requirement approx. 45 kVA Cooling unit: water/water Machine dimensions without peripherals (LxWxH): approx. 3200x1900x2650 mm CYLINDRICAL GRINDING Integrated motorized grinding spindle with a maximum speed of 45,000 rpm and a maximum power of 18 kW Touch dressing for vitrified CBN grinding wheels Automation / Gantry: EKF basket stacking cell as raw/finished part storage for 400x600 mm baskets on a floor trolley 3 basket stacks for uninterrupted operation, even during basket changes, loading/unloading via a loading gantry The machine is in very good condition and has been serviced by EMAG. The production process involves pre- and finish machining of the bore/end faces by hard turning the flat surfaces, as well as the diameter/bore, followed by bore grinding. We have described the details of the system as best as possible. We would be happy to provide more detailed information upon request. Gslslfduishcdw Asub "Price and details upon request." All technical information is subject to typographical errors/mistakes. For sale only in EU countries.

Condition: used, Year of construction: 2011, x-travel 745 mm z-travel 300 mm control Sinumerik 840 D turning speeds 6.000 U/min tool taper VDI 40 Gslhcdsvw D Afew Aoub number of tool places 12 Pos. workpiece diameter 250 mm In our opinion, the machine is in good used condition and can be viewed under power by appointment. Technical features & accessories: - lateral workpiece feed and discharge - chip conveyor KSS - cooling system KSS Type SV0.3 + KBF600 Year of manufacture 2021 - feeding system There are another 3 identical machines from 2007 available. Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in the technical data and information as well as prior sale!

Condition: used, Year of construction: 2003, Functionality: fully functional, machine/vehicle number: 2841823, Maximum workpiece diameter: 250 mm Maximum workpiece length: 175 mm Maximum chuck diameter: 315 mm Gujlhsv U Emtscdw Aeb Axis travel: X-axis: 860 mm Z-axis: 200 mm Rapid traverse: X-axis: 45 m/min Z-axis: 30 m/min Main spindle speed: up to 4500 rpm Main spindle power: 28 kW Control system: SIEMENS SINUMERIK 840Dsl Tool turret: 12 positions Maximum workpiece weight: 6 kg

Condition: ready for operation (used), Year of construction: 2011, General Data Measurements width 1500 Measurements depth 3900 Measurements height 3200 Machine weight 7000 Control Unit Model SINUMERIK 840Dsl with integrated PLC S7-300 Brand SIEMENS Main Drive Spindle speed range 4500 Spindle motor power 18 kW (100% duty cycle), 28 kW (40% duty cycle) Tool taper DIN 55026 - A6 Movement X-Axis Movement 745 mm X-Axis Feed Force 10 kN X-Axis Rapid Traverse 60 m/min Z-Axis Movement 300 mm Z-Axis Feed Force 10 kN Z-Axis Rapid Traverse 30 m/min Workpiece Workpiece weight 6 kg Tools Slots in storage 12 Additional Equipment Hydraulic 6-jaw special chuck from EMAG with face clamping device and central lubrication 15-inch TFT monitor V24 interface This EMAG VSC 250 vertical turning machine was manufactured in 2011. It features a Siemens SINUMERIK 840Dsl control system, a robust hydraulic 6-jaw chuck, and a flange turret with 12 tool positions. With a spindle speed up to 4500 rpm and a main spindle drive power of 28kW at 40% duty cycle, it's ideal for precise, efficient operations. For more information about this vertical turning machine, please reach out to us. Application Types Guolhcdjwg Icaew Ajb Turning

Condition: used, Year of construction: 2008, Article: Vertical turning and grinding centre Manufacturer: EMAG Type: VSC 250 DS Yob: 2008 Control: SIEMENS 840D Grinding spindle speed: 30,000 rpm Rotation spindle speed: 3,000 rpm Tool places turret: 12 Cooler for spindle and machine bed cooling Cooling lubricant - lifting station (no independent cooling lubricant supply) Chip conveyor Parts handling Air through the spindle Two clamping circuits through the spindle (air and oil) Unfortunately, the grinding spindle is defective. However, this can be overhauled in a spindle factory. Otherwise the machine is in a very good condition and fully functional. Please, contact us for getting more information and pictures on mail(at) or Golhcdweia Rtdj Asub *

Year of construction: 2014, Condition: like new (used), machine/vehicle number: 105488, Technical data: Chuck diameter max. 250 / 315 mm Swing diameter 350 mm Workpiece diameter max. 250 mm Traverse path: X-axis:745 mm Z-axis: 300 mm Loading times: Loading times (depending on workpiece) s 4 - 6 Gjlofyaaijhcdw Asub Main spindle: Spindle flange DIN 5502: 6 Spindle bearing, front through. Max. 110 mm Speed max. 5500 min. Disc turret: Number of tool holders: 12 Shank diameter: 40 mm Driven tools Maximum power: 8,5 kW Speed: max. 6000 min Turret swivel time: 0.3 s Control: Bosch Rexroth MTX

Condition: refurbished (used), Year of construction: 2012, Offered is a vertical turning and grinding center EMAG VSC 250 DS. The machine will be mechanically overhauled and rebuilt by EMAG. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens 840Dsl TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 Gjlhjh Tkdqscdw Asub console with grinding spindle 18 kW, 45000 1/min Delivery time and additional equipment of the machine on request.

Condition: excellent (used), Year of construction: 2017, operating hours: 39,603 h, Functionality: fully functional, controller model: Siemens 840D-SL, VERTICAL TWIN-SPINDLE TURNING CENTER - EMAG VSC250 TWIN Systems (operating hours and wear similar): 3x VSC250 TWIN available Gujlsuiw E Sohcdw Aob Machines were in production until 08/2024 (interlinked with several machines) Available immediately Systems are dismantled ready for transport Self-collection at the Haldensleben site Optional loading/transport can be offered

Condition: used, Year of construction: 2004, turning diameter 250 mm turning length 100 mm control SIEMENS 840 D total power requirement 35 kW weight of the machine ca. 7500 kg dimensions of the machine ca. m E M A G (Germany) Vertical CNC Controlled Hard Turning and Grinding machine with tool turret and workpiece handling System Model VSC 250 DS Year 2004 # M7 28.69324 _____ Turning Ø, max. 250 mm Turning length internal / external 100 mm Workpiece length min./max. 29 – 100 mm 6-positon tool turret Ø / swing-Ø 480/790 mm Workpiece spindle Slide travel, X / Z / stroke 680 / 400 / 200 mm Feed rate / Quick feed X/Z 45/30 m/min. Feed force X/Z 5,5/11 kN Spindle speed 4.300 / 6.000 rpm Spindle drive 28 kW Total electrical load, approx. 35 kW - 400 V - 50 Hz Weight, approx. 7,500 kg Accessories / Special Features: * CNC – Continuous Path Control SIEMENS Model 840 D, with colour monitor, graphics, menu-supervised dialogue programming, and all the usual options, cycles and subprograms, etc. * Hexagon Tool turret head with 6 tool positions (Ø 40 mm) without motorized tools posts, two positions T 3 u. T 6 equipped with grinding spindles with 42.000 rpm and with 18.000 rpm, using CBN discs resp. regular grinding tools Gslhcdet Hxa Tjw Ajub * Workpiece handling device with WP transportation frames and circulation system and pick-up and unloading of finished parts directly through the motor spindle which is equipped with a hydraulic 3 jaws chuck make SMW Autobloc with membrane clamping and clamping control system. * MARPOSS MIDA Measuring Probe for measuring blank parts a. the finished parts * NORGREN air measuring system, hydraulic weight compensation of spindle, * Main elements of machine are temperature stabilized by a coolant system made by HYFRA * Recooler for the grinding coolant sitting on a large Coolant device consisting of SEITZ Paper Band filter and a mobile Chipconveyor, Magnetic separator, Centrallubrication, etc. Vertical CNC lathes offer a thermo-resistant construction (chips do not fall onto the machine bed),fast workpiece change times (pick-up system through the main spindle) and a ridged tool arrangement,which also allows unrelated machining work, like hard turning or grinding process on the same machine. Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: good (used), Year of construction: 2002, Machine type: CNC Lathe Manufacturer: Reinecker Karstens Kopp - EMAG Model: VSC 250 DS Serial number: M02.43446 Gjlhcdokyrwwjw Asub Year of manufacture: 2002 Available immediately Ex site for self disassembly Optionally we can offer dismantling and loading

Condition: refurbished (used), Year of construction: 2007, Functionality: fully functional, year of last overhaul: 2023, Offered is a VSC 250 vertical turning center, which has been mechanically and electrically overhauled by EMAG. The control system was upgrated to Siemens Sinumerik One. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens Sinumerik One TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm Guolhcsrq Damjdw Aob MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 Delivery time and additional equipment of the machine on request.

Condition: refurbished (used), Year of construction: 2012, Offered is a VSC 250 vertical turning center, which has been mechanically overhauled by EMAG. Geleh Ryp Sohcdw Aoub All control components of the Siemens 840 Dsl control have been tested. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens 840Dsl TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 Delivery time and additional equipment of the machine on request.

Condition: used, Year of construction: 2001, Offered is a vertical single spindle pick up turning machine EMAG VSC 250 built 2001. The machine is equipped with a conveyor belt (O-Type) that runs through the machine. The automation belt is loaded with workpieces at the front of the machine. The work area has one working spindle and one turret with 12 tool positions. Other accessories such as a chip conveyor, coolant equipment or independent extractor unit are not included in the advertisement. The machine was taken out of service a few years ago. After inspection, the VSC 250 is fully functional and in good condition, as can be seen in the pictures. The machine has been completely cleaned and repainted. All control cabinet components and cables are still in their original condition. COTROL Siemens Powerline Golhetrwdtscdw Aeub TECHNICAL DATA workpiece diameter: max. 200 mm workpiece height: max. 150 mm swing diameter: 250 mm X-stroke: 685 mm Z-stroke: 200 mm MAIN SPINDLE power: 28 kW speed: max. 6000 rpm TOOL CARRIER 1x disc turrets, 12x D40 without driven tools The machine is sold without any warranty claims. Delivery time of the machine on request.

Condition: refurbished (used), Year of construction: 2014, Functionality: fully functional, total width: 2,500 mm, total length: 4,500 mm, total height: 3,200 mm, Offered is a double spindle pick up turning machine VSC 250 DUO. There are 2 nearly identical machines available. Each machine is equipped with 2 independent working spindles and 2 EMAG turrets. The machine can produce 2 identical workpieces with the same machining operation, as well as one workpiece in two successive machining operations. The VSC 250 DUO will receive a general overhaul before delivery and gets a control upgrade to Siemens Sinumerik ONE. The machine can be equipped with other periphery (chip conveyor, coolant system, external automation, etc.), depending on requirements. COTROL Siemens Sinumerik One TECHNICAL DATA workpiece diameter: max. 250 mm workpiece height: max. 150 mm chuck diameter: 250/315 mm swing diameter: 350 mm X-stroke: 745 mm Z-stroke: 300 mm Gelhcdor Nc Ufow Asub TOOL CARRIER working area 1 1x EMAG disc turrets, 12x VDI 50 without driven tools working area 2 1x EMAG disc turret, 12x VDI 50 with driven tools Price, delivery time and equipment of the machine on request.

Condition: used, Year of construction: 2006, Technical details: swing diameter: 200 mm weight of the machine ca.: 15 t Distance between tips: 832,5 mm turning length: 380 mm with chip conveyor and belt filter press, infeed and outfeed belt 2 x 12-position revolvers * Gjlsquy Iuohcdw Ajub

Condition: ready for operation (used), Year of construction: 2003, Two identical Emag CNC machining centers including a chip conveyor, coolant tank, various holders, jaws and a new AGW are available. Chuck diameter: 200mm, max. circulation diameter: 290mm, max. workpiece length: 140mm, speed: 6000rpm, power: 34kW, torque: 480Nm. Travel X/Z: 550mm/200mm, rapid traverse X/Y: 30m/20m/min, feed force X/Z: 11kN. Tool positions: 12, drive tool power: 7.8kW. Machine dimensions X/Y/Z: approx. 2700mm/1150mm/2800mm, weight: approx. 6500kg. Documentation available. On-site inspection is possible. Guslhcowi Tpqjdw Aob

Condition: used, Year of construction: 2008, turning diameter max. 140 mm swing diameter Futter / Chuck Ø 250 mm turning height 630 mm Control SIN840 PL spindle turning speed - stepless 1 - 5.000 U/min power capacity at 40 % load 38,00 kW Spindle head DIN55026 - Size 6 spindle diameter in front bearing 110 mm Gjlhcdewhqrtew Ajub travel -x axis 300 mm feed X-axis 1 - 30.000 mm/min rapid traverse X-axis 30,00 m/min feed force X axis 9.000 N travel -z axis 700 mm feed Z-Axis 1 - 40.000 mm/min rapid traverse Z-axis 40,00 m/min feed force Z axis 10.000 N no. of tools in turret 1 12 no. of tools in turret 2 12 tool taper VDI 40 DIN 69880 total power requirement 70 kW weight of the machine ca. 25 t dimensions of the machine ca. 6,8 x 4,7 x 4,3 m Chip conveyor Spindle cooling system HYFRA Coolant system Knoll

Condition: excellent (used), Year of construction: 2008, Functionality: fully functional, machine/vehicle number: 101197, Used CNC vertical lathe Make: EMAG Type: VTC 250 Year of manufacture: 2008 Guolhcdwov Hp Dmo Aob

Condition: used, Year of construction: 2013, turning diameter 340 mm swing diameter 420 mm turning height 315 mm Control S 840 DSL Golhewfhq Iscdw Asub x-travel 850 mm z-travel 315 mm spindle turning speed - stepless 0- 3400 U/min main drive 37(48) kW feed in x - axis 0- 45 m/min feed range Z-direction 0- 30 m/min work piece power 19 kW toolpiece turning speed range 0- 6000 U/min total power requirement 60 kW weight of the machine ca. 12 t dimensions of the machine ca. 3,7 x 3,1 x 3,3 m Machine is offered without chuck and tool holders.

Condition: good (used), Year of construction: 1998, Emag VSC 200 with workpiece conveyor and chip conveyor. The main spindle bearings were replaced in 2005. Control: Siemens 840D Turning diameter: Ø 260 mm. Turning length: approx. 200 mm. Machine dimensions: Length: 3,200 mm, width: 1,800 mm, height: approx. 2,650 mm. Gslotq Ifnjhcdw Aeub Machine weight: approx. 6,500 kg. The machine was only used in 1-2 shift operation.

Condition: used, Year of construction: 2002, Technical details: Goleruvfkjhcdw Aeub turning diameter: 175 mm turning height: 70 mm chucking diameter: 175 mm

Condition: used, Year of construction: 2012, turning diameter 340 mm swing diameter 420 mm turning height 315 mm Control S 840 DSL x-travel 850 mm z-travel 315 mm spindle turning speed - stepless 0- 3400 U/min Guelhcdwjwfhqzs Ajb main drive 37(48) kW feed in x - axis 0- 45 m/min feed range Z-direction 0- 30 m/min work piece power 19 kW toolpiece turning speed range 0- 6000 U/min total power requirement 60 kW weight of the machine ca. 12 t dimensions of the machine ca. 3,7 x 3,1 x 3,3 m Machine is offered without chuck and tool holders.
