Motorized tube bending machine

ERCOLINA Super Bender SB 48

Condition: new, Year of construction: 2026, Mandrel-free pipe bending machine RB 54 - NC-controlled, with large program memory Rodevk Scgopfx Ammsu Article number: 4300054 NC control for setting the bending angle Up to 50 programs can be saved High-quality, robust design Fast tool change Purely motor drive Automatically returns to the starting position TECHNICAL DATA General information Bending radius max. 162mm Bending angle max. 210° Bending speed(s) 2rpm Torque 2341Nm Dimensions and weights Length (product) approx. 600mm Width/depth (product) approx. 220mm Height (product) approx. 470mm Weight (net) approx. 107kg Bending performance Bending performance of pipe material 420 N/mm² (Ø x wall thickness) 54 x 4mm Bending performance of pipe material 350 N/mm² (Ø x wall thickness) 54 x 4mm Bending performance of pipe material 650 N/mm² (Ø x wall thickness) 42 x 3mm Electrical data Drive motor power 1.1kW Connection voltage 400V Mains frequency 50Hz Location: from stock - available immediately -

Condition: used, Multi-speed machine with flexible shaft BIAX type MB 4-2 Machine no. No. 9/50/55 Year of construction approx. 1970 Length of the flexible shaft: 2 meters Speed: 900 - 9000 rpm infinitely variable Rjdpfefim Tijx Ammsu Motor speed: 3000 rpm Motor power: 1.2 kW = 1.5 HP Mains connection: 380 Volt, 50 Hz - Handle straight grinder with collet Ø 6 mm - Swivel and rotatable base - Transport trolley with 2 drawers Overall dimensions: 850 x 550 x 1100 Weight: approx. 80 kg good condition Universal for milling, grinding and polishing work

Condition: used, Year of construction: 1999, tube diameter 12-54 mm (Kupfer / Edels. mm serial number EBD Rsdpfx Ajumyhlemmsu mode of operation Schneiden/ Entgraden / Re speed Rollen 450 U/min m/min

Condition: used, functionality: fully functional, Hydraulic mandrel tube bending machine Complete bending sets with bending mandrels and bending shoes: Ø 18, 20, 22, 25, 2 x 30 + 35 mm Additional bending mandrels without bending shoes: Ø 28, 2 x 38 + 42 mm Rjdswnrt Sspfx Ammsu Pre-assembly device with hydraulic cylinder Hydraulically driven deburring unit for tubes, inside and outside, from 6 - 48.3 mm Max. tube feed length: 3000 mm Machine weight: approx. 700 kg Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel
