UV Dryer

ESC special

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, Printing format: 600 mm x 900 mm Maximum sheet size: 650 mm x 950 mm Maximum screen frame size: 700 mm x 2160 mm x 40 mm Godpfx Aedx Raqsixjka Table size: 700 mm x 1000 mm Cycle rate: 1200 pieces per hour Machine dimensions (L x W x H): 1600 mm x 1080 mm x 1700 mm Squeegee and pre-squeegee adjustment: 40 mm Squeegee angle adjustment, stepless: + / - 10° Take-off adjustable: 0 - 40 mm, stepless Fine adjustment of the main frame: + / - 15 mm Maximum material thickness: 0 - 40 mm Machine weight: 600 kg Connection value: 400 volts / 50 Hz - 3 kW Air connection: 6 bar

Condition: good (used), Year of construction: 2016, operating hours: 1,200 h, functionality: fully functional, machine/vehicle number: 90-0122-DDI-IR-INTE, input voltage: 415 V, total length: 3,000 mm, total width: 1,000 mm, total height: 1,000 mm, type of input current: three-phase, year of last overhaul: 2026, conveyor belt width: 800 mm, UV drying tunnel manufactured by Natgraph, designed for use with screen printing machines. The machine was manufactured in 2016 and is in very good technical condition. The tunnel is currently in production use and operates without issues. Main Features: - IR heating section - 2 UV lamps with precise and independent power control - Integrated cooling section to reduce the temperature of printed sheets after curing - Automatic stacker for collecting finished sheets in a neat stack - Possibility to connect with a screen printing machine - Lowering table, which provides easy operator access to the printing machine Working Process The tunnel is used for UV ink curing in the screen printing process. Printed sheets pass through the IR section and then through the UV curing section, where the ink is quickly and evenly cured by UV radiation. After curing, the sheets pass through the cooling section to reduce their temperature. Finished sheets are then automatically collected by the stacker. When connected to a printing machine, the tunnel can automatically adjust the UV lamp power to save energy. Machine Condition Year of manufacture: 2016 Technical condition: very good Machine currently in continuous production use Regularly maintained Included Equipment Natgraph UV dryer tunnel IR heating section 2 UV curing lamps Cooling section Automatic sheet stacker Gkjdpeyuztgjfx Aixoa ✔ Machine ready for production ✔ Inspection possible during operation

Condition: used, Year of construction: 2007, UV Dryer, Cefla UV 2000 - Manufacturer: Cefla/Sorbini - Model: UV 2000 M2 / TTE2500 - Year of manufacture: 2007 - Working width: 1,300 mm (1,445 mm) - Working height: 900 +/- 40 mm - Operator side: right - Max. part height: 70 mm - Number of top lamps: 2 pcs. Gkjdpfxsxn Nlvj Aixea - Lamps, vertically aligned: 2 pcs. - Suitable for mercury lamps - Suitable for gallium lamps - Lamp power, max.: 120 W/cm - Conveyor type: rod transport - Length: 2,500 mm - Width: 2,300 mm - Height: 1,500 mm - Voltage, Hz: 400 V / 50 Hz - Total electrical connection: 86 A / 36.4 kW - Voltage fluctuations max.: +/- 5% Images are for reference only and show a similar machine.*

Condition: used, Year of construction: 2007, with light barriers in the inlet area, the dryer only switches on when parts are detected by the light barrier, otherwise the dryer is in energy-savingstandby mode with almost closed mirror halves. Gkjdpju S N R Eofx Aixoa Operation via a Siemens panel. - Manufacturer: Venjakob - Type: VEN DRY UV 3D - Year of manufacture: 2007 - Operating side: right - Working width: 1.300mm - Max. Part height: approx. 100mm - Number of tubes: 2 pieces - Suitable for mercury and gallium tubes - 3D for edge drying - Tube power max. 120W/cm - Tube power infinitely adjustable 50-120Watt/cm - With standby mode- With belt conveyor - Feed rate: ~ 2.5 - 7.5m/min. - Length: 3,000mm - Bretie: 2.750mm - Total connection ~45KW - Location: in stock - Volt/HZ: 400/50

Condition: used, Year of construction: 2002, machine/vehicle number: 02153/29, AVAILABLE from 08/2026 UV dryer, Cefla UV 2000 - Manufacturer Cefla/Sorbini - Type UV 2000 M2 / TTE2500 - Year of manufacture 2003 - Working width 1.300 mm (1.445) mm - Working height 900 + - 40 mm - Operating side right - Max. part height 70 mm - Number of tubes from above 2 pcs. - Straight tubes 2 pcs. - Suitable for mercury tubes - Suitable for gallium tubes - Tube power max. 120 W/cm - Bar transport - Length 2.500 mm - Width 2.300 mm - Height 1.500 mm - Volts, Hz 400 /50 - Total electrical connection 86 A / 36.4 kW - Voltage fluctuations max. +/- 5% Gkedpfjyifwpsx Aixea Images are only examples of a machine of the same design*

Condition: used, Year of construction: 2018, machine/vehicle number: 318113001, The machine has been partially overhauled and tested. - Manufacturer: Cefla - Model: UV-R3 Gsdex Tpx Aopfx Aixoka - Year of manufacture: 2018 - Working width: 1300 mm - Workpiece height: ~ 3 - 70 mm - Number of top lamps: 3 pcs. - With rod conveyor - Rod spacing: 60 mm - Suitable for mercury lamps - Suitable for gallium lamps - Lamp power: max. 120 W/cm - Connected load: 56 kW / 104A - Voltage, Hz: 400 / 50 - Control cabinet integrated under the machine - Feed speed adjustable: ~ 1.25 - 21.25 m/min - Length: ~ 3,500 mm - Width: ~ 2,700 mm - Height: ~ 1,600 mm - Exhaust air volume: 3,600 m³/h - Location: in stock - Voltage, Hz: 400 / 50

Condition: used, Year of construction: 2005, functionality: fully functional, UV drying tunnel suitable behind screen printing machines B1 size. Fully working. Gjdpfx Aisza Tv Rexoka Including stacker

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, working width: 1,250 mm, pass-through height: 80 mm, UV System Venjakob - IST LIGNOCURE HL 140-4-N-DL, Year of Manufacture: 1999 (1990) POLYMERIZATION SYSTEM consisting of 2 UV dryers: Dryer 1 Overall length 2100 mm Overall width 2339 mm Workpiece dimensions min. 250x20 mm, max. 2500x1000 mm Workpiece height max. 60 mm 1 module with 2 elliptical reflectors (2 UV lamps) Electrode spacing of the IST lamps 140 mm Rotating reflectors Lamp rating 80 W/cm2 per lamp Beam length 1400 mm Lamp power 2 x 11.2 kW Air-cooled housing, capacity 1600 m³/h (motor 1.2 kW) Compressed air consumption 6 NL/h Gjdsyalc Nspfx Aixska Belt conveyor Vanjakob, Year of Manufacture 1999, Type Novo 40 Length 2100 mm Working width 1300 mm Working height 880 - 920 mm Feed 0.75 kW Feed speed 4 – 20 m/min (Line 2 - 4 m/min) Dryer 2 Overall length 3340 mm Overall width 2339 mm Workpiece dimensions min. 250 x 20 mm, max. 2500 x 1000 mm Workpiece height max. 60 mm 1 module with 2 elliptical reflectors (2 UV lamps) Electrode spacing of the IST lamps 140 mm Rotating reflectors Lamp rating 80 W/cm2 per lamp Beam length 1400 mm Lamp power 2 x 11.2 kW Air-cooled housing, capacity 1600 m³/h (motor 1.2 kW) Compressed air consumption 6 NL/h Belt conveyor Vanjakob, Year of Manufacture 1999, Type Novo 40 Length 3340 mm Working width 1300 mm Working height 880 - 920 mm Feed 0.75 kW Feed speed 4 – 20 m/min (Line 2 - 4 m/min) Shared control cabinet for two drying tunnels 2000 x 16000 x 600 mm Operating voltage 400 V, AC, 50 Hz, 3 phases Total power of the complete UV system approx. 50 kW Operating side of the system on the left Weight of the complete system approx. 2500 kg (Subject to change and errors in technical data, as well as prior sale)
