Four rolls bending roll 3000 x 20 mm

FACCIN 4HEP 3135

FACCIN 4HEP 3135
Four roll bending machine
Electronically controlled, hydraulic four-rolls bending machine

Technical specifications:
Number of Rolls: Four
Geometry of the side rolls: planetary guide
Working length: 3000 mm
Top roll diameter: 350 mm
Lower roll diameter: 330 mm
Side rolls diameter: 250 mm
Guaranteed installed power: 14.4 kW
Guaranteed maximum rotation speed: 5 m/min
Guaranteed machine weight: 13,000 kg
Length: 5,700mm
Width: 1,800mm
Height: 2,100mm

Guaranteed capacities:
for material with a yield point of 260 N/mm²

Rolling capacity (full working width) 20 mm
Bending performance (full working width) 15 mm
from pipe diameter 1750 mm

Rolling capacity (full working width) 14mm
Bending capacity (full working width) 12mm
from pipe diameter 455 mm


Standard equipment:
planetary movement of the side rollers
Extra heavy double hinged folding release
Electronic parallelism system EPS
Hardened rolls for high wear protection
cone bending device
Mobile control panel
3 digital displays for the position of the side rolls and the lower roll
Safety trip wire with emergency stop and CE certification
