Parallel lathe 230 x 1500 mm

FERVI T075/400V3A

Condition: good (used), Year of construction: 1994, CNC Spiral bending machine, capacity 50cm3, min-max diam of coil 500-3.500mm. Rsdpoiu Acpjfx Agisck

Condition: used, Year of construction: 1991, Mazak SQT 10MS lathe for sale. The machine is fully functional and in good condition. Technical specifications: Max. turning diameter 230 mm Main spindle Speed range 35-6,000 rpm Main drive power 11 kW Secondary spindle Drive power 5.5 kW Speed range 180 - 6,000 rpm Indexing 72 positions/5 ° Tool turret Number of tool positions 12 Driven tools Speed range 120-3,000 rpm Drive power 2.2 kW Travel paths X-axis 160 mm Rcjdpfx Agsv Tbu Doiek Z-axis 455 mm B-axis 460 mm Travel speed Feed range X/Z-axis 0 - 5,000 mm/min C-axis 1 - 2,000 °/min Machine data (with standard equipment) Total connected load 43 kVA Machine weight, . 3,500 kg Machine dimensions (L x W x H), approx. 2.70 x 1.70 x 1.85 m Accessories Tool presetter (MAZAK Tool Eye System) C-axis Dual foot switch for opening/closing the chuck Chuck status feedback (open/closed) Front door lock Complete coolant system Work area lighting Documentation

Condition: like new (used), MACHINE DATA TORNI TACCHI FTC model 51 OVERALL DIMENSIONS Center distance 4000 m/m Rcedpfxed Tm D Ee Agiok Height 1550 m/m Width 1400 m/m Length 6200 m/m Weight 10.000 Kg Swing over bed 1120 m/m Swing over carriage 810 m/m Swing over gap 1350 m/m Hole through spindle 123 m/m Number of speeds 18 Range of speeds 7-550 / 1’ Horsepower of motor 25HP Morse taper № 6 Metric threads – inch – module – pitch 3 jaw chuck 450 m/m Face plate 850 m/m Extra face plate 1420 m/m Good condition

Condition: used, Holz Her UNO 1303 + PU Edge thickness 0.4 -3 mm (6 mm) Control panel with selector switches for setting the units Fully automatic edge magazine for rolls and strips Adhesive application station: cartridges + PU gluing Workpiece height 6-55 mm Rcodoxlz Nzjpfx Agiek Pneumatic pressure unit Cutting unit for rolls and strips up to 3 mm (6 mm) edge thickness with adjustment of 0-10° angle of the cutting saws Milling unit, flush milling, radius milling, bevel milling - 15° Scraping unit for bevels and radii Surface scraping unit - finish Machine is CHECKED in TOP CONDITION from a very well-maintained craft business from the Lieboch warehouse

Condition: new, turning diameter over bed 410 mm turning diameter over slide rest 240 mm turning length 1000 mm turning diameter in the gap 530 mm turning speeds 65 - 1810 U/min centre height 205 mm Rjdem Rlb Nopfx Agijck spindle bore 52 mm tailstock quill taper MT 4 total power requirement 2,2 kW weight of the machine ca. 0,9 t dimensions of the machine ca. 1,9 x 0,8 x 1,3 m Center lathe with: 3-axis digital measuring system fully assembled electromagnetic main spindle brake auto. Feed in longitudinal and transverse direction safety relay Micrometer end stop coolant device 3-jaw lathe chuck with 1 set of turning and drilling jaws German operating instructions.

Condition: good (used), Year of construction: 1988, Weiler lathe Type Condor B 2-axis digital readout Center height 165 mm Center distance 750 mm Rotation over bed 330 mm Rotation over cross slide 185 mm Spindle bore 40 mm Connected load 3 kw Speed 22-2800 rpm Tailstock MK 3 Coolant pump (not connected) work light Automatic longitudinal and planar feed spindle brake - Folding jaw chuck guard - splash guard Weight approx. 1040 kg 3 jaw lathe chuck Redjvgmbvspfx Agisck Multifix B Rotating center point

Condition: new, TC 165 x 750V Illustration shows MIOTAL® TC 180 x 1000 Center distance: 750 mm Center height: 165 mm Swing diameter over bed: Ø 330 mm Bed width: 190 mm Cross slide travel: 160 mm Top slide travel: 90 mm Spindle connection: DIN 55029 (Camlock) D 1 - 4 Spindle bore: Ø 40 mm Max. Chuck diameter: Ø 200 mm Spindle speed, infinitely variable: 30 - 2000 1/min Mechanical feed stages: 3 Motor power: 2.2 kW Longitudinal feeds Z: (40) 0.044 - 1.96 mm/rev Face feeds X: (40) 0.022 - 0.98 mm/rev Metric thread: (32) 0.4 - 7.0 mm Thread inch: (32) 4 - 56 Gg/inch Thread module: (32) 0.4 - 7.0 Diametral thread: (32) 7.5 - 112 Quill diameter tailstock: Ø 40 mm Inner taper of quill tailstock: MK 3 Quill stroke: 100 mm Lateral adjustment: ± 10 mm Weight, approx.: 650 kg Features: - Acceptance protocol according to DIN - Precise, hardened and ground guides - Robust headstock with recirculating oil lubrication, precision bearing-mounted spindle, hardened and ground gears for long-lasting quality - Electromagnetic spindle brake (TC), frequency converter with electric braking device (V models) - Torsion-resistant machine beds made of MEEHANITE quality casting, stress-free annealed and multi-ribbed for extremely smooth running - Electrical equipment from SIEMENS/SCHNEIDER - Overload protection for feed gearbox - Pulse button for main spindle - CE / IEC as well as German documentation and German service Basic equipment (standard accessories): - Machine stand with splash guard rear panel - 3-jaw lathe chuck - 4-fold steel holder - Foot pedal with mech. brake device - Coolant device - Chuck guard and spindle cover in accordance with European safety standards CE - 1 Fixed center point for main spindle - 1 Fixed center point MK3 - 1 Test report - Safety devices and electrical equipment according to CE - Reducing sleeve for main spindle Operating tool Available options for this lathe: - 3-axis digital readout Rcsdpfx Ajir Igwsgijk - Quick-change holder system Multifix also available as a gearbox version

Condition: good (used), Year of construction: 1990, operating hours: 9,200 h, functionality: fully functional, turning diameter over cross slide: 490 mm, turning length: 850 mm, turning diameter: 700 mm, spindle bore: 80 mm, spindle speed (max.): 3,200 rpm, travel distance X-axis: 330 mm, spindle motor power: 30 W, rapid traverse X-axis: 15 m/min, rapid traverse Z-axis: 20 m/min, total height: 2,620 mm, total length: 3,995 mm, total width: 2,620 mm, Equipment: documentation/manual, Tailstock Chip conveyor Rsdpfx Agsvga Nysijck Tool Control Okuma 5020L Hydraulic chuck Autoblock 500 mm

Condition: good (used), Year of construction: 2011, machine/vehicle number: 2212.287, Automatic panelsaw Schelling Typ:FH 6 430 Maskin nr:221.287 År:2011 Panel beam saw Schelling with automatic, rear-feed,lifting table. For sawing board material, chipboard, MDF, Plywood, Board, Laminate etc. Techn info: Software MCS Evolution 2.0, SPS, Soft-SPS-Siemens WinAC Operating system WINDOWS XP PC with keyboard and mouse TFT monitor 17" Cutting length 4300mm, automatic detection of the start of the plate Cutting width 4300mm Machine accuracy of the cut length 3m +-0.1mm Positioning accuracy measured at input +-0.1mm Max diameter saw blade 460mm, spindle 30mm Pre-scoring blade 200mm, spindle 20mm motor operation is set from the control console Max panel thickness 120mm Panel stack aligner Main saw blade motor 27kw Saw blade over table 135mm Safety curtain Air cushion table with 3pcs air ball nozzles, radial ventilator fan Table sizes 2650x850mm 620x850mm Rsdpfxjtk It Se Agieck 2650x2550mm Pressure beam with automatic adjustment of pressure to cut length and package height Package straightener before and after the pressure beam Max package height 120mm (incl. sum of curvature and board thickness tolerance) Pusher with 12 grippers Max clamp opening (gripper) 133mm Min-max force package straightener 400/2000N Speed saw carriage forward 6-150m/min Speed saw carriage back 150m/min Forward feed speed (pusher) up to 25m/min (according to EC Europa EN1870-13) other countries 80m/min Speed feeding back up to 80m/min Push-off device 3 pcs Lift table length x width 4350x2550mm Hydraulic unit Standard version 1600mm lifting height 1.25/2.5m/min raising speed, 1.25/5m/min lowering speed Maximum load 1200 kg/m2 total 9 tons Roller track driven rollers, frequency controlled for stack on lifting table 4100x2600mm Max stack weight 6500 kg Max stack length 1060mm Slots for forklift 4 pcs, distance in the middle 1200mm, slot width 300mm Light curtain for personal protection Roller conveyor driven for package frequency controlled input to lifting table left 5600x2600mm max load 6500kg Roller conveyor driven for packages frequency controlled input to lifting table right 5600x2600mm max load 6500kg Slots for forklift 2 pcs, center distance 900mm, slot width 400mm 2 positioning stops with roller for stack alignment Light curtain (double beam) for personal protection Roller table after saw depth 4300mm, free-running ployamide rollers Angle stop at the rolling table Infeed guide two-lane (beam length 7200mm) 2-sided hardened precision guides rack and pinion drive, two-sided Input carriage (pusher) gear rack servo drive, non-contact measuring system Gripper, (scissor clamps) in pusher 12 pcs Automatic adaptation of the clamping force to the package height (progressive clamping force) can be set to 0 Pusher for panels thickness greater than 6mm,material thinner than 6mm is fed manually Central cleaning system feed trough (pusher) Compressed air 6-8 bar, approx. 1600l/min Power 38 kw, 70 A. 3x400 volts, 50 Hz, operating voltage 24 VDC Dust extraction 4000m/h, air speed 30m/s Diameter connection 80mm (angle connection), 120mm /pressure beam), 150mm (sawdust channel) Total setup area without driven roller conveyors including protective grid approx: 11650x7300mm Driven roller tracks left-right 5500+5500mm Stock no: 2002125BXACEO Subject to incorrect technical data presented

Condition: good (used), Centre height: 195 mm Distance between centres: 1250 mm Max. swing diameter over bed/cross slide: 400/265 mm Spindle mount/bore: Camlock D1-6"/54 mm Tailstock quill taper: MT 5 Spindle speeds steplessly adjustable in 3 ranges: 0 - 2500 rpm Longitudinal feeds: 0.018 - 1.2 mm/rev Rcsdpfx Agjxlg Dwoiok Cross feeds: 1/2 of longitudinal feeds 51 metric thread pitches: 0.2 - 14 mm 56 imperial (inch) threads: 2 - 56 TPI 20 module threads: 0.2 - 3.5 module 20 diametral pitch threads: 8 - 56 DP Electrical connection: 400 V, 7.5 kW Weight: 1500 kg Space requirement: 2500 x 1300 x 1300 mm
