CNC SAWING LINE

FICEP 603 LBH

Condition: refurbished (used), functionality: fully functional, Year of construction: 2007, DAVI_MCB 3060 WT 4-roll plate bending machine CNC _ 3000x65 MM - Year of make 2007 Capacity plate width 3100 mm Plate thickness 65 mm Prebend 55 mm TOP ROLL 600 MM LOWER ROLL 550 MM Configuration installed: • Surface hardening of the four rolls • Dual pre-pinch, with adjustable force upon the input of plate thickness • Conical bending hydraulic attachment - hardened contrast pad. • Power driven rolls rotation top/bottom gearbox axial direct drive hydraulic each roll. • Calibration system for re-rolling of welded shells rounding. • Console electric independent with centralized commands joysticks and CNC screen readout. • CNC controller DAVI GENIUS semiautomatic and fully automatic programmable. with digital readout of the 4rollers for use in manual operation, • Opening front side hydraulic drop-end to unload closed shells. • Variable working speed step-less axis interpolation. • Safety installation with emergency stop. • Instruction manuals for operation and service Voltage electric 3phase Vac 380/50 power Kw 75 nr.1 top support hydraulic operated , shell ID max 5 mtrs - CNC programmable nr.1 side support hydraulic on the left nr.1 side support hydraulic on the right, finger pusher to swing the sheet plate forming cones rolling. Cedjy D Npiopfx Af Hogu

Condition: used, Year of construction: 2006, Web height min 80mm. max 1220mm. Flanges height min 42mm.max. 600mm. U channels min. 80mm 1200mm Flanges height min.45mm max 300mm. Angles min. 80x80x8mm max.300x300x50mm Flats min.100mm max.1220mm Square tubes min.80x80mm max.600x600mm Rectangular tubes min. 80x40mm max.1200x600mm Positioning weight max. 15000Kg Linear weight of the section to be handled max. 750Kg/m Carriage speed max. 30m/min. No. of drill heads 3 - two horizontal Drill Heads with single spindle - one vertical Drill Head with single spindle Max. drilling diameter 50 mm. - with tapered adaptor No.4 Max. thickness that can be drilled 75 mm. Cgedpfxox N Iclj Af Hsu Spindle rotation motor per head (a.c.) 15 kW Spindle R.P.M. (with continuous adjustment by program) RPM 180 - 3000 Positioning stroke to suit the gauge line :- vertical drilling unit 20 to 1200 mm.- horizontal drilling units 10 to 600 mm. TOOL CHANGE - number of tools change devices n. 3 - number of tools to be changed n. 6 - adaptor size ISO 45 Model 1260 BH for sections cold sawing : - sawing capacity at 90° min. 80 x 10 mm - sawing capacity at 90° 1250 x 600 mm - sawing capacity at 45° 800 x 600 mm - sawing capacity at 60° 500 x 500 mm - sawing band motor 11 kW - sawing speed 20÷100 m/min. - band size 67 x 1.6

Condition: used, Year of construction: 1999, functionality: fully functional, KALTENBACH Saw and Drilling Line – KBS 851 DGNC + APS 1003 – up to 1,000 mm – Year of Manufacture: 1999 General Information: Manufacturer: Kaltenbach Machine Type: Automatic saw and drilling line for steel profiles Bandsaw: KALTENBACH KBS 851 DGNC Drill Line: KALTENBACH APS 1003 Year of Manufacture: 1999 Condition: Used, fully functional Location: Germany Availability: Dismantling possible from mid/end of March 2026 Inspection: The system is operational and can be inspected under power Sale: Without guarantee or warranty Machine Description: For sale is a complete Kaltenbach saw and drilling system for processing heavy steel profiles. The line consists of a CNC-controlled bandsaw KBS 851 DGNC as well as a drilling unit APS 1003, including extensive infeed and outfeed roller conveyors and cross transfer conveyors. The system is currently in operation and has been reliably used in steel construction until now. It is ideally suited for efficient processing of beams and profiles in both series and project work. Typical Areas of Application: - Steel construction / hall construction - Metalworking - Beam processing (IPE, HEA, HEB, UPN, etc.) - Series and single-part manufacturing Technical Data: Bandsaw KBS 851 DGNC: - Maximum beam height: up to 800 mm - Mitre cutting: swivelable on both sides +45° / –45° - CNC-controlled length positioning - Automatic sawing mode Drill Line APS 1003: - Maximum beam height: up to 1,000 mm - CNC-controlled profile processing via drill portal Cjdpjyak Anjfx Af Hjgu - Suitable for web and flange machining Roller Conveyors & Material Handling: - Roller conveyor width: 1,000 mm - Infeed roller conveyor: approx. 15,000 mm - Outfeed roller conveyor: approx. 15,000 mm - Infeed cross transfer conveyor: approx. 4,000 mm - Outfeed cross transfer conveyor: approx. 4,000 mm Condition: - System is complete and fully functional - Currently in operation - Age and usage-related signs of wear - Sale as is - No guarantee or warranty Scope of Delivery: - Bandsaw KBS 851 DGNC - Drill line APS 1003 - Infeed and outfeed roller conveyors - Cross transfer conveyors (infeed and outfeed) - Control cabinet / operating unit - Existing safety devices - Documentation where available Dismantling & Loading: - Dismantling to be carried out by the buyer - Dismantling possible from the end of March 2026 - On site available: * Forklift truck * 2 gantry cranes each with 5 t lifting capacity - Good site access and loading conditions

Condition: good (used), 450 A with premium panel. 16 units available. Price per unit: €2,500 excl. VAT. Cedjx Emufepfx Af Hogu

Condition: new, Year of construction: 2025, control type: NC control, actuation type: hydraulic, number of rollers: 4, roller (bottom) diameter: 280 mm, roller (top) diameter: 280 mm, side roll diameter: 220 mm, roller length: 2,550 mm, sheet thickness (max.): 16 mm, STANDARD EQUIPMENT * The upper, lower, and side rolls move linearly up and down via hydraulically actuated body-mounted pistons. * Protected against overload. * Upper and side rolls are driven by hydromotors and planetary gearboxes (all three rolls are motor-driven). * The positions of the rolls can be easily read through three digital display gauges. * The hydraulically opening head and automatic upward-lifting shaft allow easy removal of the bent workpiece. * Very user-friendly operation with a mobile control panel. * Welded steel construction body. * Rolls made from SAE 1050 (CK 50) induction-hardened, forged or rolled steel shafts. * Conical bending system. * Centralized lubrication system. * Hydraulic balancing system for parallel movement of the rolls (Ø280 - 320 - 350 - 380 - 400 - 460). * Electronic balancing system (Ø500 - 550 - 580 - 620 - 680). * Dual-speed operating system. OPTIONAL EQUIPMENT * Automation with NC and CNC control consoles. * Upper crane (hoist) for support in large diameter rolling. * Hydraulic side supports for large diameter rolling. * Hydraulic plate ejector system. * Ground and polished rolls for special applications. * Infinitely variable speed adjustment system. * Electronic balancing system for parallel movement of the rolls (Ø280 - 320 - 350 - 380 - 400 - 460). TECHNICAL SPECIFICATIONS Bending Length: 2550 mm Pre-bending: 10/12 mm Cgsdpfew Smfcox Af Heu Bending: 12/16 mm Upper & Lower Roll: 280 mm Side Roll: 220 mm Motor Power: 16.5 kW Bending Speed: 1.5 - 5 m/min Length: 4850 mm Width: 1700 mm Height: 1850 mm Weight: 9650 kg
