Throughfeed drilling machine

Format4 Creator 950

Condition: like new (used), Year of construction: 2022, operating hours: 45 h, functionality: fully functional, feed length X-axis: 3,500 mm, feed length Y-axis: 950 mm, feed length Z-axis: 80 mm, travel distance X-axis: 1,475 mm, travel distance Y-axis: 1,550 mm, travel distance Z-axis: 225 mm, rotational speed (min.): 24,000 rpm, Equipment: rotational speed infinitely variable, CNC continuous feed center with clamp drive Creator 950 Advanced only 45 operating hours Creator processing area: travel of the axes: X=1475mm Y=1550mm Z=225mm Working area: X=3500mm Y=950mm Z=80mm Drill head DH 17 6H 1S - 11 vertical spindles - 6 horizontal spindles - 1 grooving saw in X direction Credpfx Aov Dty Togmjh Milling spindle 12 KW (S6) HSK F63 24000 rpm, ceramic bearing with automatic height-adjustable suction hood 2 second gripping pliers enable formatting up to 15 mm, as well as continuous milling movement in X direction. Support table made of phenolic resin with a support surface of X=1200mm Y=950mm (front + rear) Woodflash: The Woodflash machine software package includes the complete control management of the CNC machine for 2 workstations - 1 machine workstation and 1 external workstation. The software consists of: - CNC board - tool database - program editor The single pick-up location enables ergonomic changing of tools and units. The pick-up location can be used as a tool change position or as a transfer location for another tool changer. In addition, 10 fictitious tool locations are available for this pick-up location. This means that up to 11 different tools can be used from this pick-up changer in the CNC program. The 4-way linear changer ensures the shortest changeover times and offers sufficient space for milling tools and units (see layout). (For equipment variants, see layout) Max. tool diameter 120 mm Max. tool length l00mm Foldable roller table (front + rear), extends the support surface, suitable for machining large workpieces

Year of construction: 2021, condition: ready for operation (used), Main Drive Spindle speed range 24000 rpm Spindle motor power 12 KW Tool taper HSK F63 Number of axis 3 Movement X-Axis Movement 3500 mm Y-Axis Movement 950 mm Z-Axis Movement 80 mm Table Table load 130 kg Tools Max weight 7.5 kg Credpfxjwttzho Agmoh Additional Equipment Teleservice package via Internet Automatic central lubrication 4-fold linear changer for use with power packs Main Drive Spindle speed range 24000 rpm Spindle motor power 12 KW Tool taper HSK F63 Number of axis 3 Movement X-Axis Movement 3500 mm Y-Axis Movement 950 mm Z-Axis Movement 80 mm Table Table load 130 kg Tools Max weight 7.5 kg Additional Equipment Teleservice package via Internet Automatic central lubrication 4-fold linear changer for use with power packs This 3-axis FORMAT4 Creator 950 CNC Wood Machining Centre was manufactured in 2021. Ideal for precision woodworking, it offers robust construction and advanced control features. Consider the opportunity to buy this FORMAT4 Creator 950 CNC Wood Machining Centre. Contact us for more information. Application Types CNC Wood Machining

Condition: as good as new (ex-display), functionality: fully functional, The Format4 creator 950 in a wide range of equipment variants - your CNC machine for individual woodworking challenges. Efficient CNC processing at a fair price - this principle is at the heart of the creator machine series. All models are attractively equipped with the latest CNC technology and can be customized to meet specific requirements. The creator 950 is not only an easy and safe entry into the CNC world, but also serves to relieve your CNC machining centers. Your advantages at a glance: Concentrated CNC technology on a footprint of just 5 m² All-inclusive: 4-sided formatting as standard Get started right away: Maximum productivity without set-up times No suction cup and console positioning Use from interior fittings to room doors Traditional processing from above - extremely simple loading Intuitive control via control panel Easy to understand software Best suction result High-end at the best price in every configuration Carcass processing with Lamello Clamex-P Additional equipment: C19 2nd stop reference cylinder for long workpieces C71 Folding support tables front+rear - roller table C198 Pick-up space for tool and unit change C200 4-fold linear changer for use of units C233 Holder for crane transport C490 F4design (incl. 3-axis PP) Csdpfxeu Eg A Ue Agmjrh 800 E-Learning F4Design Creator processing field: Travel of the axis X= 1475mm (bracket) Y=1550mm Z= 225 mm Working field X= 3500 mm (infinite) or 130 kg maximum load Y= 950 mm Z= 80 mm Machinable workpiece Equipped with: High-performance PC 24" LED color display Keyboard, mouse and mouse pad 1 USB interface
